BRIEF



The MAN 5000 liters CAFS firefighting truck by CSCTRUCK Fire Rescue Truck is a robust and highly efficient fire rescue vehicle built on a durable MAN chassis. This 4×2 drive-type truck is powered by a 213 kW engine, offering reliable performance with a maximum speed of 90 km/h. Designed for challenging firefighting scenarios, the vehicle has a full loading weight of 17,000 kg.

Equipped with a 4,300-liter water tank, a 200-liter Type A foam tank, and a 500-liter Type B foam tank, all crafted from lightweight and corrosion-resistant PP material, the fire truck ensures sufficient firefighting resources on board. Its fire pump delivers an impressive flow rate of 60 L/s at 10 bar, while the fire monitor provides 30 L/s at the same pressure, achieving a shooting range of at least 55 meters.

The truck is further enhanced by its advanced CAFS (Compressed Air Foam System), delivering a mixture flow rate of 90 L/s, ensuring effective fire suppression with reduced water usage. This makes it especially useful for combating Class A and B fires.

The MAN 5000-liter CAFS fire truck represents a blend of cutting-edge firefighting technology and robust design, making it an excellent choice for urban and industrial fire rescue operations. Its efficiency, versatility, and high-performance features provide reliable solutions for various emergency scenarios.



FEATURES



1. High-Performance Firefighting Systems
   • Fire pump flow rate: 60L/s@10bar
   • Fire monitor flow rate: 30L/s@10bar
   • CAFS (Compressed Air Foam System) mixture flow rate: 90L/s
   • Shooting range: ≥55m.
2. Large Capacity Tanks
   • Water tank capacity: 4,300L
   • Foam tanks: 200L (Type A) and 500L (Type B)
   • Constructed with PP (Polypropylene) material for durability and corrosion resistance.
3. Powerful Chassis and Engine
   • MAN chassis with 4×2 drive type
   • Engine power: 213kW
   • Full loading weight: 17,000kgs.
4. Impressive Mobility
   • Maximum driving speed: 90km/h
   • Designed for quick response times in emergencies.
5. Versatile Firefighting Applications
   • Combines water, foam, and compressed air foam capabilities, making it suitable for various fire types, including structural, vehicle, and chemical fires.



SPECIFICATION



1. The Whole Fire Truck

• Model: CSCCFFT005
• Overall Dimensions(LxWxH): 8,550×2,510×3,560mm
• Full Load Weight: 17,000kgs
• Number of the Crew: 6 (including driver)
• Max. Speed: 90km/h
• Capacity: 4,300L Water & 200L Type A Foam & 500L Type B Foam. PP composite material liquid tank
• Fire pump flow rate: 60L/s@10bar
• Fire monitor: 30L/s flow rate, 55m shoot range
• CAFS system: Compressed air foam mixture flow rate: 90L/s. With Foam Pump and Air Compressor.

2.  Rescue Equipment (Optional)
2.1 Front Winch

• Installation form: Under the bumper
• Drive type: Electric
• Voltage: 24V
• Max. traction: 6,118kg
• Max. towing length: 38m.

2.2 Gasoline Generator

• Rated power: 5kW
• Rated frequency: 50Hz
• Rated voltage: 230V
• Installation position: Inside the equipment compartment.

2.3 Pneumatic Telescopic Light

• Main power: 2×1,000W
• Lighting: Quartz halogen lamp
• The max. height of the main light from the ground: 4.5m
• Rotation angle: Horizontal 420°, pitch 420°
• Main lamp working voltage: 220V
• Installation form: Top of the carriage.

3. Water Pump and Roof Fire Monitor
