BRIEF
The ISUZU 1300 liters water foam fire truck manufactured by CSCTRUCK Fire Rescue Truck embodies advanced firefighting capabilities tailored for efficient emergency response. Built on the ISUZU/QL1040BUFWY chassis, this vehicle operates with a 4×2 drive type, ensuring maneuverability and accessibility even in challenging urban environments. The heart of its operations lies in the 4KH1CN6LB engine, compliant with Euro 5 emission standards, delivering 120HP of reliable power.
Equipped with a dual tank system, the ISUZU 1300 liters water foam fire truck features a 1000L water tank complemented by a 300L foam tank, designed to combat fires of various scales effectively. The tanks are constructed from durable 304 stainless steel, ensuring longevity and resilience in demanding firefighting scenarios. The CB10/20 fire pump installed onboard supports a flow rate of 20L/s at 1.0MPa normal pressure, capable of maintaining a consistent 1.00MPa outlet pressure for effective fire suppression.
Further enhancing its firefighting capabilities is the WST PL8/20w fire monitor, which delivers a rated flow of 20L/s, providing precision and control during firefighting operations. Together, these components form a robust system designed to handle emergencies efficiently, making the ISUZU 1300 liters water foam fire truck a dependable asset for firefighting professionals seeking reliable performance and durability in critical situations.
FEATURES
1. Water and Foam Tank Capacity: The fire truck has a combined capacity of 1,300 liters, with 1,000 liters for water and 300 liters for foam, ideal for firefighting operations.
2. Chassis and Engine: Built on an ISUZU/QL1040BUFWY chassis with a 4KH1CN6LB engine model, this truck has a 4×2 drive type, producing 120HP and complying with the Euro 5 emission standard.
3. Stainless Steel Tank: The water and foam tank is constructed from 304 stainless steel, ensuring durability and corrosion resistance.
4. Fire Pump Performance: Equipped with a CB10/20 fire pump model, it delivers 20 liters per second at 1.0 MPa normal pressure, ensuring effective firefighting capacity.
5. Fire Monitor: Fitted with a WST PL8/20w fire monitor, capable of a 20L/s rated flow at a 1.00 MPa outlet pressure, it provides strong water jet performance for firefighting needs.
SPECIFICATION
| Technical Specification | |||||||
| Truck | Make/Model Line | ISUZU | 4X2 LHD | ||||
| Chassis Model | ISUZU | QL1040BUFWY | |||||
| Engine Make/Model/emission | ISUZU | 4KH1CN6LB/Euro 5 | |||||
| Horsepower | 120HP | ||||||
| Front /Rear loading | 2.5T+4.8T | ||||||
| Tire Size | 700R15 with 1 spare tire | ||||||
| Wheelbase | 2,765mm | ||||||
| Cabin | Mode | Double cab | |||||
| People | 2+3person | ||||||
| Material | High-quality Q235 carbon steel | ||||||
| The seats | The seats in the rear section should be made in the form of a locker with mounts for breathing apparatus for firefighters in the quantity of 4 units and 4 units of reserve tanks and equipped with safety belts for all members of the truck crew. The seat cushions of the TCC should be folded to ensure access to lockers under the seats. | ||||||
| Water tanker | Capacity | 1,000Liters | |||||
| Shape | round Cylindrical | ||||||
| Material | 304 stainless steel | ||||||
| Thickness | shell: 5mm | ||||||
| Reinforcing ribs | installed on the surface of the sewer tanker to increase the strength of the tank | ||||||
