BRIEF
The ISUZU 700P 3CBM water fire truck, produced by CSCTRUCK Fire Rescue Truck, is a versatile and efficient firefighting vehicle designed for quick response and adaptability in various emergencies. This fire truck is built on the ISUZU QL1100A8KAY chassis, offering a reliable 4×2 drive type and powered by the 4HK1-TC51 engine, delivering 190 horsepower. This engine ensures robust performance and maneuverability, essential for swift response and navigation through tight spaces or challenging terrain.
A key feature of this fire truck is its 3m³ (3000 liters) water tank capacity, crafted from high-quality carbon steel, which provides durability and resistance to corrosion. It is equipped with the CB10/30 fire pump model, capable of delivering a flow rate of 30 liters per second at a pressure of 1.0 MPa. This high-performance pump enables firefighters to maintain a steady and powerful stream of water during operations.
The PS30 fire monitor, integrated into this vehicle, offers an impressive shooting range of 45 meters or more, allowing firefighters to tackle fires from a safer distance. The combination of high-quality components and a compact, agile design makes the ISUZU 700P 3CBM water fire truck an excellent choice for urban firefighting applications. Its sturdy build, reliable ISUZU engineering, and effective firefighting equipment make it a valuable asset for fire departments seeking a balance of efficiency, power, and maneuverability.
FEATURES
1. Efficient Water Tank Capacity: Equipped with a 3m³ (3000 liters) water tank, providing sufficient capacity for firefighting in urban and rural areas.
2. Powerful Engine Performance: Built on the ISUZU QL1100A8KAY chassis with a 4×2 drive type and powered by a 4HK1-TC51 engine, delivering 190 horsepower for reliable performance in diverse terrains.
3. High-Performance Fire Pump: Uses the CB10/30 fire pump model, with a flow rate of 30 liters per second at a pressure of 1.0 MPa, enabling strong water output for efficient firefighting.
4. Long-Range Fire Monitor: Equipped with the PS30 fire monitor model, which has a shooting range of over 45 meters, ensuring the ability to reach distant fires effectively.
5. Durable Water Tank Material: The tank is constructed from high-quality carbon steel, enhancing durability and corrosion resistance for prolonged usage and low maintenance.
SPECIFICATION
| Item | Specification |
|---|---|
| Vehicle Model | ISUZU 700P 3CBM Water Fire Truck |
| Chassis Model | QL1100A8KAY |
| Manufacturer | Qingling Motors Co., Ltd. |
| Tank Capacity | 3m³ |
| Fire Pump Model | CB10/30 (Flow rate: 30 L/s at 1.0 MPa) |
| Fire Monitor Model | PS30 (Range: ≥45 m) |
| PTO (Power Take-Off) | Sandwich full-power PTO |
| Engine | 4HK1-TC51 (190 HP) |
| Tire Model | 8.25R20 |
| Number of Tires | 6+1 (4×2 drive) |
| Dimensions (LxWxH) | 6,940×2,280×2,880 mm |
| Wheelbase | 3,815 mm |
Fire Truck Special Features
| Item | Description |
|---|---|
| Cabin | Fully enclosed all-metal cabin with dual rows and 4 doors. Features panoramic curved windshield, optional new front grille, front bumper, front combination lights, door windows, and front fascia. |
| Tank | Made of high-quality carbon steel (Q23**), welded structure, with internal anti-sway baffles and advanced anti-corrosion treatment. Stainless steel material is optional. |
| Pump Compartment | Mid- or rear-mounted pump, with high-strength aluminum alloy rolling shutters on both sides of the pump and equipment compartments. |
| Equipment Compartment | Made with European technology, aluminum alloy material, using concealed overlapping technology with full mortise and tenon structure. Aluminum alloy rolling shutters were used. |
| Electrical Configuration | The top front of the cabin has a long light bar, rear of the body has a 24V 60W fire scene light. Red and blue flashing lights on both sides and safety marker lights on the lower side. Interior lighting in the cabin, equipment compartments, and pump compartment. 100W siren light, extra flashing light switch, and communication device ports are provided. |
