BRIEF
The ISUZU FVR 6CBM foam fire truck by CSCTRUCK Fire Rescue Truck is an advanced, reliable vehicle engineered for rapid response to fires, especially in high-risk areas requiring foam-based fire suppression. Built on the robust ISUZU/QL1180XMFRY chassis model, this truck features a 4×2 drive type, ensuring both stability and maneuverability on a variety of terrains.
The fire truck is powered by the 6HK1-TCH engine, delivering 240 horsepower, which provides the necessary power for quick response times and sustained operational performance. It has a dual-capacity tank system with a 4m³ water tank and a 2m³ foam tank, allowing firefighters to switch between or combine water and foam depending on the nature of the fire. The tanks are crafted from high-quality carbon steel, enhancing durability and resistance to corrosion.
Equipped with the CB10/40 fire pump, the truck achieves a flow rate of 40 liters per second at a pressure of 1.0MPa, ensuring a steady and strong supply of firefighting agents. The PL32 fire cannon, capable of a shooting range of 70 meters or more, enables firefighters to reach and suppress fires at significant distances, maximizing safety and effectiveness in challenging situations.
The ISUZU FVR 6CBM foam fire truck represents CSCTRUCK Fire Rescue Truck’s commitment to high-performance firefighting solutions, integrating powerful engine specifications, ample tank capacity, and reliable firefighting equipment to handle complex firefighting scenarios effectively.
FEATURES
1. Water and Foam Tank Capacity: Equipped with a 4,000-liter water tank and a 2,000-liter foam tank, providing a combined capacity of 6,000 liters for efficient fire suppression.
2. Powerful Engine and Chassis: Built on the ISUZU QL1180XMFRY chassis model with a 6HK1-TCH engine, it has a 240hp power rating, which ensures high performance and durability, especially in emergency conditions.
3. Effective Fire Pump and Flow Rate: Features the CB10/40 fire pump model, offering a flow rate of 40 liters per second at a pressure of 1.0 MPa, making it highly efficient for firefighting tasks.
4. Long-Range Fire Cannon: Equipped with the PL32 fire cannon model that has a shooting range of over 70 meters, allowing firefighters to tackle fires from a safe distance.
5. High-Quality Tank Material: The tank is made from high-quality carbon steel, ensuring durability, corrosion resistance, and longevity in rigorous firefighting environments.
SPECIFICATION
| Specification | Details |
|---|---|
| Model | ISUZU FVR 6CBM Foam Fire Truck |
| Chassis Model | QL1180XMFRY |
| Manufacturer | Qingling Motors Co., Ltd. |
| Tank Capacity | Water Tank: 4 m³ + Foam Tank: 2 m³ |
| Fire Pump Model | CB10/40, Flow: 40 L/s at 1.0 MPa |
| Fire Cannon Model | PL32, Range ≥ 70 m |
| PTO (Power Take-Off) | Sandwich-type Full Power PTO |
| Engine | 6HK1-TCH (240 hp) by Qingling Isuzu (Chongqing) Engine Co., Ltd. |
| Tire Model | 11.00R20 |
| Number of Tires | 6+1 (4×2 Drive) |
| Dimensions (L x W x H) | 8,060×2,500×3,510 mm |
| Wheelbase | 4,500 mm |
Fire Truck Special Features
| Component | Description |
|---|---|
| Cabin | Fully enclosed all-metal cabin, double-row seats, 4 doors, panoramic curved windshield, optional new front grille, bumper, and headlamps. |
| Tank | High-quality carbon steel (Q23**), welded structure with anti-sloshing baffles, advanced anti-corrosion treatment, stainless steel optional. |
| Pump Compartment | Central or rear pump, with high-strength aluminum alloy roll-up doors on both sides. |
| Equipment Compartment | Made with European-style embedded aluminum alloy joints, full mortise and tenon structure, and aluminum alloy roll-up doors. |
| Electrical Configuration | Long-row lights on the cabin top, 24V 60W scene light at the rear, red and blue strobe lights on each side, safety lights below, cabin and equipment compartment lighting, 100W alarm lights, additional switches, and communication equipment interface. |
