BRIEF
The SITRAK 32M small aerial platform fire truck, produced by CSCTRUCK Fire Rescue Truck, is a versatile and efficient fire-fighting vehicle designed to meet modern emergency response demands. This advanced truck boasts a maximum working height of 32 meters, making it ideal for high-rise fire operations and rescue missions. Its minimum turning diameter of 17 meters ensures excellent maneuverability, even in confined urban environments.
Built on a robust SITRAK chassis with a 4×2 drive configuration, the truck combines reliability with agility. Powered by the MC07.28-50 engine, the vehicle delivers an impressive 203 kW of power while adhering to the EURO V emission standard, ensuring environmentally responsible performance. The engine enables the truck to reach a maximum driving speed of at least 90 km/h, allowing for rapid deployment to emergency sites.
A key feature of the SITRAK 32M fire truck is its 400 kg work platform load capacity, providing ample support for firefighters and rescue equipment during operations. This capability enhances the truck’s efficiency in tackling complex rescue scenarios, such as evacuating multiple individuals or handling heavy tools.
The SITRAK 32M small aerial platform fire truck is meticulously engineered for durability, safety, and operational efficiency, making it a vital asset for fire departments and rescue teams. Its blend of high-performance features, such as the extended aerial reach, powerful engine, and environmental compliance, underscores its suitability for diverse emergency applications. Whether addressing urban fires, conducting rescues, or responding to disaster scenarios, the SITRAK 32M stands out as a reliable and effective fire rescue vehicle.
FEATURES
- High-Performance Aerial Platform:
- Maximum working height of 32 meters, suitable for high-rise rescue operations.
- Work platform load capacity of 400 kg, accommodating multiple personnel and equipment.
- Compact Maneuverability:
- Minimum turning diameter of 17 meters, allowing for effective navigation in tight urban spaces.
- Powerful and Efficient Engine:
- Equipped with the MC07.28-50 engine model delivering 203kW of power.
- Meets the EURO V emission standard, ensuring environmental compliance.
- Reliable Chassis and Drive Type:
- Built on a robust SITRAK chassis with a 4×2 drive configuration, providing stability and durability.
- Impressive Speed and Mobility:
- Capable of reaching a maximum driving speed of ≥90 km/h, ensuring rapid response to emergencies.
SPECIFICATION
| Items | Parameters | |||
| Size parameters | Boundary dimension | Length | mm | 9,650 |
| Width | mm | 2,500 | ||
| Height | mm | 3,880 | ||
| Wheelbase | mm | 4,500 | ||
| Wheel track | mm | 1,998/1,830 | ||
| Front overhang/rear overhang | mm | 1,430/2,710 | ||
| Driving parameters | Maximum speed | km/h | 90 | |
| Minimum turning diameter | m | 17 | ||
| Braking distance (full load, initial braking speed 30km/h)m | ≤10 | |||
| Approach/departure angle | ° | 16/10 | ||
| Maximum gradability | % | 25 | ||
| Quality parameters | Curb weight | Total mass | kg | 17,880 |
| First shaft | kg | 6,010 | ||
| Second shaft | kg | 11,870 | ||
| Maximum allowable total mass | Total mass | kg | 18,030 | |
| First shaft | kg | 6,180 | ||
| Second shaft | kg | 11,850 | ||
| Chassis parameters | Model | ZZ5206N501GE1 | ||
| Drive Type | 4×2 | |||
| Manufacturer | SINOTRUK | |||
| Engine | Model | MC07.28-50 | ||
| Fuel types and labels | Diesel/0#(In winter:-10#) | |||
| Emission Standards | National V | |||
| Displacement L | 6.78 | |||
| Maximum net power | kW | 203 | ||
| Rated power/speed | kW/(r/min) | 206/2,300 | ||
| Maximum torque/speed | N·m/(r/min) | 1,100/1,200~1,800 | ||
| Manufacturer | SINOTRUK | |||
| Number of leaf springs (front/back) | 3/5 | |||
| Tire specifications | 295/80R22.5 | |||
| Spare tire specification | 295/80R22.5 | |||
| Number of tires (number of spare tires) | 6(1) | |||
| Passengers | people | 2 | ||
