BRIEF
The Mercedes-Benz 16,000L water foam fire engine, produced by CSCTRUCK Fire Rescue Truck, is a high-performance firefighting vehicle designed to meet the rigorous demands of modern fire and rescue operations. Built on a robust Mercedes-Benz chassis with a 6×4 drive configuration, this fire engine combines reliability, mobility, and operational efficiency, making it suitable for urban, industrial, and large-scale emergency scenarios. Powered by a 330kW engine, the truck can achieve a maximum driving speed of 90 km/h, ensuring rapid response times even in challenging environments.
Equipped with a 16,000-liter firefighting capacity, the tanker fire truck carries 10,000 liters of water and 6,000 liters of foam, allowing it to tackle a wide range of fire types, including chemical, flammable liquid, and structural fires. The fire engine features a high-capacity water pump capable of delivering 100 liters per second at 10 bar, with a suction height of up to 7 meters, providing strong and consistent water pressure even in areas with limited water supply. Its fire monitor supports a flow rate of 80 liters per second at 10 bar and a water shooting range of 85 meters, while the foam stream reaches up to 80 meters, making it highly effective in reaching distant fire sources.
The monitor offers a horizontal rotation range of 0° to 340°, providing firefighters with flexibility and precision in controlling the direction of the water or foam stream. This ensures safe operation from a distance while maintaining effective suppression coverage. The Mercedes-Benz 16,000L water foam fire engine combines advanced engineering, high capacity, and superior maneuverability, making it an essential asset for fire departments that require dependable performance and versatility in managing diverse fire emergencies efficiently. Its combination of power, capacity, and precision makes it a benchmark in modern fire suppression vehicles.
FEATURES
- High-Capacity Dual Tank System:
Equipped with a 10,000-liter water tank and a 6,000-liter foam tank, this fire engine ensures extended firefighting capability, suitable for both water-based and foam-based firefighting operations in industrial and municipal settings. - Powerful Mercedes-Benz Chassis and Engine:
Built on a reliable Mercedes-Benz 6×4 chassis with a 330 kW engine, it delivers strong power, high torque, and stability under full load, ensuring excellent performance and durability during emergency responses. - Efficient High-Performance Pump System:
The onboard fire pump provides a flow rate of 100 L/s at 10 bar, with a suction height of up to 7 meters, allowing rapid water intake from natural or artificial sources to maintain continuous firefighting operations. - Advanced Fire Monitor Capability:
The roof-mounted fire monitor achieves a flow rate of 80 L/s at 10 bar, with impressive shooting ranges of ≥85 meters for water and ≥80 meters for foam, combined with 0°–340° horizontal rotation for wide-area coverage. - High-Speed Mobility and Operational Efficiency:
With a maximum driving speed of 90 km/h, the Mercedes-Benz fire engine offers quick deployment to emergency sites, while its ergonomic design and robust structure support reliable, efficient, and long-term firefighting performance.
SPECIFICATION
No. |
Main Items |
Technical Parameters |
|---|---|---|
| 1 | Mercedes-Benz 16000L Water Foam Fire Engine | With Water Pump and Monitor |
| 1.1 | Model | CSCWFFE016 |
| 1.2 | Overall Dimensions(LxWxH) | 10,370 × 2,500 × 3,790mm |
| 1.3 | Total Weight | 31,150 kgs (full load) |
| 1.4 | Crew | 2 (including driver) |
| 1.5 | Max. Speed | 90 km/h |
| 1.6 | Capacity | 10,000L Water & 6,000L Foam, PP composite material, never rusts |
| 1.7 | Fire Pump Flow Rate | 100 L/s @ 1.0 Mpa |
| 1.8 | Fire Monitor | 80L/s flow rate, 85m shoot distance |
| 1.9 | Paint | Red Color, U.S. PPG brand |
| 2 | Superstructure | CSCWFFE016 |
| 2.1 | Compartment Material | High-strength aluminum alloy profiles |
| 2.2 | Structure | All-aluminum alloy welded frame; bonded aluminum alloy plates for outer skin |
| 2.3 | Roof Guard | Aluminum alloy; strobe warning lights and exterior lights outside; LED roof lights inside |
| 2.4 | Ladder Frame | Multifunctional ladder frame on top |
| 2.5 | Rear Ladder | Aluminum alloy safety ladder to the roof on the right rear |
| 2.6 | Electrical System – Warning Lights | Long row warning lights on top; control devices in the cab |
| 2.7 | Electrical System – Equipment Box Lights | LED strips on both sides; linked with the rolling door |
| 2.8 | Electrical System – Strobe Lights | Strobe lights on the upper part |
| 2.9 | Electrical System – Exterior Lighting | LED lights on the upper part of the compartment |
| 2.10 | Electrical System – Roof Lighting | LED lights inside the top of the carriage |
| 2.11 | Electrical System – Side Indicator | Built-in yellow indicator lights on pedals |
| 3 | Water Pump / Fire Monitor / Liquid Tank | For Heavy Duty Fire Truck |
| 3.1 | Water Pump Brand | Optional |
| 3.2 | Water Pump Model | Optional |
| 3.3 | Water Pump Flow Rate | 100 L/s @ 1.0 Mpa |
| 3.4 | Vacuum Pump | Electric vacuum pump |
| 3.5 | Priming Manner | Automatic |
| 3.6 | Suction Height | 7 m |
| 3.7 | Priming Time | ≤ 60 s |
| 3.8 | Location | Rear-mounted |
| 3.9 | Water and Foam Monitor Brand | Optional |
| 3.10 | Monitor Model | Optional |
| 3.11 | Monitor Flow Rate | 80L/[email protected] |
| 3.12 | Shoot Range | Water ≥ 85 m, Foam ≥ 80 m |
| 3.13 | Monitor Location | Top of tank |
| 3.14 | Control Type | Remote Control |
| 3.15 | Horizontal Rotation Angle | 0°~340° |
| 3.16 | Pitch Rotation Angle | -15°~60° |
| 3.17 | Water & Foam Tank Capacity | Water 10,000L, Foam 6,000L |
| 3.18 | Tank Material | PP composite material never rusts |
| 3.19 | Tank Structure | Two manholes; two overflow/pressure relief devices; two liquid level indicators; one foam tank drain outlet with valve; one water tank drain outlet with valve. |
