BRIEF
The Mercedes-Benz 60M water tower fire truck, manufactured by CSCTRUCK Fire Rescue Truck, is an advanced firefighting vehicle designed for high-demand scenarios, especially where tall structures are involved. With a maximum working height of 60 meters, it’s equipped to tackle fires in high-rise buildings effectively. This robust truck features a 6,000-liter water tank and a 2,000-liter foam tank, ensuring an ample supply of fire suppression agents.
Built on a Mercedes-Benz chassis with an 8×4 drive type, this Mercedes-Benz 60M water tower fire truck offers optimal stability and power distribution across challenging terrains. The full load weight is a substantial 42,600kg, making it a heavyweight in both capacity and capability. Despite its size, the truck can reach speeds of up to 90 km/h, powered by a 375kW engine.
The firefighting systems are highly efficient, with a fire pump flow rate of 170 L/s at 10.3 bar and a fire monitor flow rate of 80 L/s, capable of reaching a shooting range of 70 meters or more. The tank, constructed from polypropylene (PP) composite material, is designed for durability and corrosion resistance, enhancing the truck’s longevity and performance in harsh environments.
In summary, this water tower fire truck by CSCTRUCK Fire Rescue Truck combines a powerful engine, high water, and foam capacity, and impressive firefighting reach, making it a valuable asset for urban and industrial firefighting operations.
FEATURES
1. High Working Reach: With a maximum working height of 60 meters, this fire truck is designed for high-rise firefighting, allowing firefighters to reach elevated areas efficiently.
2. Large Water and Foam Capacity: Equipped with a 6,000-liter water tank and a 2,000-liter foam tank, it provides ample resources for prolonged firefighting operations, ideal for tackling both liquid and solid fuel fires.
3. Powerful Fire Pump and Monitor: The truck’s fire pump delivers a robust flow rate of 170 liters per second at 10.3 bar, while its fire monitor provides an 80 liters per second flow rate, capable of reaching distances over 70 meters, ensuring effective firefighting from a distance.
4. Reliable Mercedes-Benz Chassis with 8×4 Drive: Built on a Mercedes-Benz chassis with an 8×4 drive configuration, this vehicle offers stability and reliability, ensuring it can navigate various terrains under full load conditions.
5. Durable PP Composite Tank: The tank is constructed from polypropylene (PP) composite material, which is highly resistant to corrosion, lightweight, and durable, extending the truck’s operational life in demanding firefighting environments.
SPECIFICATION
| No. | Main Items | Technical Parameters |
| 1.1 | Model | CSCWTFT060 |
| 1.2 | Overall Dimensions | 12,700×2,500×3,950mm |
| 1.3 | Total Weight | 42,600kg with Full Load |
| 1.4 | Number of the Crew | 1+1 (Including Driver) |
| 1.5 | Max. Speed | 90km/h |
| 1.6 | Capacity | 6,000 Liters of Water and 2,000 Liters of Foam. |
| 1.7 | Fire Pump Flow Rate | 170L/[email protected] |
| 1.8 | Fire Monitor on Boom | 80L/s Flow Rate. 70m shoot range. |
| 1.9 | Max. Working Height | 60.5 Meters |
| No. | Main Items | Technical Parameters |
| 1 | Aluminum Compartment | |
| 1.1 | Material | High-strength aluminum alloy profiles (Never Rust) |
| 1.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear. |
| 2 | Aluminum Roller Shutter Door | |
| 2.1 | Material | Aluminum alloy profiles with anodized surface |
| 2.2 | Structure | With a rain-proof groove on the top, a lever-type bar, lock handle, pull strap, 2-point fixed seat, LED light, and sensors. |
| 3 | Foot Pedals | |
| 3.1 | Material | High-quality aluminum alloy |
| 3.2 | Structure | 50cm width, bears more than 300kg, anti-slip design, with double lock function. Mounted on both sides of the compartment. |
1. Fire Pump
- Rated Flow Rate: 170L/s@10bar
- Vacuum Pump: Electric vacuum pump
- Priming Manner: Automatic
- Suction Height: 7 meters
- Priming Time: ≤80 seconds
- Location: Rear-mounted
2. Water/Foam Monitor on Boom
- Flow Rate: 80L/s
- Shoot Range: 70 meters
- Location: On the top of the boom
- Control Manner: Remote control
- Horizontal Rotation Angle: 0°~340°
- Pitch Rotation Angle: -22°~75°
3. Liquid Tank
- Capacity: Water 6,000 Liters and Foam 2,000 Liters
- Material: PP composite material and Never Rust
- Structure: 2 Tank Manholes; 1 Overflow Device/Pressure Relief Device; 2 Liquid Level Indicators; 1 Foam tank Drain Outlets with Valves; 1 Water tank Drain Outlets with Valves.
