BRIEF
FEATURES
Fire Pump:
Brand: Ziegler Water Pump.
International Standard: NFPA 1901, ISO 9001:2008, DIN EN Standard.
Type: Centrifugal fire pump FPN 10-6000.
The low-pressure pump conforms with DIN 14420 respectively EN 1028.
Output: Nominal output: 6,000 L/min at 10 bars.
Materials: Castings (impeller, pump cover, pump housing) are made from sea-water resistant light metal alloy. The pump shaft and split water rings are made from corrosion-resistant steel.
Priming unit: Fully automatic priming system ZIEGLER – TROKOMAT – PLUS.
Advantages: The centrifugal fire pump and its components are very solid and extremely reliable. Insensitive against dirt and water. Insensitive against frost since centrifugal fire pump can be quickly and completely drained.
Extinguishing system:
Pipe system
a) Water suction ports: Two 6-inch water suction ports with manually controlled valves are installed at the end of the fire vehicle. A special rubber elastic connection device is offered at the appropriate piping position.
b) Water outlet ports: There are two 2.5-inch normal pressure outlets on both sides of the vehicle body, a tank water injection pipeline from the pump to the tank, which is mounted with a 2.5” ball valve, and one fire monitor pipeline.
c) Water filling ports: One water filling port with a manual control valve is installed on the left and right sides of the pump room.
c) Residual water drainage pipeline: At the lowest and easily accessible location is mounted with residual water drainage cock, which can drain away residual water quickly when required.
d) Cooling water pipeline: PTO is equipped with a forced cooling water pipeline connected to the water inlet and outlet pipeline of the pump, mounted with a valve, which can drain away residual water through a vacuum process.
Pump drive system:
Power take-off (PTO) System:
Installation method: Sandwich type
Cooling mode: Circulating water cooling
Transmission shaft: High-balance precision transmission shaft, using a special middle support connection.
Roof fire monitor:
Installation site: at the roof of the fire vehicle
Horizontal rotating angle: 0°~360°
Vertical rotating angle: -10°~ 60°
Pressure/flow rate: 1.0Mpa/ max. flow rate: 4800L/M
Water range: Approx.75m (1.0Mpa)
Operation type: Manual
Water tank:
Water tank capacity: 10,000Liters
Material: High-quality stainless steel 304 tank. Polypropylene (PP) tank is optional.
Equipment: One manhole(450mm)
One overflow device
One liquid-level sensor
Drain with valve
Tank construction：
Sealing plates are both at the front and back sides, and the wall plates are at both sides of the tank vertical and horizontal oscillation shield plates are equipped with trapezoidal steel, which can increase the strength, of the water tank through strict water leakage test and strength reliability test.
Sub-frame:
Structure characteristics: The tank and sub-frame are connected by an elastic connecting seat with torque reduction performance, which not only increases the flexibility of the connection between the frame and tank body and prevents the deformation and fracture from the upper structure, but also increases the strength of the storage compartment of upper body and gives the chassis a great performance. Meanwhile, the standardized subframe comes to realize the flexible assembly of the upper body.
Equipment box and pump room:
Material: The equipment box, pump room, and inner frame are made of high-strength aluminum alloy profiles and interior trim panels are made of oxide
aluminum plates.
Structure: The framework is the welded structure of all aluminum alloy frames where equipment boxes are in the front and pump room is at the back. The outer skin is aluminum alloy plate bonding technology. The equipment frame adopts the aluminum alloy profile overlapping structure, which can flexibly lay out the equipment box structure according to the customer’s requirements to maximize space utilization. In the equipment box, the new type of sliding bracket, drawer, or high-strength plastic storage boxes and other storage structures can be selected to make full use of limited space inside the compartment. Interior trim panels and base plates are made of smooth brushed aluminum alloy materials.
- Storage compartments for equipment with suitable fixing facilities with sliding drawers and fixed shelves to safely and easily retain equipment.
- Compartments are fixed light alloy anodized roller shutter doors.
Pump room:
- The pump compartment is located at the rear of the vehicle.
- It is closed by an aluminum roller shutter or a steel plate at the rear.
Roller shutter doors:
- Anodized roof-roll type shutters with strips as well as lift bars
- Each shutter is provided with automatic illumination when the Shutter is opened.
Roof deck:
- The roof deck will be used to store suction hoses and an extension ladder and will be covered by aluminum chequered plates to make movement easier.
Roof access ladder:
- A light alloy roof access ladder will be provided at the rear of the fire vehicle.
Pedal plate
Rear roof access ladder
Location: Under the roller shutter doors
Material: High-strength plate aluminum alloy profile, with anti-skid function
Structure: Pedal plates are the overall drawn structure of aluminum alloy plates. The strength is higher than the skeleton welding structure. Pedal plates can carry more than 150kg. The pedal surface is an anti-skid design with a spring locking function to prevent the pedal plate from automatically turning over during driving.
Hose reel
To have two 60-meter 20mm diameter semi-rigid hose reels (each with a pistol grip jet/spray/fog control branch) located on each side of the rear compartment. The hose reel to have manual winding with a hand wheel system.
Towing winch system:
Hose reel photos
Front hydraulic winch with a hook, 14mm wire rope with a hook (32M long) has a manual operation option. The rear of the chassis should be fitted with two towing eyes, should be recessed, and not protrude beyond the bodywork. They must be formed to allow a 45-side pull without damage to panels.
Telescopic Light Mast:
Two(2)electric flood LED light towers with 4 sets of 200W each of rooftop lights. The light tower shall extend telescopically to a maximum of three (3) meters.
Towers shall incorporate an “Auto stow” function and shall be operated by a hand-wired pistol grip remote that is supplied with the towers.
The mast shall be able to rotate at 360 degrees and be able to incline the lights vertically at an angle of 180 degrees.
Electric system:
The alarm lamp, which is located at the top of the cab, is a long bar of lights, equipped with a 100W alarm control system. Three flashing lights are installed on both sides of the top of a fire truck. 2 LED side lamps are equipped on both sides of the top of the truck. Safety sign lights are equipped below of truck. Viewing lights and width lights are equipped at the both front and rear sides of the truck. One 24V, 35W LED searching light is mounted at the rear of the truck roof. Electric circuits are designed independently.
