The ISUZU 3000 liters water tanker small fire truck, produced by CSCTRUCK Fire Rescue Truck, is a compact yet efficient fire-fighting vehicle. Built on the ISUZU QL1100A8KAY chassis, it features a 4×2 drive type and supports a 9,680 kg rated loading weight. It is designed for quick response and reaches a maximum speed of 90km/h. It is powered by a 4HK1-TC51 engine, which delivers 141kW of power.

This fire truck is equipped with a 3000-liter water tank made from durable PP composite material, which ensures both lightweight and high corrosion resistance. The vehicle is fitted with a high-performance water pump that offers a flow rate of 40 liters per second at 10 bar pressure. Its electric vacuum pump enables a suction height of up to 7 meters, making it versatile for water sourcing.

Additionally, the fire truck is fitted with a roof water monitor that also offers a 40L/s flow rate at 10 bar pressure, with a water shooting range of 50 meters or more, allowing for effective fire suppression even from a distance. This configuration makes the ISUZU water tanker ideal for fire emergencies in urban and rural settings where agility, speed, and reliable water output are crucial.

1. Chassis and Drive Type: Built on the ISUZU QL1100A8KAY chassis with a 4×2 drive type, providing stability and maneuverability.

2. Engine Performance: Powered by the 4HK1-TC51 engine model, delivering 141kW, enabling a maximum driving speed of 90km/h, suitable for rapid response.

3. Water Capacity and Tank Material: Equipped with a 3000-liter water tank made of durable PP composite material, ensuring effective water storage and long-lasting performance.

4. Pump and Water Flow Rate: Features a high-capacity water pump with a flow rate of 40L/s at 10 bar pressure, ensuring powerful water delivery for firefighting operations.

5. Suction and Water Monitor: Capable of a 7-meter suction height with an electric vacuum pump, the roof water monitor provides a water shoot range of over 50 meters, ensuring efficient firefighting from a distance.

3. Superstructure of CSCWTT003

3.1 Cabin

• Structure: Double-row cabin with 4 doors.
• Seats: 2+4, with 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with storage box under the rear 4 seats.

3.2 Compartment

• Material: High-strength aluminum alloy profiles (Never Rust)
• Structure: Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear.

3.3 Roller Shutter Door

• Material: Aluminum alloy profiles with anodized surface.
• Structure: With rain-proof groove on the top, lever-type bar, lock handle, pull strap, 2-point fixed seat, LED light, and sensors.

3.4 Superstructure Electric Appliance

• Warning Light and Siren: Long-row warning light and siren are mounted above the cabin. The controller is installed in the driver’s cabin.
• Strobe Light: Mounted on both sides of the compartment.
• External Lighting: LED lights are mounted on both sides of the compartment.
• Roof Lighting: LED lights are mounted on the inside of the roof.
• Side Indicator Light: Inline yellow warning light is mounted on the side of the compartment and pedals.

3.5 Water Pump

• Flow Rate: 40L/s @ 10bar
• Vacuum Pump: Electric vacuum pump
• Priming Manner: Automatic
• Suction Height: 7m
• Priming Time: ≤35s
• Location: Rear-mounted

3.6 Roof Water Monitor

• Flow Rate: 40L/s @ 10bar
• Shoot Range: Water ≥ 50 m
• Location: On the top of the tank
• Control Manner: Manual
• Horizontal Rotation Angle 0°~360°
• Pitch Rotation Angle: -15°~60°

3.7 Water Tank

Capacity: 3,000 Liters Water.

Material: PP composite material and Never in Rust.

Structure: 1 Tank Manhole; 1 Overflow Device/Pressure Relief Device; 1 Liquid Level Indicators; 1 Tank Drain Outlets with Valves.
