BRIEF
The ISUZU 2000-liter small fire engine, produced by CSCTRUCK Fire Rescue Truck, is designed for rapid response and urban fire-fighting operations. Built on the reliable ISUZU chassis with a 4×2 drive type, it is ideal for maneuvering through tight city streets. The fire engine features a 2,000-liter water tank made from durable PP composite material, providing excellent corrosion resistance and long-term durability.
Weighing 6,800 kg with a rated loading capacity, the fire truck can reach a maximum speed of 90 km/h, powered by an ISUZU engine that delivers 88kW of power. This performance ensures quick arrival at emergency scenes. The firefighting system includes a CB10/30 fire pump, which has a flow rate of 30 liters per second at 1.0MPa, offering strong water pressure for efficient firefighting. The pump can absorb water from a depth of up to 7 meters, providing versatility in areas where hydrants may not be immediately available.
The fire engine is equipped with a PS30 roof-mounted fire monitor, capable of discharging water at a rate of at least 30 liters per second, with an impressive range of over 50 meters. This ensures effective firefighting even from a distance, making it a versatile and powerful tool for fire departments. This compact yet capable fire truck is ideal for small to medium-scale fire emergencies, offering excellent performance and reliability in demanding situations.
FEATURES
1. Water Tank Capacity & Material: The truck is equipped with a 2000-liter water tank made from durable PP composite material, ensuring lightweight yet robust storage for firefighting operations.
2. Pump & Performance: It features a CB10/30 fire pump capable of delivering a flow rate of 30L/s at 1.0 MPa pressure, with a water absorption depth of 7 meters, providing strong pumping capability for firefighting.
3. Roof Fire Monitor: The PS30 roof fire monitor delivers a flow rate of ≥30L/s with a range of ≥ 50 meters, offering efficient fire suppression over a wide area.
4. Chassis & Power: The fire engine is built on an ISUZU chassis with a 4×2 drive type, powered by an 88kW ISUZU engine, allowing for reliable performance and handling.
5. Load & Speed: With a rated loading weight of 6,800kg and a maximum driving speed of 90km/h, the truck is designed for both quick response and sufficient payload capacity.
SPECIFICATION
Technical parameters of the Small Fire Engine
Dimensions: 6760mm×1920mm×2980mm
The total mass of full load: 6800 kg
Fire extinguishing agent capacity: 2000kg (water)
Number of crew: 5
Maximum speed: ≥90km/h
Chassis of the Small Fire Truck
| No. | Main Items | Technical Parameters |
| 1 | Manufacturer | ISUZU |
| 2 | Model | Optional |
| 3 | Drive Type | 4X2 |
| 4 | Wheelbase | 3,815mm |
| 5 | Engine model | Optional |
| 6 | Engine | Inline 4-cylinder, turbocharged, inter-cooled diesel engine |
| 7 | Power | 88kW |
| 8 | Gearbox form | Manual gearbox, 6 forward gears + 1 reverse gear |
| 9 | PTO | Full power sandwich type |
| 10 | Fuel Tank | 100L |
Superstructure
| No. | Main Items | Technical Parameters |
| 1 | Cabin | |
| 1.1 | Structure | Double row cabin with 4 doors |
| 1.2 | Seats | 2+3, with a 3-point safety belt, the rear 4 seats with SCBA bracket for 6-9L air cylinders, with storage box under the rear 4 seats |
| 2 | Sub-frame | |
| 2.1 | Material | High-strength rectangular tube made of special steel |
| 2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats |
| 3 | Compartment | |
| 3.1 | Material | High-strength aluminum alloy profiles (Never Rust) |
| 3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear |
| 4 | Roller Shutter Door | |
| 4.1 | Material | Aluminum alloy profiles with anodized surface |
| 4.2 | Structure of Roll-Up Doors | With a rain-proof groove on the top, a lever-type bar, a lock handle, a pull strap, a two-point fixed seat, LED light, and sensors. |
Water Pump, Roof Fire Monitor, and Water Tank
1 Fire pump
1.1 Manufacturer: Optional
1.2 Type: CB10/30
1.3 Flow rate: 30 L/s at 1.0MPa
1.4 Water diversion form: Automatic
1.5 Water absorption depth: 7m
1.6 Water diversion time: ≤35s
1.7 Installation form: rear-mounted
1.1 Manufacturer: Optional
1.2 Type: CB10/30
1.3 Flow rate: 30 L/s at 1.0MPa
1.4 Water diversion form: Automatic
1.5 Water absorption depth: 7m
1.6 Water diversion time: ≤35s
1.7 Installation form: rear-mounted
2 Roof Fire Monitor
2.1 Manufacturer: CSCTRUCK
2.2 Model: PS30
2.3 Flow rate: ≥30L/s
2.4 Range: ≥50m
2.5 Horizontal rotation angle: 360°
2.6 Installation position: top of the carriage
2.1 Manufacturer: CSCTRUCK
2.2 Model: PS30
2.3 Flow rate: ≥30L/s
2.4 Range: ≥50m
2.5 Horizontal rotation angle: 360°
2.6 Installation position: top of the carriage
3 Liquid Tank
3.1 Capacity: 2,000kg (water)
3.2 Material: PP composite material (Never in Rust)
3.3 Structure: Built-in vertical and horizontal anti-oscillation partitions
3.4 Type: exposed type
3.5 Equipment: 1 Φ450mm inlet hole with quick opening and locking device; 1 overflow/pressure relief device; 1 liquid level sensor; 1 drain port with valve; 2 water injection ports.
3.1 Capacity: 2,000kg (water)
3.2 Material: PP composite material (Never in Rust)
3.3 Structure: Built-in vertical and horizontal anti-oscillation partitions
3.4 Type: exposed type
3.5 Equipment: 1 Φ450mm inlet hole with quick opening and locking device; 1 overflow/pressure relief device; 1 liquid level sensor; 1 drain port with valve; 2 water injection ports.