Fire-fighting control panel:
Location: In the rear pump compartment
Structure:
- According to the vehicle configuration, various types of control modules can be selected, and all fire-fighting components are electrically controlled, using PLC intelligent control; All buttons, switches, and indicators on the control panel are marked in English languages. Pipeline layout and brief operation instructions are set at the prominent position of the panel. The panel is waterproof and dustproof design mode, and the protection grade can reach IP56.
Electrical Package:
In addition to the standard electric system of the vehicle by International and Local Road Regulations, the following units are mounted.
Illumination: The lighting system for the interior of the cabin is the original chassis manufacturer. The pump Compartment and storage lockers are illuminated for night operation and automatically switched on when roller shutters are opened.
Warning lights:
A long bar of lights on the driver’s cabin roof
One complete PA system will be installed with controls in the cabin.
Control Boards:
The following controls/lights are located inside the cabin, near the driver’s or co-driver seat flash lights warning light. A long bar of lights’ switch and light.
Painting
Red paint: Cabin, equipment box, pump room (except shutter)
The front bumper will be painted white or red.
(The color of the whole fire vehicle can also be customized.)
Technical requirements:
All the operating switch has the nameplate & signs of precautions11 Fire vehicle performance is by international standards.
All instruments and controls are stamped or engraved in the English language the brackets or drawers in the equipment box are designed according to the principle of ergonomics, to obtain equipment more easily.
Documentation:
We will provide a complete and comprehensive set of documentation in English language:
- Complete fire vehicle operation and maintenance manual.
- Chassis operation and maintenance manual.
- Spare parts manuals for fire vehicles, fire pumps, and all connected equipment.
Inspection & Training:
- Factory Acceptance Test will be conducted upon 100% progress, witnessed by customers.
- Training for operation and maintenance will be given by factory engineers.
Additional Accessories:
| No. | Name | Qty. |
| 1 | Water hose (dia.65mmx20m) | 12 |
| 2 | Suction hose (dia.150mmx2m) | 4 |
| 3 | Water filter | 1 |
| 4 | Water separator | 1 |
| 5 | Water collector | 1 |
| 6 | Suction hose wrench | 2 |
| 7 | Ground fire hydrant wrench | 1 |
| 8 | Underground fire hydrant wrench | 1 |
| 9 | Water gun | 2 |
| 10 | Reducer of suction hose | 1 |
| 11 | Reducer | 2 |
| 12 | Heterotype coupling | 2 |
| 13 | Hose hook | 2 |
| 14 | Water hose bandage | 4 |
| 15 | Water hose bridge | 1 |
| 16 | Sharp axe | 1 |
| 17 | Multifunctional shovel | 1 |
| 18 | Dry powder fire extinguisher | 1 |
| 19 | Chassis tool | 1 |
SPECIFICATION
1.0 MANDATORY EQUIPMENT
The Vehicle MUST be supplied with ALL the equipment stated below and MUST be well stored in their respective lockers with others mounted on the vehicle.
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 1. | Fire helmets with reflective visor
|
8 | The helmet has a reflective face shield and eye screen, suitable chain straps with an automatic buckle. It Should have the following features:
§ The helmet shell should be made of high-temperature-resistant material. § Be bright yellow. § Inner lining to be made of fire/flame-resistant material and hood for each helmet. § Have an inner adjustment system ratchet to allow quick adjustment and optimal holding of the helmet onto the wearer’s head. § Have provision to receive respiratory masks with mask adapters or with mask bands. § Preferably the inner linings, the chin straps, and the buckles should be made of washable material. § To have a reflective Fire Service crown (Six (6) pointed stars with the lettering “PFS” inscribed in the middle) appropriately placed. § Each helmet is to be supplied with a detachable and rechargeable LED search spotlight. § Should be fully compliant with EN 443 and EN 166. § |
Helmet material: PEI（Polyetherimide） Shawl material: Aluminum foil and aramid
Color: Yellow/Red
Size:54-64 cm Helmet Max Temp:300℃ Lens heat resistance:260℃ Max Impact force:5000N Electrical insulation:0.9 A Goggles type: Full type Mask Vision:160°
The inner lining is to be made of fire/flame-resistant material and a hood for each helmet. Have provision to receive respiratory masks with mask adapters or with Preferably the inner linings, the chin straps, and the buckles made of washable material. To have a reflective Fire Service crown (Six (6) pointed star with the lettering “PFS” inscribed in the middle) appropriately placed. Each helmet is to be supplied with a detachable and rechargeable LED search spotlight. |
| No. | Item Description | Quantity to be
supplied |
Remarks | OFFER |
| 2. | Firefighting gloves (Pairs)
|
8 | These should have the following minimum features:
§ Five fingers with “swing thumb” construction § Suitable leather tanned for lasting softness, comfort, fire resistance, and durability. § Liner/moisture barrier system § Knit wrist, made of suitable fire/flameproof material, attached to the glove body. § Should be of different sizes (3 medium, 8 large, and 4 extra-large). |
Layer:4 layers TPP:≥35cal/cm2
Outer sell::Nomex/K-ever blended fabric Moisture barrier: Nomex substrate with PTFE membrane
Thermal lining: Nomex aramid Comfortable layer: Nomex aramid/viscose woven blended fabric Color: Yellow/Navy Blue/Orange Size: One Size Fits All
Five fingers with “swing thumb” construction Suitable leather tanned for lasting softness, comfort, fire resistance, and durability. Liner/moisture barrier system |
| 3. | Classic Fire Fighting Suits (turn out Coat and bunker Pant) to be supplied each with a personal line-
3.5mm, Hi- |
8 | These should have the following minimum
features: § Should be made of suitable flame/fireproof material (preferably Normex or similar) as approved by NFPA. § Both the coat and the pants/trousers have moisture, thermal barrier, and outer protective shell. High visibility 3M brand Scotchlite reflective trim to be appropriately attached as per NFPA standards. |
flame-retardant PTFE waterproof and moisture permeable (120g/m ²)。 Insulation: 100% aramid. Comfort layer: 80% intermediate aramid, 20% intermediate aramid. *Front closed by heavy FR |
| No. | Item Description | Quantity to be
supplied |
Remarks | OFFER |
| visibility kevlar core cord with karabiner 6 meters in length. | § 32” Coat length
§ The top back part of the jacket bears the words “KPA-PORT FIRE SERVICES”. The lettering is to be of FIREBRAND style in white 3M diamond grade reflective material and will be mounted upon yellow 3M Diamond grade reflective material. § The coat is to have a 3.5”x 9”x 2” radio pocket with FR hook and loop closure on the left chest. § The collar should be appropriately sewn to keep water out and provide a secure thermal seal. § There should be appropriate reinforcement of the coat at the elbow and shoulders while the pants to be reinforced at the knee, and cuffs. § The coat sleeves should have wristlets with an eyelet for the thumb. § Both the coat and pants have pockets to be suitably made to ensure the mobility of the user. § Color: Navy Blue outer shell with lime yellow and silver 3M brand Scotchlite reflective material in NFPA trim pattern. |
zipper and FR Velcro
*One radio pocket on the left chest, closed by Velcro, size: 8 “H x 3” W x 2 “D *3-inch wide 3M Scotchlite FR yellow silver reflective tape *FR drain mesh at waist hem and bottom pocket
Knit cuffs with thumbs and rings *H-type quick buckle strap *Thickened sewing process for elbows and knees *3D pocket design with drainage holes reserved
The top back part of the jacket bears the words “KPA-PORT FIRE SERVICES”. |
||

|
| No. | Item Description | Quantity to be
supplied |
Remarks | OFFER |
| 4. | Breathing Apparatus (BA) sets with a capacity of 6 liters at 300 bars. (Open Circuit)
|
8 | Each cylinder should be constructed with Aluminum Liner with Carbon Fiber Composite Wrap and Epoxy overcoat, frame, and face mask.
