MAN 4WD 5000L Small Water Fire Truck

BRIEF

The MAN 4WD 5,000L Small Water Fire Truck, produced by MAN and integrated by CSCTRUCK Fire Rescue Truck, is a compact yet highly capable emergency response unit designed for rapid deployment in urban, industrial, and semi-off-road firefighting scenarios. Built on a rugged MAN 4×4 chassis, the vehicle combines strong mobility with reliable firefighting performance, making it suitable for environments where accessibility and response time are critical.

At its core, the truck is powered by a MAN D0836LFL95 diesel engine delivering 250 hp (184 kW), paired with a TipMatic 12.12 OD automatic transmission. This drivetrain ensures smooth power delivery and efficient handling across a wide range of terrain. The 4,500 mm wheelbase and full 4×4 axle configuration, supported by spring suspension and 14.00R20 tires, provide stability, durability, and off-road capability. A 300-liter fuel tank and air-conditioned day cab enhance operational endurance and crew comfort during extended missions.

The firefighting system is centered around a 5,000-liter water tank and a rear-mounted CINAR 3000 N pump, capable of delivering 3,000 L/min at 10 bar and 250 L/min at 40 bar. This dual-pressure capability allows both high-volume suppression and high-pressure targeted firefighting. The system is equipped with two 2.5-inch STORZ outlets, dual 1-inch × 60 m manual rewind hoses, and a CINAR aluminum monitor capable of 2,700 L/min water/foam discharge, ensuring flexible and effective fire control.

The MAN 4WD 5,000L Small Water Fire Truck features a practical 1+1 locker layout for equipment storage and an integrated firefighting engine system designed for rapid response operations. Overall, this compact water tender is engineered for fast mobilization, strong pumping performance, and dependable operation, making it an efficient solution for municipal fire departments and industrial safety applications requiring a high-performance yet maneuverable firefighting unit.

FEATURES

1. Rugged 4×4 All-Terrain Chassis
   Built on a MAN 4WD (4×4) chassis with a 4,500 mm wheelbase, spring suspension, and 14.00R20 tires, the truck offers robust off-road mobility and stability in urban, industrial, and semi-rough environments.
2. High-Performance Diesel Powertrain
   Equipped with a MAN D0836LFL95 diesel engine producing 250 hp (184 kW), paired with a TipMatic 12.12 OD automatic transmission, ensuring smooth power delivery and efficient driving performance under emergency conditions.
3. 5,000-Liter Water Tank Capacity
   The integrated 5,000L water tank provides substantial firefighting endurance, enabling extended operations without frequent refilling during municipal or industrial fire response.
4. Dual-Mode High-Efficiency Pump System
   Features a rear-mounted CINAR 3000 N pump capable of 3,000 L/min at 10 bar and 250 L/min at 40 bar, offering both high-volume suppression and high-pressure targeted firefighting capability.
5. Flexible Firefighting Equipment Configuration
   Includes dual 2.5-inch STORZ outlets, 1-inch × 60 m manual rewind hoses, and a CINAR aluminum monitor with up to 2,700 L/min discharge capacity, supported by a practical 1+1 equipment locker layout for rapid deployment.

SPECIFICATION

1. General Vehicle Data

2. Chassis & Running Gear

3. Axle Specifications

4. Firefighting System

5. Remarks
