BRIEF
The ISUZU FVR multipurpose fire rescue truck, produced by CSCTRUCK Fire Rescue Truck, is a robust and versatile emergency vehicle designed for various rescue operations. Built on the ISUZU QL1180XMFRY chassis, this truck features a 4×2 drive type and can reach a maximum speed of 90 km/h. Powered by the ISUZU 6HK1-TCL engine, it delivers 240 horsepower, ensuring reliable performance in high-stakes situations.
Equipped with a hydraulic crane, the ISUZU FVR fire truck can lift to 5,000 kg, with a maximum lifting height of 7.4 meters, providing significant operational flexibility for rescue tasks. It is fitted with a powerful 4x1000W lifting lighting system to enhance visibility in low-light conditions, allowing for effective nighttime operations. Additionally, the truck includes an electric winch on the front with a rated pulling force of 8,000 kgf (approximately 3,629 kg), making it suitable for heavy-duty rescue operations and vehicle recovery.
The vehicle also has a 380V/10kv/A generator, supplying sufficient power for various tools and equipment needed during rescue missions. This generator enhances the truck’s versatility, supporting extensive rescue operations in remote or challenging environments. With its combination of strength, power, and adaptability, the ISUZU FVR multipurpose fire rescue truck is an ideal choice for fire and rescue departments, providing the capabilities needed for efficient and effective response to diverse emergency scenarios.
FEATURES
1. Engine Power and Speed: Equipped with a 6HK1-TCL engine model delivering 240 horsepower, allowing for a top speed of 90 km/h.
2. Crane Capacity: Features a hydraulic crane with a maximum lifting height of 7.4 meters and a rated lifting capacity of 5,000 kg, suitable for heavy-duty rescue operations.
3. Lighting System: Includes a powerful 4×1,000W lifting lighting system, enhancing visibility during nighttime or low-light rescue operations.
4. Front Winch Capability: Comes with a front electric winch that has a rated pulling force of 8,000 kgf (approximately 3,629 kg), aiding in vehicle recovery and towing tasks.
5. Power Generator: Equipped with a 380V/10kVA generator, providing reliable power for various rescue tools and equipment during operations.
SPECIFICATION
| Component | Specification |
|---|---|
| Chassis Model | QL1180XMFRY |
| Manufacturer | Qingling Motors Co., Ltd. |
| Max Speed | 90 km/h |
| Tire Model | 11.00/20 |
| Number of Tires | 6+1 (4×2 drive) |
| Dimensions (L x W x H) | 8,210 x 2,500 x 3,400 mm |
| Engine | 6HK1-TCL (240 horsepower) |
| Wheelbase | 4,500 mm |
Emergency Rescue System
| Component | Specification |
|---|---|
| Lifting Lighting System | |
| – Main Light | 4 x 1,000W |
| – Pan/Tilt | DC12V |
| – Max Height | 7.5 m |
| – Air Pump | AC220V |
| – Control Box | AC380V, wired remote control |
| Hydraulic Crane | |
| – Max Rated Lifting Capacity | 5,000 kg |
| – Max Lifting Moment | 6 Ton.m |
| – Max Working Radius | 5.8 m |
| – Max Lifting Height | 7.4 m |
| – Max Outrigger Span | 3.5 m |
| Front Electric Winch | |
| – Voltage | 24VDC |
| – Current | 240A |
| – Rated Pulling Force | 8000 kgf (3,629 kg) |
| – Gear Ratio | 150:1 |
| – Speed | 5.6 m/min |
| Generator | |
| – Voltage | 380V |
| – Power | 10 kv/A |
| – Start Mode | Electric/Manual Start |
Fire Truck-Specific Features
| Component | Specification |
|---|---|
| Cabin | Fully enclosed metal, single-row, dual-door, panoramic curved windshield, optional new front cover, front bumper, combination lamps, doors and windows, and front cover panel. |
| Equipment Compartment | Made with imported European aluminum alloy materials, concealed connecting technology, full mortise-and-tenon structure, with aluminum alloy roller shutter doors. |
| Electrical Configuration | |
| – Front Roof Light Bar | Long light bar |
| – Rear Lighting | 24V60W scene light |
| – Side Strobe Lights | Red and blue flashlights on both sides |
| – Safety Indicator Lights | Mounted on lower sides |
| – Interior Lighting | Equipped in cabin, equipment compartment, and pump room |
| – Warning Light | 100W warning light and switch, pre-wired for communication devices |
| – The “elevating lighting system” is powered by a generator set and raised by an air pump system.
– The mast can be lifted to a height of 7.6 meters, with four 1000W main lights providing a broader and farther illumination range, making it especially suitable for nighttime operations. |
  |
|
  |
– Hydraulic Crane
– XCMG 5-ton Knuckle Boom Crane: It takes up minimal space and has a foldable arm mounted on the truck.
– When not in use, the entire boom is retracted, saving space on the vehicle. This allows for more emergency rescue equipment to be placed on the truck.
|
|
|
– Generator Set
– Energy Saving: Excellent combustion efficiency results in significant economic benefits.
– Silent Operation: Low-noise generator sets can be used in any location.
– Reliable: A stable mechanical system and alert system ensure worry-free operation.
|
  |
|
  |
– Electric Winch
– The electric winch is installed at the front of the vehicle and is driven by the vehicle’s power system.
– Advantages: It can be used normally even when the vehicle stalls, is easy to install, allows for multi-position installation, and can be quickly repositioned.
|
