BRIEF
The ISUZU 14000-liter water foam fire truck, crafted by CSCTRUCK FIRE RESCUE TRUCK, epitomizes cutting-edge firefighting technology with a robust design tailored for high-performance emergency response. Built on the reliable ISUZU GIGA chassis and featuring a 6×4 drive configuration, this vehicle boasts a formidable 12,000-liter water tank coupled with a 2,000-liter foam tank. The heart of its operations lies in the 6UZ1-TCG51 engine, delivering 350HP and complying with Euro 4 emission standards, ensuring both power and environmental responsibility.
Constructed from durable 304 stainless steel, the round cylindrical tanker fire truck ensures durability and longevity under intense firefighting conditions. The firefighting capabilities are further augmented by a Hale/Prima p2 4010 fire pump, capable of delivering an impressive flow rate ranging from 6,200 to 7,700 liters per minute, adapting dynamically to operational needs. The Akron/PLK8/48B-5177 fire monitor, operating at 1.0MPa working pressure, facilitates precise fire suppression with a rated flow of 48 liters per second.
Designed for versatility and efficiency, this fire truck stands ready to tackle diverse firefighting scenarios with its advanced features, robust build, and powerful firefighting equipment. It represents a fusion of engineering excellence and operational reliability, ensuring firefighters can respond swiftly and effectively to protect lives and property in challenging environments.
FEATURES
1. High-Capacity Water and Foam Tanks: The truck is equipped with a 12,000-liter water tank and a 2,000-liter foam tank, providing significant firefighting resources.
2. Powerful Engine and Emission Compliance: It features an ISUZU GIGA chassis with a 6UZ1-TCG51 engine model, delivering 350 horsepower and meeting Euro 4 emission standards.
3. Stainless Steel Tank Construction: The water and foam tanks are made from 304 stainless steel, ensuring durability and corrosion resistance, with a round cylindrical design.
4. High-Performance Fire Pump: The truck is fitted with a Hale/Prima P2 4010 fire pump capable of delivering a maximum flow rate of 6,200 to 7,700 liters per minute, depending on the operational mode.
5. Advanced Fire Monitor: The Akron/PLK8/48B-5177 fire monitor can operate at a working pressure of 1.0 MPa and has a rated flow of 48 liters per second, ensuring efficient firefighting capabilities.
SPECIFICATION
| Truck | Make/Model Line | ISUZU | 6X4 LHD | |||
| Chassis Model | ISUZU | QL1250U1SDZY | ||||
| Engine Make | ISUZU | 6UZ1-TCG51 / Euro 4 | ||||
| Horsepower | 350hp | |||||
| Front /Rear loading | 7T+13*2T | |||||
| Tire Size | 12.00R22.5 with 1 spare tire | |||||
| Wheelbase | 4,565+1,370mm | |||||
| White color, 6 persons allowed, air conditioner, power assist, radio, MP3, etc. | ||||||
| Cabin | Mode | Double cab | ||||
| People | 2+4 person | |||||
| Material | High-quality Q235 carbon steel | |||||
| The seats | The seats in the rear section should be made in the form of a locker with mounts for breathing apparatus for firefighters in the quantity of 4 units and 4 units of reserve tanks and equipped with safety belts for all members of the truck crew. The seat cushions of the TCC should be folded to ensure access to lockers under the seats. | |||||
| Water tanker | Capacity | 12,000Liters | ||||
| Shape | Round Cylindrical | |||||
| Material | 304 stainless steel | |||||
| Thickness | Shell: 5mm | |||||
| Reinforcing ribs | Installed on the surface of the sewer tanker to increase the strength of the tank | |||||
| Tank Testing | The tank is hydrostatically tested. | |||||
| Foam tanker | Capacity | 2,000Liters | ||||
| Shape | Round Cylindrical | |||||
| Material | 304 stainless steel | |||||
| Thickness | Shell: 5mm | |||||
| Reinforcing ribs | Installed on the surface of the sewer tanker to increase the strength of the tank | |||||
| Tank Testing | The tank is hydrostatically tested. | |||||
| Fire Pump | Brand | Hale | ||||
| Make/Model | Prima p2 4010 | Prima p2 4010 | ||||
| Origin | U.S.A | |||||
| Priming Performance Range | To 7.5m | |||||
| Priming Speed | 2,500rpm | |||||
| Max. Suction Pressure | 12bar | |||||
| Max. recommended speed | 3,600rpm | |||||
| Minimum idle speed | 900rpm | |||||
| Maximum Outlet Pressure | 17bar | |||||
| Low Pressure | ||||||
| Maximum Outlet Pressure – | 54.5bar | |||||
| High Pressure | ||||||
| Max. Flow – Low Pressure | 6,200 l/min | |||||
| Max. Flow – High Pressure | 7,700 l/min |
| Fire Monitor | Make/Model | PLK8/48B-5177 | ||||
| Brand | Akron | |||||
| Origin | USA | |||||
| Monitor Type | Electric control, remote control | |||||
| Working pressure | 1.0MPa | |||||
| Rated flowing | 48L/s | |||||
| Spray distance | Water ≥ 70 m , Foam ≥ 60 m | |||||
