BRIEF
The IVECO 4000-liter water-foam fire truck by CSCTRUCK Fire Rescue Truck is a robust firefighting vehicle designed to deliver reliable performance during fire emergencies. It is built on the SAIC-IVECO HONGYAN chassis, which ensures durability and high functionality. With a 4×2 drive type and a powerful 221 kW engine, this fire truck offers a maximum speed of 90 km/h, allowing quick deployment to emergency sites.
This fire truck has a 16,800 kg full loading weight and houses a 3,000-liter water tank and a 1,000-liter foam tank, providing an optimal balance of water and foam for versatile fire suppression capabilities. The tanks are constructed from durable PP composite material, ensuring both longevity and resistance to corrosion. The fire truck is equipped with a high-performance fire pump that delivers a flow rate of 60 liters per second at a pressure of 10 bar, while the roof-mounted fire monitor offers a flow rate of 48 liters per second with a shooting range exceeding 60 meters, enabling firefighters to tackle flames from a safe distance.
This IVECO fire truck is engineered to address various fire situations, making it ideal for industrial sites, urban firefighting, and other high-risk areas. With its advanced firefighting equipment and well-constructed design, this vehicle is a dependable asset for fire rescue operations, offering enhanced efficiency, mobility, and performance under challenging conditions.
FEATURES
1. Dual Tank Capacity: This fire truck has a 3,000-liter water tank and a 1,000-liter foam tank, providing ample capacity for firefighting operations requiring both water and foam.
2. High-Performance Fire Pump: The truck has a powerful fire pump with a flow rate of 60 liters per second at 10 bar, delivering significant water output for intense firefighting needs.
3. Long-Range Fire Monitor: It features a fire monitor with a flow rate of 48 liters per second and a shooting range of over 60 meters, enabling effective firefighting at a distance.
4. Durable and Lightweight PP Composite Tank: The water and foam tanks are made from PP (polypropylene) composite material, known for durability, corrosion resistance, and lighter weight compared to metal, enhancing the vehicle’s stability and longevity.
5. Robust Power and Load Capacity: Built on a SAIC-IVECO HONGYAN chassis with a 4×2 drive type, the truck is powered by a 221 kW engine, supports a full loading weight of 16,800 kg, and can reach a top speed of 90 km/h for rapid response.
SPECIFICATION
1. IVECO 4000 Liters Water Foam Fire Truck
| No. | Main Items | Technical Parameters |
| 1.1 | Model | CSCWFFT004 |
| 1.2 | Overall Dimensions(LxWxH) | 8,420×2,500×3,730mm |
| 1.3 | Full Load Weight | 16,800kgs |
| 1.4 | Number of the Crew | 8(include driver) |
| 1.5 | Max. Speed | 90km/h |
| 1.6 | Capacity | 3,000L Water & 1,000L Foam. PP composite material liquid tank. |
| 1.7 | Fire pump | 60L/s@10bar |
| 1.8 | Fire monitor | 48L/s flow rate, 60m shoot range |
| 1.9 | Painting | The red paint of U.S. PPG |
2. Chassis
- Manufacturer: SAIC-IVECO HONGYAN
- Model: Optional
- Drive Type: 4×2
- Wheelbase: 4,600mm
- Engine model: Optional
- Engine type: Inline 6-cylinder, turbocharged, inter-cooled diesel engine
- Rated power: 221kW
- Gearbox: Manual gearbox
- PTO: Full power sandwich type
- Fuel tank capacity: 200L aluminum alloy fuel tank
3. Superstructure of The Fire Fighting Truck
| No. | Main Items | Technical Parameters |
| 3.1 | Cabin | |
| 3.1.1 | Structure | Front Driver’s Cabin+Rear Crew Cabin |
| 3.1.2 | Seats | 2+6, with a 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with storage box under the rear 4 seats |
| 3.2 | Standardized Sub-frame | |
| 3.2.1 | Material | High-strength rectangular tube made of special steel |
| 3.2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats |
| 3.3 | Compartment | |
| 3.3.1 | Material | High-strength aluminum alloy profiles (Never Rust) |
| 3.3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear |
| 3.4 | Roller Shutter Door | |
| 3.4.1 | Material | Aluminum alloy profiles with anodized surface |
| 3.4.2 | Structure | With a rain-proof groove on the top, a lever-type bar, a lock handle, a pull strap, a two-point fixed seat, an LED light, and sensors. |
| 3.5 | Foot Pedals | |
| 3.5.1 | Material | High-quality aluminum alloy |
| 3.5.2 | Structure | 50cm width, bears more than 300kg, anti-slip design, with double lock function. Mounted on both sides of the compartment. |
| 3.6 | Superstructure Electric Appliance | |
| 3.6.1 | Warning Light and Siren | Long-row warning lights and sirens are mounted above the cabin. The controller is installed in the driver’s cabin. |
| 3.6.2 | Strobe Light | Mounted on both sides of the compartment |
| 3.6.3 | External Lighting | LED lights are mounted on both sides of the compartment |
| 3.6.4 | Roof Lighting | LED lights are mounted on the inside of the roof |
| 3.6.5 | Side Indicator Light | The inline yellow warning light is mounted on the side of the compartment and the pedals. |
4. Main Equipment of the Fire Truck
4.1 Fire monitor
- Rated flow: ≥48L/s
- Range: Water≥60m, foam≥55m
- Installation position: Top of the carriage
- Control mode: Manual control
- Horizontal rotation: 0°~360°
- Pitch and rotation: -15°~60°
4.2 Fire pump
- Rated pressure: 10 bar
- Rated flow: 60L/s
- Vacuum pump: Electric vacuum pump
- Water diversion form: Wiper water diversion
- Water absorption depth: 7m
- Water diversion time: ≤50s
- Installation form: In the rear pump room.