§ The cylinder is to be designed for optimal ergonomics factoring light weight (AirMaXX, DragerMan PSS 90 series or similar type) for back mounting. § Should be of positive pressure type with lung-governed demand valve. § The carrying/plate frame has a hip belt with elastic fixations, easily adjustable straps & shoulder pads with length adjustment provisions, freely swiveling, and a luminescent pressure gauge. § It should have a rechargeable battery-powered digital warning and monitoring device for the user and supplied with three (3) chargers and a dozen of battery replacements. § Each set should allow cylinder support for one or two compressed air cylinders. § A Personal Alert Safety System (PASS) device should be incorporated for use with each of the BA sets which should also include a Pack Tracker Locator System complete with a Handheld receiver. The Pack Tracker Locator System should be compatible with the frame of the BA set. § Six (6) BA sets 4 to be mounted in the crew cabin, two (2) in the driver’s cabin, and the other seven (7) in the equipment compartments. |
SCBA set with 6.8L carbon fiber cylinder *1pc+kevlar material harness mask*1 pc + lung demand valve *1pc+backplate with belt and shoulder pad*1pc+ pressure regulator assembly with pressure gauge and whistle*1pc+PASS
*1pc+carrying case *1pc Each cylinder is constructed with Aluminum Liner with Carbon Fiber Composite Wrap and Epoxy overcoat, frame, and face mask. The cylinder to be designed for optimal ergonomics factoring in light weight. It is of positive pressure type with lung lung-governed demand valve. The carrying/plate frame has a hip belt with elastic fixations, easily adjustable straps & shoulder pads with length adjustment provisions, freely swiveling, and a luminescent pressure gauge. Each set should allow cylinder support for one compressed air cylinder. A Personal Alert Safety System (PASS) device should be incorporated for use with each of the BA sets |
| No. | Item Description | Quantity to be
supplied |
Remarks | OFFER |
| 5. | Closed Circuit Breathing Apparatus sets with a capacity of 420L 4-hour use, at an O2 constant dosage of 1.9 LPM and Breathing bag volume of 5.5L
|
2 | Includes:
§ Sentinel electronic alarm, mask, lightweight carbon cylinder and valve, and black carrying case. § Spring-loaded breathing bag generates positive pressure throughout the breathing circuit; and protects the user from the potential increase of toxic, ambient gases in the event of leaks around the mask seal. § Ergonomically shaped frame with padded harness and waist belt for comfort § Lid is reinforced for durability. § Strengthening rings on breathing hoses provide constant support, and bayonet rings for easier assembly. § Flow-sensitive CO2 absorber, low breathing resistance, and integrated cooling system reduce stress to the user. § Lightweight, carbon fiber supply cylinder holds 420L of O2 and features both minimum and manual bypass valves. § Uses refillable regeneration cartridges § Sentinel electronic alarm warns user with audible and visual alarms when residual or low pressure is reached |
Includes:
§Sentinel electronic alarm, mask, lightweight carbon cylinder and valve, and yellow carrying case.
§Spring-loaded breathing bag generates positive pressure throughout the breathing circuit; and protects the user from the potential increase of toxic, ambient gases in the event of leaks around the mask seal.
§Ergonomically shaped frame with padded harness and waist belt for comfort §Lid is reinforced for durability.
§Strengthening rings on breathing hoses provide constant support, and bayonet rings for easier assembly.
§Flow-sensitive CO2 absorber, low breathing resistance, and integrated cooling system reduce stress to the user.
§Lightweight, carbon fiber supply cylinder holds 480L of O2 and features both minimum and manual bypass valves. Uses refillable regeneration cartridges Sentinel electronic alarm warns user with audible and visual alarms when residual or low pressure is reached. |
5
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 6. | Ladders are to be stowed on the rooftop of the appliance.
|
3 | § A hydraulic system has to be provided to allow for slipping and loading of ladders to be carried out entirely from ground level.
§ All ladders are to be manufactured in aluminum using the lightweight riveted truss method of construction. The set of ladders to have the following specifications: § One extension ladder of 15 meters when fully extended to be mounted at the rear central part of the appliance. The ladder should not have more than three extensions. § A second set of extension ladders of 9 meters (30ft), one triple extension ladder of 5.4 meters (18ft) to be placed on either side of the main ladder, and one roof ladder. § The roof ladder has a folding hook manufactured from a stainless steel tube with truss side members for strength and lightness.
6 |
All ladders are to be manufactured in aluminum using the lightweight riveted truss method of construction.
The set of ladders to have the following specifications:
One extension ladder of 15 meters when fully extended to be mounted at the rear central part of the appliance. The ladder should not have more than three extensions.