| Tank Testing | The tank is hydrostatically tested. | ||||||
| Foam tanker | Capacity | 300Liters | |||||
| Shape | round Cylindrical | ||||||
| Material | 304 stainless steel | ||||||
| Thickness | shell: 5mm | ||||||
| Reinforcing ribs | installed on the surface of the sewer tanker to increase the strength of the tank | ||||||
| Tank Testing | The tank is hydrostatically tested. | ||||||
| Fire Pump | Make/Model | CB10/20 | |||||
| Origin | China | ||||||
| Normal Pressure | 20L/[email protected] | ||||||
| Outlet Pressure | 1.00MPa | ||||||
| Rated RPM | 3309±50r/min | ||||||
| Axial Power | 36kW | ||||||
| Fire Monitor | Make/Model | WST PL8/20w | |||||
| Monitor Type | Manual | ||||||
| Rated flowing | 20L/s | ||||||
| Rated pressure | 0.8mpa | ||||||
| Origin | China | ||||||
| Range | Water≥50m | ||||||
| Horizontal rotation | 0°-360° | ||||||
| Foam mixer | Model | PH48 | |||||
| Material | Cast aluminum and stainless steel | ||||||
| Type | Negative pressure ring pump with washing device | ||||||
| Mixer ratio | 3-6% | ||||||
| Pipe system | Material | High-quality steel pipe | |||||
| Pipe Line inlet | 1 unit DN100 inlet behind pump room | ||||||
| Filling pipe | 1 unit DN65 port at each side of the water tank (2 units) | ||||||
| 1 unit DN65 pump filling water tank. | |||||||
| Pipe Line outlet | 1 unit DN65 at each side of the pump room (2 units), with valve | ||||||
| Cooling pipe | Cooling pipe and control valve for PTO | ||||||
| Electrical equipment | |||||||
| Auxiliary lighting | The firemen’s room, pump room, and equipment box are respectively provided with lights, operating instrument panel is provided with lighting and indicators. | ||||||
| Strobe light | Red and blue strobe lights are installed on both sides of the body. | ||||||
| Warning device | A long row of all-red alarm lights mounted on the roof of the cab. | ||||||
| An alarm with a control box in front of the driver. | |||||||
| Projector | Install a 35W projector at the rear of the upper structure. | ||||||
| Painting | The exterior and interior of the tank are spray painted with high-quality painting | ||||||
| Accessories | |||||||
| No. | Item | Standardards | QTY | ||||
| 1 | Suction Pipe | DN150x 4m | 2 | ||||
| 2 | Water Filter | FLF DN150 | 1 | ||||
| 3 | Water separator | FII8065x3-1.6 | 1 | ||||
| 4 | Water collector | JII150/80×2-1.0 | 1 | ||||
| 5 | Suction Pipe Spanner | FS100 | 2 | ||||
| 6 | Overground Hydrant Spanner | QT-DS1, 400mm | 1 | ||||
| 7 | Underground Hydrant Spanner | 860mm | 1 | ||||
| 8 | Fire hose | 16-65-20 | 6 | ||||
| 9 | Fire hose | 16-80-20 | 2 | ||||
| 10 | Fire hose | 16-65-5 | 1 | ||||
| 11 | Reducer union | KJK65/80 | 1 | ||||
| 12 | Hose bandage | DT-SB | 4 | ||||
| 13 | Hose strap | 4 | |||||
| 14 | Water-stream nozzle | QZG3.5/7.5 | 1 | ||||
| 15 | Diffuser nozzle | QHD6.0/8 | 1 | ||||
| 16 | Flowering water nozzle | QZH19 | 1 | ||||
| 17 | Air foam nozzle | QP4/0.7Z; 65 | 1 | ||||
| 18 | Outer pipette assembly | Φ40×2000 | 1 | ||||
| 19 | Shovel | 1050mm | 1 | ||||
| 20 | Crowbar | 1060mm | 1 | ||||
| 21 | Fire axe | 390mm | 1 | ||||
| 22 | Fire hammer | 1 | |||||
| 23 | Portable ladder | TE60 | 1 | ||||
| 24 | Extinguisher | 3kg/ABC | 1 | ||||
Pump room
Fire pump
Fire monitor
Fire horse
Fire hydrant
Ax and Hammer and shovel
Water gun and compromise joint and manifold converging
Water filter and manifold for separating
