BRIEF
The ISUZU FVR 8 CBM pumper fire truck manufactured by CSCTRUCK Fire Rescue Truck stands out as a robust and specialized vehicle designed for firefighting operations. Built on an ISUZU FVR chassis with a 4×2 drive type configuration, it combines reliability with maneuverability essential for urban and suburban firefighting scenarios. Powering this vehicle is a 6HK1-TCG61 engine, delivering 240 horsepower and meeting the stringent Euro 6 emission standards, ensuring efficiency and reduced environmental impact.
At its core, the fire suppression capabilities are enhanced by the CB10/40 fire pump model, capable of a robust 40 liters per second at 1.0MPa, ensuring rapid deployment of water or fire retardant. This capability is crucial in containing and extinguishing fires swiftly. The PS40 fire gun model further complements these capabilities with a flow rate of 40 liters per second and an impressive range of over 60 meters, providing firefighters with the reach needed to tackle fires effectively from a safe distance.
The 8 CBM water tanker capacity ensures ample onboard water supply, critical for sustained firefighting operations without frequent refills. This feature enhances the ISUZU FVR 8 CBM pumper fire truck‘s autonomy and operational efficiency during emergencies, enabling firefighters to focus on containment and rescue efforts.
Overall, the ISUZU FVR 8 CBM pumper fire truck by CSCTRUCK Fire Rescue Truck represents a pinnacle of engineering tailored for firefighting exigencies. Its combination of powerful engine performance, advanced fire suppression systems, and substantial water carrying capacity makes it an indispensable asset in any firefighting brigade’s arsenal, ready to respond swiftly and effectively to protect lives and property in challenging fire incidents.
FEATURES
- High-Capacity Water Tanker – Equipped with an 8 CBM (8,000 liters) water tank, ensuring ample water supply for firefighting operations.
- Powerful Engine & Efficient Performance – Built on an ISUZU FVR chassis with a 6HK1-TCG61 engine, delivering 240HP and meeting Euro 6 emission standards for high performance and environmental compliance.
- Robust Fire Pump System – Features a CB10/40 fire pump, providing a 40L/s flow rate at 1.0MPa pressure, ensuring efficient water discharge.
- Long-Range Fire Gun – Equipped with a PS40 fire gun with a 40L/s rated flow and a ≥60m range, allowing effective firefighting from a safe distance.
- Reliable 4×2 Drive Configuration – The 4×2 drive type ensures stability and maneuverability, making it suitable for urban and suburban firefighting operations.
SPECIFICATION
| Model No. | CSCPFT008 | ||
| Cab | GIGA double row, air con, power window, central lock, allowable 3+3 passengers | ||
| Engine(Hp) | 240 | ||
| Power(kW) | 177 | ||
| Wheelbase | 4,500mm | ||
| Front/Rear Suspension | 1,335/2,090mm | ||
| Steering | Power steering | ||
| Approach/departure angle | 15/13 | ||
| Wheels & tire | 295/80R22.5 | ||
| Tire number | 6+1 | ||
| Tank Dimensions(mm) | / | ||
| Cubage (m3) | 8 | ||
| RHD or LHD | LHD | ||
| Overall Dimensions(mm)(LxWxH) | 8,110×2,540×3,600 | ||
| Curb weight (Kg) | 10,250 | ||
| Engine | Model | 6HK1-TCG61 | |
| Horsepower | 240 | ||
| Maximum output (kW) | 177 | ||
| Maximum torque (N·m) | |||
| Type | 6 cylinders, in-line,4-stroke, diesel engine | ||
| Displacement | 7.79L | ||
| Japan brand, Euro 6 | |||
| Driving passenger | 3+3 | ||
| Transmission | MLD 6 speed forward and one reverse, manual | ||
| Front Axle | 6.3T | ||
| Rear Axle | 13T | ||
| Brake System | Air brake Exhaust brake |
||
| Color and LOGO | customized | ||
| Electric system | 24V | ||
| Fire equipment part | Fire pump | CB10/40, rated pressure 1.0MPa, flow 40L/s | |
| Fire gun | PS40, flow 40L/s, jet distance ≥60m | ||
| Standard configuration | National standard equipment box, full units national standard fire-fighting equipment, fire pump, fire gun, fire power take off, sliding gate, row type lights, reel, common tools, rear climbing ladder, water tank. | ||
| Optional configuration | Foam type, dry powder type, stainless tank, other requirements. | ||