Made of high-strength high-quality aluminum alloy, the limiting device of the ladder is safe and reliable in the process of expansion and condensation. It can be used to rescue people and put out fires during firefighting and disaster relief. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 7. | CMC Rescue Confined Space Rescue Team Kit
This kit has the minimum equipment for the entrant, attendant, stand-by rescuer, and mainline operator and is a layer to set up systems for vertical entry into |
1 | Kit Contents:
§ Fire-Rescue Harness (2) § Lifesaver Victim Chest Harness § Shasta Gear Bag § #2 Rope Bag (3) § 7/16″ Static-Pro Lifeline – 200′ § 1/2″ Static-Pro Lifeline – 200′ § 1″ Web – 100′ (5×20′) § ProSeries Pulley (5) § Access Pulley § Born Entry-Ease § ProTech Oval § Long Prusik Loop (3) § Sked Basic Rescue System § Load Release Strap § Edge Pad – XL (2) § FastLink Anchor Strap § Helmet (5) § Confined Space Entry and Rescue Manual § Sked-Evac Tripod & Bag |
Kit Contents:
§ Fire-Rescue Harness (2) § Lifesaver Victim Chest Harness § Shasta Gear Bag § #2 Rope Bag (3) § 7/16″ Static-Pro Lifeline – 200′ § 1/2″ Static-Pro Lifeline – 200′ § 1″ Web – 100′ (5×20′) § ProSeries Pulley (5) § Access Pulley § Born Entry-Ease § ProTech Oval § Long Prusik Loop (3) § Sked Basic Rescue System § Load Release Strap § Edge Pad – XL (2) § FastLink Anchor Strap § Helmet (5) § Confined Space Entry and Rescue Manual § Sked-Evac Tripod & Bag § Lifesaver Victim Harness § Lassen Duffel Bag, Med (2) § Rope & Equipment Bag, Med § 1/2″ Static-Pro Lifeline – 200′ § 1/2″ Static-Pro Lifeline – 200′ § 1″ Web – 48′ (4×12′) § Anchor Plate § Access Double Pulley § ProSeries Screw-Lock (16) § ProSeries Manual-Lock (2) § Short Prusik Loop (4) § Mill Full Body Splint § Riggers Gloves (5 pairs) |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| a confined space for both rescue and patient transport. For a complete confined space solution, add or use your communication, gas monitor, and ventilation equipment. | § Lifesaver Victim Harness
§ Lassen Duffel Bag, Med (2) § Rope & Equipment Bag, Med § 1/2″ Static-Pro Lifeline – 200′ § 1/2″ Static-Pro Lifeline – 200′ § 1″ Web – 48′ (4×12′) § Anchor Plate § Access Double Pulley § ProSeries Screw-Lock (16) § ProSeries Manual-Lock (2) § Short Prusik Loop (4) § Mill Full Body Splint § Riggers Gloves (5 pairs) § Alta Knee Pad (5 pairs) § Anchor Strap Sleeve § Headlamp (2) § Confined Space Entry & Rescue Field Guide |
§ Alta Knee Pad (5 pairs)
§ Anchor Strap Sleeve § Headlamp (2) |
||
| 8. | 24 Meter fire Hoses
drained type (BS 6391 |
10 | The hoses to have 21/2 inches instantaneous connections:
§ 6 hoses to have an internal diameter of 75mm, 480g/m excluding coupling. |
Please note that all the fire hoses to you will be 65mm (BS type) |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| type 3)
|
§ 14 hoses to have an internal diameter of 38mm, 220g/m excluding coupling.
§ Couplings to be made of gunmetal or light alloy. |
– We don’t have 75mm and 38mm fire hoses. | ||
| 9. | Pistol Grip Control branch pipes can give spray/jet/fog
|
6 | To be compatible with item 8
§ Must give a flow rate of 1050LPM @ 7 Bars § Must have a maximum pressure withholding capacity of 16 Bars. |
To be compatible with item 8 give a flow rate of 1000LPM @ 7 Bars
has a maximum pressure withholding capacity of 16 Bars. |
| 10. | jet/spray/shut-off with a water curtain. | 2 | § To be compatible with Item number 8.
§ Made of Aluminum alloy |
To be compatible with Item number 8.
Made of Aluminum alloy Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
|
|
||||
| 11. | 2 Meter hard Suction Hoses
|
4 | To be placed on the rooftop
§ Must have a 4-inch threaded coupling. |
To be placed on the rooftop top It will be compatible with
a suction inlet port in a fire vehicle. Comply |
| 12. | Controlled diffuser branch pipe
|
4 | § To be compatible with item number 8
§ Able to discharge at 750LPM. § Made of copper alloy. |
To be compatible with item number 8
Able to discharge at 750LPM. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 13. | Suction strainers with float chains
|
2 | § Must have a non-return valve.
§ Material of construction: Aluminum Alloy |
Must have a non-return valve. |
| 14. | Gooseneck
|
4 | § To be compatible with item 8 above.
§ To have male instantaneous coupling § Made of copper alloy |
To be compatible with item 8 above.
To have male instantaneous coupling |
| 15. | Portable Ground monitor (Dual inlet) | 4 | § All Connections must be compatible with item number 8.
§ Durable, Lightweight Aluminum Construction § Capable of flows up to 1250 GPM (4732 Lpm) § Compact folding base can be stored in any truck compartment or pre- |
The monitor is especially suitable for oil fields, oil depots, airports,
docks, large buildings, petrochemical tank farms, old urban areas and underground shopping malls that are difficult for fire engines to enter, and other toxic, harmful, flammable and explosive high-risk places. Flow rate:4800 LPM@ 8 Bar Max. pressure: 10 Bar |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
connected in the hose bed.
§ Legs lock in folded and deployed positions. § Safety stop at 30 degrees above horizontal § Stainless steel ball bearings at all rotation joints § Liquid-filled pressure gauge. § Grease fittings for lubrication § Red paint finish § Dual application as a portable monitor or add the top flange for deck mount use. Ø High Volume: § 800 gpm (3028 lpm) in portable mode with double inlet § 1250 gpm(4732 lpm)in deck mount |
Gun body: stainless steel, gun head, and base: aluminum alloy Vertical: +30 °~+85 ° Horizontal: +60 °
Product features:
Two-hand wheel operation, worm gear, and worm drive, with self-locking function. The horizontal stroke is 120 ° and adjustable, and the vertical stroke is 30 °- 85 “and adjustable. To maintain a constant injection pressure within the range of 1200LPM~4800LPM, ensuring effective injection Distance. |
||
| 16. | Turbo Pump | 3 | § It is a water turbine-driven centrifugal Pump.
