BRIEF
The ISUZU FVR 8CBM foam fire truck, produced by CSCTRUCK Fire Rescue Truck, is a powerful and reliable vehicle designed to handle diverse firefighting operations. Built on the ISUZU QL5190GXFWMFRY chassis with a 4×2 drive configuration, this fire truck combines performance and efficiency. It’s equipped with a robust 6HK1-TCH engine that delivers 300 horsepower, enabling it to tackle challenging terrains with ease.
The fire truck features a spacious water tank with a 6m³ (6,000 liters) capacity and a 2m³ (2,000 liters) foam tank, both constructed from high-quality carbon steel for enhanced durability and resistance to corrosion. This dual-tank system enables the vehicle to store ample water and foam concentrate, crucial for extinguishing flammable liquid fires.
The firefighting equipment includes a CB10/40 fire pump capable of delivering 40 liters per second at a pressure of 1.0 MPa, ensuring a strong and steady flow rate for effective firefighting. Additionally, the PL32 fire cannon on the truck has an impressive shoot range of over 60 meters, allowing firefighters to combat flames from a safe distance.
This ISUZU FVR fire truck’s blend of sturdy build, high-performance engine, and specialized firefighting equipment makes it a highly valuable asset for emergency response teams, ideal for industrial sites, airports, and urban settings that require dependable and high-capacity firefighting solutions.
FEATURES
1. Large Water and Foam Capacity: This truck has a 6m³ water tank and a 2m³ foam tank, allowing it to handle fires effectively with a significant volume of extinguishing agents.
2. Powerful Engine and Chassis: It is built on the ISUZU QL5190GXFWMFRY chassis with a 6HK1-TCH engine producing 300 hp, providing reliable performance in challenging firefighting situations.
3. High-Performance Fire Pump: Equipped with a CB10/40 fire pump that delivers 40L/s at 1.0 MPa, this fire truck can sustain high-pressure water flow, ensuring effective firefighting capabilities.
4. Long-Range Fire Cannon: The PL32 fire cannon has a shooting range of ≥60 meters, enabling effective water or foam projection from a safe distance.
5. Durable Tank Material: The water and foam tanks are constructed from high-quality carbon steel, ensuring durability and corrosion resistance under demanding conditions.
SPECIFICATION
| Item | Specification |
|---|---|
| Chassis Model | QL5190GXFWMFRY |
| Manufacturer | Qingling Motors Co., Ltd. |
| Tank Capacity | Water: 6m³, Foam: 2m³ |
| Fire Pump Model | CB10/40 – Flow: 40 L/s at 1.0 MPa |
| Fire Cannon Model | PL32 – Range ≥ 60 m |
| Power Take-Off | Sandwich Full-Power PTO |
| Engine | 6HK1-TCH (300 hp) |
| Tire Model | 11.00R20 |
| Number of Tires | 6+1 (4×2 drive) |
| Dimensions(LxWxH) | 7,995×2,500×3,700 mm |
| Wheelbase | 4,500 mm |
Specialized Fire Truck Features
| Section | Description |
|---|---|
| Cabin | Fully enclosed metal cabin, double-row seats, 4 doors, panoramic curved windshield, with optional new front cover, bumper, combination lights, door windows, and front panel. |
| Tank | Made from high-quality carbon steel (Q23**), welded structure with longitudinal and transverse anti-sway plates, treated with advanced anti-corrosion technology. Stainless steel option available. |
| Pump Room | Mid- or rear-mounted pump. Both sides of the pump room and toolboxes have new high-strength aluminum alloy roller shutters. |
| Toolbox | Made with European aluminum alloy embedded overlap technology, fully mortised structure with aluminum alloy roller shutters. |
| Electrical Configuration | Long-row warning light at the front of the cabin roof, 24V 60W scene lighting at the rear, red and blue strobe lights on both sides, safety marker lights below, cabin, toolbox, and pump room lighting, 100W warning light, additional rotation light switch, communication equipment interface. |
