HOWO Multipurpose Fire Truck

Model No.:	HOWO Multipurpose Fire Truck
Overall Dimensions(LxWxH):	9,040×2,500×3,590mm.
Chassis Brand/Model:	HOWO/ZZ5207N4617E1.
Drive Type:	4×2.
Engine Model/Power:	D10.34-50/340HP.
Wheelbase:	4,600mm.
Lift Lighting System:	Main Light: 4*1,000W Cloud Platform DC12V.
Hydraulic Crane:	5,000 kg Payload.
Front Electric Winch:	8,000 kgf (3,629 kg) Rated Pull.
Generator:	380V Voltage, 10 kVA/A Power.

Truck Enquiry

Categories: Multipurpose Fire Truck, Rescue Fire Truck

Description
Reviews (0)

BRIEF

The HOWO multipurpose fire truck, manufactured by CSCTRUCK Fire Rescue Truck, represents a state-of-the-art emergency response vehicle designed to tackle a wide range of firefighting and rescue operations with efficiency and precision. Built on the robust HOWO/ZZ5207N4617E1 chassis, this rescue fire truck boasts a 4×2 drive type, ensuring optimal maneuverability and accessibility even in challenging terrain.

Powering this formidable vehicle is the D10.34-50 engine, delivering an impressive 340 horsepower, guaranteeing swift response times and reliable performance in emergencies. With its powerful engine, the HOWO rescue fire truck can navigate swiftly through urban environments and rural landscapes alike, ensuring timely arrival at the scene of emergencies.

The versatility of the HOWO multipurpose fire truck is further enhanced by its three main structures, each equipped with advanced functionalities to aid in firefighting and rescue operations. The lift lighting system comprises several key components, including a main light featuring 4×1,000W cloud platform DC12V lights, providing exceptional illumination even in low-light conditions.

Additionally, the rescue fire truck is equipped with a hydraulic crane capable of handling payloads of up to 5,000kg, facilitating the lifting and movement of heavy objects encountered during rescue missions. Moreover, a front electric winch with a remarkable 8,000 kgf (3,629kg) rated pull capacity ensures the efficient extraction of vehicles and debris obstructing emergency routes.

Furthermore, the fire truck is outfitted with a 380V voltage, 10 kVA/A power generator, ensuring uninterrupted power supply to vital equipment and tools deployed during firefighting and rescue operations. This generator not only provides essential electricity to the vehicle but also supports the operation of external devices, enhancing the overall effectiveness of the firefighting efforts.

In conclusion, the HOWO multipurpose fire truck by CSCTRUCK Fire Rescue Truck represents a pinnacle of innovation and engineering in the realm of emergency response vehicles. With its powerful engine, versatile structures, and advanced features, it stands ready to tackle any firefighting or rescue challenge with unwavering efficiency and effectiveness.

FEATURES

1. Versatile Chassis: The HOWO multipurpose fire truck boasts a sturdy and reliable HOWO/ZZ5207N4617E1 chassis, offering exceptional durability and stability in diverse rescue scenarios.

2. Powerful Engine: Equipped with a D10.34-50 engine delivering 340 horsepower, this rescue fire truck ensures swift response and effective operation in emergencies, enabling it to reach incident sites quickly and efficiently.

3. Enhanced Lighting System: Featuring a sophisticated lift lighting system, the fire truck is equipped with multiple lighting components to illuminate rescue operations effectively. The main light comprises 4×1,000W cloud platform DC12V lamps, ensuring ample brightness in low-light conditions for improved visibility.

4. Heavy-duty Crane and Winch: With a hydraulic crane capable of lifting payloads of up to 5,000 kg, the rescue fire truck facilitates complex rescue operations by efficiently maneuvering heavy objects. Additionally, a front electric winch with an impressive 8,000 kgf (3,629 kg) rated pull capacity enables the vehicle to assist in various recovery tasks swiftly and securely.

5. Onboard Power Generation: To support its operational needs, the rescue fire truck features a reliable 380V, 10 kVA/A power generator. This onboard generator ensures continuous power supply to essential equipment and tools, empowering firefighters to execute their duties effectively even in remote or challenging environments.

SPECIFICATION

Feature	Details
Chassis Model	ZZ5207N4617E1
Chassis Manufacturer	HOWO
Maximum Speed	95 km/h
Tire Model	12.00/20
Number of Tires	6+1 (4×2 Drive)
Dimensions	9,040×2,500×3,590mm
Engine	D10.34-50(340 HP)
Wheelbase	4,600mm
Emergency Rescue System
Lift Lighting System
Main Light	4*1,000W Cloud Platform DC12V
Lift Height	7.5 m
Pump	AC220V
Control Box	AC380V Wired Remote Control
Hydraulic Crane
Maximum Lifting Weight	5,000kg
Maximum Lifting Torque	6 Ton.m
Maximum Working Range	5.8 m
Maximum Lifting Height	7.4 m
Maximum Leg Span	3.5 m
Front Electric Winch
Voltage	24VDC
Current	240A
Rated Pull	8,000kgf (3,629kg)
Speed Ratio	150:1
Speed	5.6 m/min
Generator
Voltage	380V
Power	10 kVA/A
Startup	Electric/Manual
Fire Truck Special Functions
Cabin	Full Metal Enclosed, Single Row Seat, Double Doors, Panoramic Curved Windshield, Optional New Front Mask, Front Bumper, Front Combination Lamps, Door Windows, Front Grille.
Equipment Box	Aluminum Alloy Profile Hidden Interlocking Technology Manufactured with European Technology, Fully Interlocking Structure. Equipped with Aluminum Alloy Roller Shutter Door.
Electrical Configuration	The front end of the cabin top is equipped with a long row of lights, and the rear of the vehicle is equipped with one 24V60W fire scene lighting lamp. Red and blue flashing lights are installed on both sides of the vehicle, with safety warning lights installed below. The crew compartment, equipment box, and pump room are all equipped with lighting, equipped with 100W alarm lights, additional rotating warning light switches, and communication device reserved interfaces.

Details

Lifting and Lighting System Powered by a generator set, the lifting and lighting system operates through a pneumatic pump system. **Lifting and lowering of the mast, with a lifting height of 7.6 meters, using 4×1,000W main lights to illuminate a wider and farther range. Particularly suitable for nighttime operations.
		Hydraulic Crane 5-ton folding-arm crane, occupying minimal space. The folding arm retracts with the crane when not in use, saving space for the entire vehicle and allowing for more emergency equipment to be stored onboard.
Generator Set Energy efficiency: Excellent combustion efficiency results in high economic benefits. Silent: Low-noise generator set can be used anywhere. Reliable: Stable mechanical systems and warning systems ensure peace of mind during operation.
		Electric Winch The electric winch is installed at the front of the vehicle and is driven by the vehicle’s power system. Advantages include normal operation even when the vehicle engine is off, simple installation, and the ability to be mounted in multiple positions and quickly relocated.