§ Turbine inlet and outlet-2 ½” male and female Instantaneous. |
It is a water turbine-driven centrifugal Pump. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
§ Pump Outlet -2 ½” female Instantaneous as per BS33.
§ Strainer Brass. § Feed Water Flow- 850LPM @7 bars. § Floodwater Flow- 150LPM @ 2 Bars. |
|||
| 17. | Variable ejector pump
|
2 | § The adjustability features make it possible to vary the angle of throw of water for effective operation.
§ Material of construction: Aluminum Alloy § Working Pressure: Max- 10 bar, Min- 5 bar § Suction Inlet: 2½” male Instantaneous § Suction Outlet: 2 ½” Female Instantaneous. |
The adjustability features make it possible to vary the angle of throw of water for effective operation.
Material of construction: Aluminum Alloy |
| 18. | Nobel Ejector Pump | 2 |  |
It is since there is no requirement, and the supplier also doesn’t know about this one. So finally they recommend that is the same as item 17. Both are called ejector pumps. |
| 19. | Suction | 6 | Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| wrenches (pairs)
|
||||
| 20. | FOAM MAKING
EQUIPMENT Inline Inductors Ø IND 100 (450 lpm) Ø IND 50 (225 lpm) Ø IND 100 (450) Marine version |
4 4 4 |
§ Must be compatible with item number 8
|
FOAM MAKING EQUIPMENT
Inline Inductors IND 100 (450 lpm) IND 50 (225 lpm) IND 100 (450) Marine version |
| 21. | Foam Making Branches: | § Connection to be compatible with item No. 8 | Foam Making Branches:
low expansion non self- |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| low expansion non-self-inducing.
-(LX50) (225lpm) -(LX100) (440lpm) -low expansion self-inducing (225lpm) -medium expansion foam (MX100) (450lpm |
4 4 4
4 |
|
inducing.
-(LX50) (225lpm) -(LX100) (440lpm) -low expansion self- inducing (225lpm) -medium expansion foam (MX100) (450lpm) |
|
| 22. | High-expansion Foam generator complete with
7.5m duct. |
2 | § Connection to be compatible with item No. 8 | High expansion Foam generator with 7.5m fire hose. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
||||
| 23. | Portable oxyacetylene cutter | 2 |  |
Portable oxyacetylene cutter |
| 24. | Fire Blankets (Heavy-duty) | 4 |
|
§ 2×2 Meters |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 25. | Hose rolling winder
|
4 | § Must have guide plates to ensure even rolling.
§ Must be collapsible. § To be supplied with an operation manual |
have guide plates to ensure even rolling.
§ Must be collapsible. To be supplied with operation manual |
| 26. | Hose reel adaptors
|
2 | § 2 ½ to 1 ½ inches | § 2 ½ to 1 ½ inches |
| 27. | 4-way Collecting head | 4 | § 4” female round thread
§ 2 ½ Instantaneous male coupling |
It will be compatible with fire vehicles. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
||||
| 28. | Dividing breaching | 4 |  |
Comply |
| 29. | 1-way BL standpipe/ Key and Bar (for each standpipe) | 3 | § 2 ½ Instantaneous female coupling
|
§ 2 ½ Instantaneous female coupling |
| 30. | Hydrant adapter | 5 |  |
Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 31. | 60-meter 8-plait polyester Guideline | 3 | Comply | |
| 32. | Rescue line 67meters 3 strands of polyester | 2 | Comply | |
| 33. | Collecting breaching | 4 |  |
Comply |
| 34. | Paraguard rescue stretcher with lifting mechanism | 2 |
|
Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 35. | Handheld Thermal imaging camera (with life detector) | 1 |
|
★ 1. Temperature measurement range: no less than – 40 ℃~1200 ℃ or better; Temperature measurement accuracy: ≤
± 2 ℃; 2. Display screen: ≥ 3.5 inch LCD; ★ 3 It has the function of working indicator light and automatic adjustment of screen brightness; It has infrared mode and visible mode, which can be switched quickly; ★ 4 It has the compass orientation function and laser indication function, and the laser pointer can indicate the high-temperature hazardous area; 5. Cold and hot spot tracking function: it has a full-screen automatic high and minimum temperature pointer search mode in the fire scene, and simultaneously displays the maximum and minimum temperatures, which is convenient for rapid positioning and cold and hot spot tracking in the fire scene; 6. Resolution of infrared detector: 384 * 288; ★ 7. Noise equivalent temperature difference (NETD): ≤ 30mK (when the ambient temperature is 30 ℃± 5 ℃); 8. Wavelength range: 8-14 μ m； 9. Sampling frame rate: ≥ 50 frames/s; ★ 10. Working time in high temperature environment: ≥ 30min at 80 ℃, ≥ 15min at 150 ℃, ≥ 10min at 260 ℃; 11. ≥ 8 kinds of palettes can be |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| selected: fire scene, personnel search and rescue, missing persons, fire mode, etc;
★ 12. Protection grade: IP67; 2 m falling to the hard ground will not affect the use; 13. Working temperature: – 20 ℃~+60 ℃; Storage temperature: – 40 ℃~+70 ℃; 14. Battery life: ≥ 4h/battery, equipped with 2 batteries |
||||
| 36. | Portable rechargeable LED spotlight
|
4 | § Integral D-rings allow attachment of the included shoulder strap.
§ High-impact ABS thermoplastic housing and weatherproof construction; elastomer impact bumper; cushioned-grip handle § Optimum peripheral illumination for scene lighting; 90° swivel neck allows you to aim the beam where you need it for task lighting. § Not less than 3,600 lumens, 31,000 candela, 352m beam distance § Runtime of not less than 4 hours § Intrinsically safe |
Integral D-rings allow attachment of the included shoulder strap.
