BRIEF

The IVECO 4000-liter CAFS fire engine, produced by CSCTRUCK Fire Rescue Truck, is a robust firefighting vehicle built on the reliable SAIC-IVECO HONGYAN chassis. Designed for efficient fire suppression, it features a 4×2 drive configuration and a powerful 257kW engine, enabling it to reach a top speed of 90km/h. With a full loading weight of 17,490kg, this fire engine ensures a balanced combination of performance and capacity.

The IVECO 4000-liter CAFS fire engine is equipped with a 3,300-liter water tank, a 200-liter Type A foam tank, and a 500-liter Type B foam tank, all constructed from durable PP-C composite material to enhance longevity and resistance to corrosion. Its advanced compressed air foam system (CAFS) delivers efficient fire suppression capabilities, complementing the onboard fire pump that provides a flow rate of 60 L/s at 10 bar pressure and a suction height of up to 7 meters.

For effective firefighting at a distance, the fire monitor has a flow rate of ≥48 L/s, with a shooting range of at least 60 meters for water and 55 meters for foam. This ensures that the vehicle can tackle fires in challenging environments, delivering high-performance firefighting solutions.

The IVECO 4000-liter CAFS fire engine combines advanced technology, reliable construction, and versatile firefighting capabilities, making it a valuable asset for fire departments.

FEATURES

1. Tank and Foam System:
   • 3,300 liters of water capacity.
   • Separate foam tanks for 200 liters of Type A foam and 500 liters of Type B foam.
   • Constructed with durable PP-C composite material for lightweight and corrosion resistance.
2. Performance and Drive:
   • Equipped with a powerful 257kW engine.
   • SAIC-IVECO HONGYAN chassis with a 4×2 drive type.
   • Maximum driving speed of 90km/h, ensuring rapid response.
3. Firefighting Capabilities:
   • Fire pump flow rate of 60 liters per second at 10 bar pressure.
   • Suction height of 7 meters, ideal for drawing water from external sources.
4. Fire Monitor Specifications:
   • Monitor flow rate of ≥48 liters per second.
   • Shooting ranges: Water up to 60 meters, foam up to 55 meters.
5. Design and Load:
   • Full loading weight of 17,490 kg for optimal balance between performance and payload.
   • CAFS (Compressed Air Foam System) for enhanced firefighting efficiency.

SPECIFICATION

2. Fire Pump, Fire Monitor and Liquid Tank
2.1 Fire Pump
2.1.1 Brand: Optional
2.1.2 Model: Optional
2.1.3 Rated pressure: 10 bar
2.1.4 Rated flow: 60 L/s
2.1.5 Vacuum pump: Electric vacuum pump
2.1.6 Water priming: Automatic
2.1.7 Water absorption depth: 7m
2.1.8 Water diversion time: ≤50s
2.1.9 Installation form: Rear-mounted
2.2 Fire Monitor
2.2.1 Brand: Optioanl
2.2.2 Model: Optional
2.2.3 Rated flow: ≥48L/s
2.2.4 Range: water≥60m, foam≥55m
2.2.5 Installation position: top of the carriage
2.2.6 Control mode: Manual control
2.2.7 Horizontal rotation angle: 0°~360°
2.2.8 Pitch and rotation angle: -15°~60°
2.3 Water and Foam Tank
2.3.1 Capacity: 3,000 Liters of water, 1,000 Liters of foam
2.3.2 Material: PP-C composite material
2.3.3 Installation form: Liner type
2.3.4 Structure: 2 manholes; 1 overflow/pressure relief device; 2 liquid level sensors; 1 foam tank drain outlet, 1 water tank drain outlet.
3. Superstructure
