BRIEF
The MAN multipurpose fire truck produced by CSCTRUCK Fire Rescue Truck is a specialized firefighting truck built on a German MAN chassis, integrating lighting, traction, rescue, and fire-fighting capabilities. It features an imported compressed air foam system, high-power electricity generation, and advanced lighting. The fire truck is also equipped with robust traction systems and essential rescue, emergency, and protective gear. This versatile vehicle is ideal for handling various emergencies, including fires, traffic accidents, building collapses, earthquakes, and incidents in public buildings, residential areas, and shopping malls.
FEATURES
– Outstanding power performance with specific power greater than 13.
– Carefully designed with a corrosion-resistant aluminum alloy body and an independent high polymer material tank.
– Advanced intelligent control system featuring user-friendly PLC control, CAN-bus communication, and a one-touch fire-fighting operation.
– Customized fire-fighting equipment arrangement for optimal performance, with equipment evenly distributed and arranged with lighter items on top and heavier items below.
SPECIFICATION
| Item | Unit | Parameter |
| Overall length | mm | 8,960 |
| Overall height | mm | 3,570 |
| Overall width | mm | 2,500 |
| Total weight | kg | 15,800 |
| Extinguishant-rated load weight | ||
| Water | kg | 4,400 |
| Foam | kg | 300/200（A/B） |
| Max. travel speed | km/h | 90 |
| Max. net power | kW | 213 |
| Power density | – | 13 |
| Monitor | ||
| Water monitor-rated flow | L/S | 48 |
| Water monitor-rated pressure | Mpa | ≤1 |
| Rated reach | ||
| Water | m | 60 |
| Foam | m | 55 |
| Water pump | ||
| Fire-rated flow | L/S | 60 |
| Fire-rated pressure | MPa | 1 |
| Air/foam compressor system | ||
| Dry foam flow | L/S | 1.5 |
| Wet foam flow | L/S | 3 |
| Dry foam reach | m | 12 |
| Wet foam reach | m | 20 |