High-impact ABS thermoplastic housing and weatherproof construction; impact bumper; cushioned-grip handle Optimum peripheral illumination for scene lighting; 90° swivel neck allows you to aim the beam where you need it for task lighting. Not less than 2100 lumens, 493m beam distance Runtime of not less than 4 hours Intrinsically safe |
| 37. | Portable siren | 2 | § Rated voltage: DC 12/24V. | Product functions: public address, whistle, recording, alarm, TF card, |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
|
§ Compatible with cigarette lighter plug
§ Rated current: – Sound pressure level: >/= 120dB § Resonance frequency: 3000 +/- 500Hz § 1 x Speaker buzzer |
U disk, lighting, Bluetooth Product power supply: No. 5 battery or lithium battery
Maximum power: ≥ 20W Lighting power: 1.2W (LED) Recording time: ≥ 240 seconds Frequency characteristic: 300HZ- 20KHZ Product specification (LWH): 270 × one hundred and sixty-eight × 225mm Weight: 650g (including lithium battery) |
||
| 38. | Adapter junction boxes | 2 |  |
Comply |
| 39. | Generator | 1 | To be vehicle mounted and compatible with all electrically driven equipment supplied.
§ To be externally regulated § Single phase output with an external voltage regulator that senses the output voltage. § Frequency range of 50-60 Hz § AC voltage output of 240/110V |
Unit parameter Spare power: 12KW
Rated power: 10KW Frequency: 50Hz Voltage: 230V Rating/spare current: 43.4/47.8A Oil tank:20L Power factor: 1 cos board Number of phase: single phase Speed regulating agency: mechanical speed adjustment |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |

(photo just for reference) |
§ DC voltage output of 24/12V
§ Current output of not less than 51 Amperes § Rated at 12KVA. § Power output 9.6 KV § Low Maintenance and air-cooled § Gasoline powered with a tank capacity of 10L. § With an emergency STOP button To be supplied together with: § 8 x 20,000 Lumen LED Floodlights (low heat emission, Waterproof, both portable and tripod mounted, not easily damaged by fall or impact not less than 50,000 hours operational life, 5 years LED light warranty, 12/24 volt DC, 18/9 amps120/240 volt AC, 2/1 amps) § Cable reels/Sockets sufficient in number for all supplied electrical equipment. |
Stable state adjustment rate: ≤ ± 1% Engine
Model: Dajiang 2V80 Ignition method: no touch ignition Cooling method: wind and cold Number of cylinders: 2 cylinders Displacement (L): 713cc Rating speed: 3000 (R/min) The minimum speed of the air load: is 1000 (R/min) Oil consumption rate: ≤1.5 (g/kw · h) Machine oil temperature: ≤121 (℃) Motor oil pressure: 207-345 (KPA) Steady-state speed volatility: ≤0.5% Start the power: DC, 12V Lubrication method: splash lubrication Machine oil model: ST/CF4 up SG15W- 40 Daily maintenance time: 100 hours per interval Electric engine Model: Shenchi Electric Number of phase: single phase Connection method: cones connection Insulation level -level H level |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 40. | Tripods | 4 |  |
Rated load: ≤180Kg
Gathered length：1.34m Open length：2.14m Manual handle force：≤500N Length of wire rope: 30M Winch mechanical efficiency 5:1 Blocking force: 22KN Dimension: 173*39*36cm Weight: 18.5kg Safety factor: 10 With winch |
| 41. | Multipurpose fire rescue chain saw. | 1 |  |
Engine: Single bar, air-cooled, two-stroke
Fuel tank volume: 550 ml Engine displacement: 45 cubic centimeters Max. engine power: 2.4 kW Maximum engine speed under load: 11,500 rpm Max. engine idle speed: 2800 rpm Saw chain pitch: 0.325 Guide plate size: 16 Oil supply system: automatic pump with oil regulator Weight: 7 kg |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 42. | Electric drill kit
|
1 | To include;
§ 13piece set of bits for metal. § 8 pieces set of bits for masonry /wood. § 23-piece Hole Saw bit set. § To be compatible with item No. 39 |
To include;
§ 13piece set of bits for metal. § 8 pieces set of bits for masonry /wood. § 23-piece Hole Saw bit set. |
| 43. | Electric Reciprocating Saw
|
1 | § To include a set of Fire & rescue grade blades for both metal and wood
§ 850W, 23V motor § Variable blade speed control (800 – 3000 strokes/min) § Five adjustable shoe stops for depth control and even blade wear § 24mm stroke length § Max cutting capacities; wood 210mm, Aluminum 20mm & mild steel 10mm. § Includes 3 wood (L130mm) & 3 metal (L80mm) blades. § To be compatible with item No. 39 |
To include a set of Fire & rescue grade blades for both metal and wood
850W, 23V motor Variable blade speed control (0-3300 strokes/min) Five adjustable shoe stops for depth control and even blade wear 28mm stroke length Max cutting capacities; wood 250mm, Aluminum 20mm & mild steel 10mm. Includes 3 wood (L130mm) & 3 metal (L80mm) blades. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 44. | Hydraulic Lukas cutters | 2 |
|
Rated working pressure: 63 Mpa Opening distance: 128 mm Max. shearing capacity (Q235 material):ф32mm(round steel)/16mm(steel plate) Weight: 14.42kg
No-load opening time (motorized pump supply):≤25s No-load closing time (motorized pump oil supply):≤30s Dimensions: L*W*H:700*210*165mm |
| 45. | Powerhawk Electric Rescue kit
|
1 | CY‐2 Kit includes:
§ P‐16 Rescue Tool § AP‐1600 Attachment Pins § S‐1601 Spreader Arms § C‐1601 Curved Cutter § CS‐1602 Power Blade § CA‐4M Power Cable § PC‐100 Controller Unit § PWR‐3X12 Power Pack (QTY‐2) § BC‐U1 Battery Charger § JC4‐16 Jumper Cables, 16 Ft. |
We only can recommend similar rescue tools:
Electric hydraulic pump: pump type single-stage pump; Operation mode: electric button; Rated pressure 720bar; High pressure flow 0.5L/min; Low pressure flow 1.0L/min; Conversion pressure 5-10Mpa; Hydraulic oil capacity 0.2L; Motor power 550W; Motor speed 2500rp/min; Battery (rechargeable lithium battery) 28V 5AH; Net weight: 5.5kg; The length of the output oil pipe is 2m; Micro shear: the maximum opening distance is 60mm; Shear capacity (Q235A material): 18mm; |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| § P‐40 Power Pusher Ram, 40” (QTY‐2)
