BRIEF
The SITRAK 18M aerial ladder fire truck, produced by CSCTRUCK Fire Rescue Truck, is a versatile and efficient firefighting vehicle designed to tackle urban emergencies. Built on a Sinotruk Sitrak chassis, this fire truck features a 4×2 drive type and has a full load weight of 18,000 kg. It can reach a top speed of 90 km/h, powered by a robust 225 kW engine, making it ideal for rapid response scenarios.
Equipped with an 18-meter telescopic ladder, the SITRAK 18M fire truck enables firefighters to access heights up to 18 meters, which is essential for rescuing individuals trapped in high-rise buildings. The truck’s onboard water and foam systems further enhance its firefighting capabilities, with a 2,800-liter water tank and a 500-liter Type A foam tank, both made of durable PP composite material. The vehicle’s high-performance fire pump delivers a flow rate of 60 liters per second at 10 bars of pressure, while its fire monitor provides a flow rate of 30 liters per second and can shoot up to 55 meters, making it effective for distant fire suppression.
The SITRAK 18M aerial ladder fire truck also includes a compressed air foam system with a flow rate of 100 liters per second, allowing for efficient fire suppression in situations where water alone may not be sufficient. With its powerful features and dependable design, this fire truck is a valuable asset for urban firefighting and rescue operations.
FEATURES
1. High Reach and Stability: Equipped with an 18-meter aerial ladder, allowing for effective access to elevated areas during rescue operations.
2. Large Water and Foam Capacity: Features a 2,800L water tank and a 500L Type A foam tank made from durable PP composite material, providing substantial firefighting resources.
3. Powerful Engine and Drive: Built on the Sinotruk Sitrak 4×2 chassis with an engine power of 225kW, reaching speeds up to 90 km/h with a full load weight of 18,000kg, ensuring quick response.
4. High-Performance Pump and Monitor: Contains a fire pump with a flow rate of 60L/s at 10 bar and a fire monitor with a flow rate of 30L/s, achieving a shooting range of ≥55 meters.
5. Compressed Air Foam System: Supports a compressed air foam flow of up to 100L/s, enabling effective fire suppression, especially for flammable liquid fires.
SPECIFICATION
No. | Main Items | Technical Parameters |
1 | Model | CSCALFT018 |
2 | Overall Dimensions(LxWxH) | 8,430×2,500×3,620mm |
3 | Full Load Weight | 18,000kgs |
4 | Number of the Crew | 2+4 (include driver) |
5 | Max. Speed | 90km/h |
6 | Capacity | 2,800L Water & 500L Type A Foam. PP composite material liquid tank. |
7 | Fire pump flow rate | 60L/s@10bar |
8 | Compressed Air Foam Flow | 100L/s |
9 | Max. working height | 18meters |
Superstructure
1 Original Cabin
- Structure: Double-row cabin with 4 doors.
- Seats: 2+4, with 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with storage box under the rear 4 seats.
2 Standardized Sub-frame
- Material: High-strength rectangular tube made of special steel.
- Performance: The liquid tank and the sub-frame are connected by elastic connecting seats.
3 Aluminum Compartment
- Material: High-strength aluminum alloy profiles (Never Rust).
- Structure: Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear.
4 Aluminum Roller Shutter
- Material: Aluminum alloy profiles with anodized surface.
- Structure: With rain-proof groove on the top, lever-type bar, lock handle, pull strap, two-point fixed seat, LED light, and sensors.
5 Foot Pedals
- Material: High-quality aluminum alloy.
- Structure: 50cm width, bearing more than 300kg, anti-slip design, with double lock function. Mounted on both sides of the compartment.
Fire Extinguishing System
No. | Main Items | Technical Parameters |
1 | Fire Pump | |
1.1 | Brand | Optional |
1.2 | Model | Optional |
1.3 | Rated Flow Rate | 60L/s @ 10bar |
1.4 | Vacuum Pump | Electric vacuum pump |
1.5 | Priming Manner | Automatic |
1.6 | Suction Height | 7m |
1.7 | Priming Time | ≤80s |
1.8 | Location | Rear-mounted |
2 | Fire Monitor | |
2.1 | Brand | Optional |
2.2 | Model | Optional |
2.2 | Flow Rate | 30L/s |
2.3 | Shoot Range | 55m |
2.4 | Location | On the top of the boom |
2.5 | Control Manner | Manual |
2.6 | Horizontal Rotation Angle | 0°~360° |
2.7 | Pitch Rotation Angle | -15°~60° |
3 | Liquid Tank | |
3.1 | Capacity | Water 2,800L, Type A Foam 500L |
3.2 | Material | PP composite material and Never Rust |
3.3 | Structure | Two Tank Manhole; One Overflow Device/Pressure Relief Device; Two Liquid Level Indicators; One Foam tank Drain Outlets with Valves; One Water tank Drain Outlets with Valves. |
4 | Control Panel | |
4.1 | Structure | Each fire extinguishing system is controlled by PLC, and different standardized control modules can be selected. IP56 protection level |
4.2 | Location | Rear pump room. |
