The Volvo 45M aerial platform fire truck, produced by CSCTRUCK Fire Rescue Truck, is a specialized firefighting vehicle designed for high-performance emergency response. Built on the reliable Volvo FM540 8×4 chassis, the truck features an 8×4 drive type, providing excellent traction and stability for challenging terrains. It has a 4,000kg water tanker and a 2,000kg foam tanker, offering robust firefighting capacity.

With a 45-meter rated working height, the fire truck is well-suited for operations in high-rise buildings and difficult-to-reach areas. The gross vehicle weight of the truck is 41,200kg, and it can travel at speeds of up to ≥90km/h. Powered by a 405kW engine, it delivers efficient and powerful performance during emergencies.

The aerial platform has a maximum working radius of 23 meters(500kg) and 25 meters(320kg), ensuring flexible access to various heights and angles during rescue operations. The boom deployment time is ≤150 seconds, while the outriggers can be deployed in ≤40 seconds, optimizing setup time.

The fire truck‘s water monitor has a rated flow of ≥80L/s and a reach of ≥70 meters, ensuring strong water delivery. Additionally, the fire-rated water pump has a capacity of ≥100L/s and can deliver pressures of ≥1MPa, making the Volvo 45M an exceptional tool for both firefighting and rescue missions in urban and industrial environments.

1. Chassis and Drive Type: Built on a Volvo FM540 8×4 chassis, offering an 8×4 drive configuration for optimal stability and maneuverability in challenging terrains.

2. Tank Capacity: Equipped with a 4,000kg water tanker and a 2,000kg foam tanker, allowing it to carry significant fire suppression resources.

3. Performance and Power: Powered by a 405kW engine, the truck achieves a maximum travel speed of ≥90km/h with a gross vehicle weight of 41,200kg.

4. Aerial Platform Specifications: The aerial platform has a rated working height of 45m and a maximum working radius of 23m(500kg) or 25m(320kg), making it suitable for high-rise firefighting.

5. Water Delivery System: Features a high-capacity water monitor with a flow rate of ≥80L/s, a rated reach of ≥70m, and a fire pump with a rated flow of ≥100L/s and a pressure of ≥1MPa for efficient firefighting.