§ 2C0516‐1 Coupling, Ram. § LB‐1204 Flood Light § EC4‐16 Extension Cable, 16 Ft. |
Weight: 2.05kg
Micro expander: expansion distance 154mm; Expansion tension: 40KN; Weight 2.92kg Micro door opener: closing length 250mm; The maximum stroke is 95mm; The maximum supporting distance is 300mm; The maximum opening force is 63KN; Weight 3.75kg Crowbar: weight 0.7kg; 390mm long. Package weight 20.15kg |
|||
| 46. | Hydraulic Lukas spreader | 2 |
|
Hydraulic Chinese spreader Rated working pressure: 63Mpa Maximum expansion distance: 604mm
Rated expansion force: 53.16~71.66kn No-load opening time (motor pump oil supply): ≤30s No-load closing time (motor pump oil supply): ≤25s Weight (working condition): 19.76kg Dimensions: L*W*H: 745*190*160mm |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 47. | Hydraulic Lukas rams | 2 |
|
Hydraulic Chinese rams Working pressure: 63MPa Stroke: 400mm
Max. jacking force: 123.41KN Extending length：940mm Closed length: 540mm Weight: 12.14kg Dimensions: LxWxH: 540x195x90mm |
| 48. | Hydraulic reels 20 M | 2 |  |
Hydraulic reels 20 M |
| 49. | Hydraulic Lukas hand pump | 2 |  |
Hydraulic Chinese hand pump Rated working pressure: 63MPa Hydraulic oil tank volume: 2.0L Low-pressure output pressure: 5~10MPa
High-pressure flow rate: 1.5ml/time Low-pressure flow rate: 12ml/time Maximum handle force: 350N Weight: 7kg |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| Dimensions (L*W*H): 715*180*170 mm | ||||
| 50. | Hydraulic Lukas door /pedal cutter | 1 |  |
Hydraulic Chinese door /pedal cutter
comply |
| 51. | Hydraulic Lukas pump | 2 | § To have 2(two) starting mode: Manual and electric
|
To have 2(two) starting mode: Manual
Rated pressure: 63Mpa*2 Rated working speed: 3200±200rpm Output flow (high-pressure flow): ≥0.66L/min*2 Output flow (low-pressure flow): ≥2.0L/min*2 Weight: 23.94kg Dimensions (L*W*H): 460*330*430mm Accessories: 2 sets of 5m hose |
| 52. | Ram support | 2 |
|
Comply |
| 53. | Rotary hammer | 1 | § Unmatched Power to Weight Ratio – | Unmatched Power to Weight |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
|
|
8.0 Amps, 2.6 ft-lbs Impact Energy and 7.7 lbs
§ Vibration Control – Vibration reduction in the hammer mechanism and the grip area to provide maximum user comfort for extended periods of work. § Multi-Function Selector – 3 modes of operation: Rotary Hammer, Hammer- Only mode, and Rotation mode. § Integral Clutch – To help minimize torque reaction. § Variable Speed 3-Finger Trigger – Better operator control and accurate bit starting. § Supplied with 11 pcs SDS drill bits set for heavy-duty work. |
Ratio – 8.0 Amps, 2.6 ft-lbs Impact Energy, and 7.7 lbs Vibration Control – Vibration reduction in the hammer mechanism and the grip area to provide maximum user comfort for extended periods of work. | ||
| 54. | Hacksaw | 2 |  |
Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 55. | Hazard demarcating tapes (roles) and triage tags | 3 | Comply | |
| 56. | Adapter for socket set | 3 | The adapter for the socket set Comply | |
| 57. | Bolt cutters 42” | 1 | Bolt cutters 42” Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 58. | Forcible entry tool
|
2 | § This should be a multi-use forcible entry tool to be used for different forced entry scenarios. (striking, cutting, prying, pushing/pulling) | Fire axes, fire hammers, fire claw rakes, fire toppers, long-handled fire saws, fire shears, etc. |
| 59. | Biel tool
|
2 | § Is a personal-size multi-purpose forcible entry and rescue tool.
§ Designed for forcing doors and windows, prying and twisting hasps and locks. § Light overhauling, metal cutting, and chopping. § Constructed of alloy steel forgings. § Heat treated for maximum strength and durability. § Chrome plated for easy maintenance. |
Is a personal size multi-purpose forcible entry and rescue tool.
Designed for forcing doors and windows, prying and twisting hasps and locks. Light overhauling, metal cutting, and chopping. Constructed of alloy steel forgings. Heat treated for maximum strength and durability. Chrome plated for easy maintenance. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 60. | Vetter Air bags HP 70-ton | 2 |  |
Air bags HP 68 ton Lifting tonnage: 68T Dimensions mm: 960*960*25
Lifting height mm：550 Inflation volume Liter: 1208 Water filling liter: 135 Self-weight kg: 28.4 |
| 61. | Vetter Air bags HP 35-ton | 2 |  |
Airbags HP 31 ton Lifting tonnage: 31T Dimensions mm: 660*660*25 Lifting height mm:365 Inflation volume Liter:445 Water filling liter: 49
Self-weight kg: 13.5 |
| 62. | Vetter Air bags HP 6-ton | 2 |  |
Air bags HP 6 ton Lifting tonnage:6T Dimensions mm: 300*300*25 Lifting height mm:155 Inflatable volume Liter:22.5 Water charge liter:2.4
Self-weight kg: 2.65 |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER | |
| 63. | Vetter Air bags HP 1ton | 2 |  |
Air bags HP 1ton Dimensions mm: 150*150*25 Lifting height mm:70 Inflatable volume Liter:6.2 Water filling liter:0.7
Self-weight kg:0.66 |
|
| 64. | Vetter Air bags LP Type D | 2 |   |
Do not understand this
item, and we recommend you Air regulator and pipeline. Please check the attached photos. Lifting air cushion air hose (Double 5m air line + pressure reducing valve) |
|
| 65. | Vetter Air regulator
/controller |
2 |
|
|
No. 64 item included an air regulator, so here we give an air cylinder:
Gas cylinder volume 6L, Working pressure 30MPa |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 66. | Step chocks Large set (sliding) | 2 |  |
Step chocks Large set (sliding) |
| 67. | 4-Jacks Hydraulic Car Dolly Mover | 2 set |  |
4-Jacks Hydraulic Car Dolly Mover
Weight capacity: 1500 lbs. Casing length: 13″. Casing distance: 420 – 700mm. Packing size: 70*65*21cm. Net weight: 22kg; Gross weight: 25kg |
| 68. | Multi-gas detector and analyzer (Integrated Wireless) | 2 | § It should have a 5-way notification system for gas, and radiation.
