BRIEF
The SITRAK 10-wheeler pumper fire truck, produced by CSCTRUCK Fire Rescue Truck, is a high-performance firefighting vehicle designed for rapid response and large-scale fire suppression. Built on the Sinotruk SITRAK ZZ5356V524MF1 chassis, it features a 6×4 drive type, allowing for enhanced stability and maneuverability in challenging environments. The truck boasts a full-loaded maximum driving speed exceeding 90 km/h, ensuring quick deployment to emergency sites.
At the core of its firefighting capabilities is a 420L/S booster pump, operating at a rated pressure of 1.2 MPa, powered by a 965 kW engine. This high-capacity system ensures a strong and consistent water supply for effective fire suppression. Additionally, the truck is equipped with 2 Pontoon pumps, each with a rated flow of 210L/S and a pressure of 0.4 MPa, weighing less than 100 kg. These pumps enhance the truck’s ability to draw water from external sources, making it highly adaptable to various firefighting scenarios.
For rescue and lifting operations, the fire truck includes a boom system with a 20T.m lifting capacity and a maximum working radius of 17 meters. It is capable of lifting loads over 500 kg, making it ideal for rescue missions involving elevated structures or hazardous conditions.
Powered by an engine rated at 460 kW at 1,600 rpm, the SITRAK fire truck delivers robust performance while maintaining operational efficiency. Its combination of high-capacity pumping systems, strong lifting capabilities, and rapid mobility makes it a reliable asset for emergency response teams handling large-scale fires and complex rescue operations.
FEATURES
- High-Performance Booster Pump – Equipped with a 420L/S booster pump with a rated pressure of 1.2 MPa and an engine power of 965 kW, ensuring powerful water delivery for firefighting operations.
- Robust Chassis & Drivetrain – Built on a Sinotruk SITRAK/ZZ5356V524MF1 chassis with a 6×4 drive type, providing excellent durability and mobility. It can achieve a maximum driving speed of over 90 km/h when fully loaded.
- Efficient Pontoon Pump System – Includes 2 pontoon pumps, each with a rated flow of 210L/S, a pressure of 0.4 MPa, and a lightweight design of under 100 kg, enhancing its ability to draw water from various sources.
- Powerful Boom System – Features a 20T.m lifting capacity, a maximum working radius of 17m, and a lifting weight exceeding 500kg, making it suitable for various rescue and support operations.
- Strong Engine Performance – The 460 kW engine operating at 1,600 rpm ensures superior power and efficiency, supporting both firefighting and rescue operations in demanding conditions.
SPECIFICATION
Performance |
Unit |
Parameter |
|
Dimensions(LxWxH) | mm | 11,848×2,520×3,970 | |
Total mass | kg | 28,000 | |
Chassis model | / | Sinotruk SITRAK ZZ5356V524MF1 | |
Number of passengers | person | 2 | |
Maximum speed | km/h | >90 (fully loaded) | |
Engine power rating/speed | kW/rpm | 460/1,600 | |
Chassis wheelbase | mm | 5,400+1,400 | |
Pontoon pumps | Rated flow | L/s | 210 |
Rated pressure | Mpa | 0.4 | |
Weight | kg | <100 | |
Quantity | EA | 2 | |
Booster pump | Rated flow | L/s | 420 |
Rated pressure | Mpa | 1.2 | |
Engine power | kW | 965 | |
Boom system | Lifting capacity | T.m | 20 |
Maximum working radius | m | 17 | |
Maximum lifting weight | kg | >500. |
