The Volvo 54M aerial platform fire truck, produced by CSCTRUCK Fire Rescue Truck, is a high-performance vehicle designed for advanced fire rescue operations. This truck is built on a Volvo FM540 8×4 chassis with an 8×4 drive type, giving it excellent stability and maneuverability. With a gross vehicle weight of 40,200kg, it carries a 2,500kg water tanker and a 500kg foam tanker, offering significant firefighting resources on-site.

One of its standout features is its 54-meter rated working height, making it ideal for high-rise firefighting and rescue operations. The fire truck‘s 400kg-rated load on the platform ensures the safe and effective deployment of rescue personnel and equipment at height. With a maximum working radius of 18 meters, the truck can efficiently access difficult-to-reach areas.

Performance-wise, it has a 398kW max net power, and its maximum travel speed reaches ≥85km/h, allowing it to respond swiftly to emergencies. The boom deployment time is ≤200 seconds and the outriggers can be deployed in ≤30 seconds, ensuring rapid setup at the scene.

For firefighting capabilities, the fire truck features a water monitor with a ≥64L/s rated flow and ≥65m reach, while its water pump delivers a ≥100L/s rated flow at ≥1MPa rated pressure. This makes the Volvo 54M aerial platform fire truck an essential asset for large-scale firefighting operations.

1. Aerial Platform & Height: The truck features a 54-meter rated working height with an 18-meter maximum working radius, providing excellent reach for firefighting and rescue operations.

2. Water & Foam Tank Capacity: Equipped with a 2,500kg water tanker and a 500kg foam tanker, allowing it to handle a range of firefighting tasks.

3. Chassis & Drive Type: Built on a Volvo FM540 8×4 chassis with an 8×4 drive configuration, offering stability and power on diverse terrains.

4. Firefighting Power: The water monitor has a rated flow of ≥64L/s and a reach of ≥65 meters, while the water pump delivers a fire-rated flow of ≥100L/s and a pressure of ≥1MPa, ensuring powerful firefighting capabilities.

5. Gross Vehicle Weight & Speed: The truck has a gross vehicle weight of 40,200kg and a maximum travel speed of ≥85km/h, making it highly capable of rapid response despite its size.