§ Delivers unmistakable alerts (audible/vibration) to the user, and people working in the vicinity as soon as a hazardous atmosphere has been detected. § Should be intrinsically safe. § Easy to use, calibrate, and maintain/service. |
Delivers unmistakable alerts (audible/vibration) to the user, and people working in the vicinity as soon as a hazardous atmosphere has been detected.
Should be intrinsically safe. Easy to use, calibrate, and maintain/service. |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
|
|
§ Powered by rechargeable batteries | |||
| 69. | AC Hot stick | 2 | § CONFIRM power shutdown, lockout, tag out, disconnects.
§ FIND hidden sources of dangerous AC from a safe distance without making physical contact. § DETECT power line back feeds from motor generators and energized pools of water. § ENSURE a safe environment for your vehicular rescue. |
Detection voltage: 120V/60Hz or 220V/50Hz;
Signal indication: sound and light (frequency increase or decrease) Test frequency: 20~100Hz Self inspection: 3s Power supply: 4 No. 5 alkaline batteries Normal service life: 1 year Continuous use time: 300h Battery alarm: internal low |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
§ IT PROTECTS the life of your first responders. | voltage alarm
Operating temperature: – 30 ° C~50 ° C Size: ￠45mm, Length 521mm Weight: 0.57kg |
||
| 70. | Motor vehicle Crash Kit | 2 | § MP-1000 – A fire-extrication blanket to cover the patient.
§ The HRS Hood Release Tool – Release vehicle hood latches in seconds! § 911 Battery Cable Cutter – Top-of-the-line cable cutters, cut battery cables with minimal effort. § Pro Hack Saw & spare blades – Pro Hack Saw Premium Professional: Patented quick blade change feature means no tool is needed to change out. |
Fire blanket Cable Cutter
Pro Hack Saw & spare blades
|
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| blades. Unique sanded finish rubber grip handle for better grip and comfort.
§ Heavy Duty Spring Window Punch – This Spring Window Punch is the safe way to shatter tempered glass. No need to push through the window. With the new spring window punch just pull back and release. § V-Knife Belt – The V-Knife cutter is an excellent tool for cutting seat belts quickly and safely. It is also GREAT for cutter wiring out of the way. It has a replaceable standard blade. § Battery Cable Cutters § ART Glass Removal Tool (with additional window punch)- The fastest and safest windshield removal saw on the market today. § 9 1/2″ Grip locks § Set of screwdrivers (star/Flat) § File |
Spring Window Punch
screwdrivers (star/Flat)
Adjustable Wrench
Magnetic Holder
|
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| § 8″ Adjustable Wrench
§ Spring Window Punch § 12″ Pry Bar § Utility Knife w/spare blades § Auto Writer § Magnetic Holder |
Utility Knife w/spare blades
|
|||
| 71. | Smoke extractor
|
2 | § Connection to be compatible with item No. 39.
§ Electric drove at 240V. § Low maintenance. § Light in weight. § Portable and Compact in size. § Air cooled. § Waterproof. § Rust-free body. § Long functional life. |
voltage 220V, frequency 50hz, blade diameter of fan 40cm, number of blades 17,
Speed: 2,800rpm |
| 72. | Allen Keys (set) | 1 |  |
Comply |
| 73. | Socket wrench
spanner set (21 |
1 | § The handle to be insulated to
withstand 415V |
The handle is to be insulated to withstand 415V |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| pieces) |  |
|||
| 74. | Fire extinguishers
1 Dry powder, 1 CO2, 1 water- gas, Dry powder (8KG) CO2 (9KG) Water-Base (9KG) |
3 | Each to have;
§ 9kg capacity. § Pressurized with pressure gauge. § Mounted in the equipment lockers
|
Dry powder (8KG) CO2 (9KG)
Water-Base (9KG) |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| 75. | Ear defenders (pairs) | 10 |  |
Comply |
| 76. | Petrol can 20litrs
|
1 | § Noncorrosive metal insulated. | Noncorrosive metal insulated. Comply |
| 77. | Body Bags | 12 | Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
||||
| 78. | Safety Goggles (pairs) | 10 |  |
Comply |
| 79. | Multipurpose ceiling hooks | 3 | § Provision to be stored in fire engine rooftop | Provision to be stored in fire engine rooftop
Comply |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
 |
||||
| 80. | Petrol Disc saw | 1 | § With provision for wood, stone, and metal cutting blades (two each)
|
Gearless saw cylinder displacement 74 CM3
The Bore of the cylinder is 51 mm Maximum high-speed idle speed is 9300rpm Power 3.7KW Ignition system manufacturer SEM Spark plug Champion RCJ6Y Trip distance 0.5 mm Fuel tank capacity 0.9 liters Power cutter (without saw blade and hydraulic oil) 12 kg Saw blade diameter 350mm Cutting depth 125 mm Cutting blades with wood, stone, and metal (two each) (including a diamond saw blade) |
| 81. | High-pressure portable fire pump with high | 1 | § Petrol-driven engine
§ 60m high-pressure hose on a reel with provision for extension to up to 90M |
Type GX140 Dimension(mm) 1,400*750*1,000
Total weight(kg) 145kg Droplet particles(um) <400 |
| No. | Item Description | Quantity to be supplied | Remarks | OFFER |
| pressure hose
|
with relevant fitting.
§ High-pressure 5,000psi hand lance with 900mm extension § Mounted onto a heavy-duty steel frame or aluminum frame. § Pneumatic rubber tires for easy maneuvering § Choice of both manual recoil pull and electric start § Water flow rates from 12.65LPM or greater § High-pressure heavy-duty piston pumps for long endurance § Low recoil on handgun activation § Water Mist approved F11 deluge nozzle § Maintenance-free Battery to be supplied. § To have a 65~70L Aluminum water tank and a provision for connection to an external water supply. |
Power Gasoline (Customizable diesel, motor type) Injection remaining rate 1%
Firefighting level performance 20A、297B Hose length(m): 30 Range(m) 14.5 Direct straight range (m) 16 Water mist pressure(Bar) 100 Rated jet flow(L/min) 20 Rated injection pressure of spray(Bar) 30 Rated flow of water spray(L/min) 20 Liquid storage container volume(L) 170 Droplet particles(um) <400 |
Related Posts:
Reviews
There are no reviews yet.