| Spray method | DC, flowering | |||||
| Rotation angle | Horizontal 0~340 °, Tilt -45 ° ~ 12 |
| Pipe system | Material | High-quality steel pipe | ||||
| Pipe Line inlet | 1 unit DN100 inlet behind pump room | |||||
| Filling pipe | 1 unit DN65 port at each side of the water tank (2 units) | |||||
| 1 unit DN65 pump filling water tank. | ||||||
| Pipe Line outlet | 1 unit DN65 at each side of the pump room (2 units), with valve | |||||
| Cooling pipe | Cooling pipe and control valve for PTO | |||||
| Compartment | Material | Aluminum alloy | ||||
| Structure | The outer frame has a special aluminum alloy frame with an overall welded structure, skeleton, and mask for the aluminum alloy profiles, a beautiful appearance, and durability. The outer skin is bonded through an air-fed high-strength adhesive, and the inner floor is an anodized aluminum alloy plate. | |||||
| Equipment door | the use of light high-quality aluminum alloy, with aluminum alloy large shutter doors (with pull rod door handle), open and close flexibility, good sealing, low noise, beautiful appearance, light, and reliability, all shutter doors can be a common key. | |||||
| Internal structure | The internal skeleton with aluminum lap technology, maximizes the increase in space utilization and variability, makes full use of limited space inside the compartment, and picks and places equipment convenient and solid. | |||||
| Roller shutter door | is made of high-strength composite material, mounted with a safe lock. The roller shutter will slide up automatically after pulling out the Lever from the holder. | |||||
| Stairs | Material | high-quality aluminum alloy | ||||
| Width | 50cm, bear more than 300kg, anti-slip design on the pedals with double lock function. | |||||
| Location | on both sides of the compartment and pump room | |||||
| Superstructure Electric Appliance | ||||||
| Warning Light and Alarm | The long-row alarm light is mounted above the cabin. The control switch is in the cabin and integrated with the Siren | |||||
| Strobe Light | It is mounted on a top aluminum frame, at the front and end of the compartment. Its power switch is in the cabin. | |||||
| External Lighting | Long-life lamps are installed on both sides of the compartment for lighting at night. Its power switch is in the cabin. | |||||
| Storage Compartment Light | LED lights are installed in the storage compartment and its main power switch is in the cabin. After opening the power switch, all LED lights in the storage compartment will be on; After closing the power switch, all LED lights in the storage compartment will be off. | |||||
| Side Indicator Light | Side indicator lights are on both sides of the compartment for vehicle width indicating at night. Its power switch is in the cabin. | |||||
| Hose reel | ||||||
| To have two 60-meter 20mm diameter semi-rigid hose reels (each with a pistol grip jet/spray/fog control branch) located on each side of the rear compartment. The hose reel to have manual winding with a hand wheel system. | ||||||
| Towing winch system: | ||||||
| Front hydraulic winch with a hook, 14 mm wire rope with a hook (32M long) has a manual operation option. The rear of the chassis should be fitted with two towing eyes, should be recessed, and not be produced beyond the bodywork. They must be formed to allow a 45-side pull without damage to panels. | ||||||
| Painting | The exterior and interior of the tank are spray painted with high-quality painting |
| Accessories | ||||||
| No. | Item | Standardards | QTY | |||
| 1 | Suction Pipe | DN150x 4m | 2 | |||
| 2 | Water Filter | FLF DN150 | 1 | |||
| 3 | Water separator | FII8065x3-1.6 | 1 | |||
| 4 | Water collector | JII150/80×2-1.0 | 1 | |||
| 5 | Suction Pipe Spanner | FS100 | 2 | |||
| 6 | Overground Hydrant Spanner | QT-DS1, 400mm | 1 | |||
| 7 | Underground Hydrant Spanner | 860mm | 1 | |||
| 8 | Fire hose | 16-65-20 | 6 | |||
| 9 | Fire hose | 16-80-20 | 2 | |||
| 10 | Fire hose | 16-65-5 | 1 | |||
| 11 | Reducer union | KJK65/80 | 1 | |||
| 12 | Hose bandage | DT-SB | 4 | |||
| 13 | Hose strap | 4 | ||||
| 14 | Water-stream nozzle | QZG3.5/7.5 | 1 | |||
| 15 | Diffuser nozzle | QHD6.0/8 | 1 | |||
| 16 | Flowering water nozzle | QZH19 | 1 | |||
| 17 | Air foam nozzle | QP4/0.7Z; 65 | 1 | |||
| 18 | Outer pipette assembly | Φ40×2,000 | 1 | |||
| 19 | Shovel | 1,050mm | 1 | |||
| 20 | Crowbar | 1,060mm | 1 | |||
| 21 | Fire axe | 390mm | 1 | |||
| 22 | Fire hammer | 1 | ||||
| 23 | Portable ladder | TE60 | 1 | |||
| 24 | Extinguisher | 3kg/ABC | 1 | |||
| Pictures for your reference: | ||||||
Pump room
Fire horse
Fire axe
Top.1 brand hose coupling with aluminum alloy material
Water filter and manifold for separating
