BRIEF
The HOWO 8-ton water fire truck produced by CSCTRUCK Fire Rescue Truck is a robust firefighting vehicle designed for efficient water transport and high-performance fire suppression. With a 7,800 kg water tank capacity, this truck can deliver a large volume of water to combat fires, making it suitable for medium to large-scale fire emergencies. The truck operates with a 4×2 drive type, ensuring sufficient mobility and stability, while its total weight of 19,100 kg reflects its heavy-duty construction.
Powered by a 245 kW engine, the HOWO fire truck delivers the necessary power to navigate challenging terrains and support its firefighting equipment. The water monitor installed on the truck has a rated flow of 60 L/S and a maximum range of ≥70 meters, enabling it to reach fires from a safe distance. The monitor also operates at a fire-rated pressure of ≤1.2 MPa, ensuring a steady and forceful water stream.
Additionally, the fire truck is equipped with a high-capacity water pump, capable of a rated flow of ≥60 L/S and operating at a pressure of ≥1 MPa, ensuring continuous and reliable water delivery during firefighting operations. These features make the HOWO 8-ton water fire truck a versatile and effective tool for firefighting, particularly in urban and industrial settings, where quick response and large water capacity are critical to managing emergencies.
FEATURES
1. Water Tanker Capacity: The truck has a water tanker capacity of 7,800 kg, allowing it to carry a substantial amount of water for firefighting operations.
2. Drive Type: It features a 4×2 drive type, providing solid handling and stability on various terrains suitable for firefighting missions.
3. Firefighting Power: Equipped with a 60L/S water monitor and a fire-rated pressure of ≤1.2 MPa, it can efficiently discharge water at a significant rate and pressure.
4. High-Performance Water Pump: The water pump has a rated flow of ≥60 L/S and a rated pressure of ≥1 MPa, ensuring a powerful water output during firefighting.
5. Water Range: The water monitor has a range of ≥70 meters, enabling the fire truck to fight fires from a safe distance with high precision.
SPECIFICATION
Item | Unit | Parameter |
Overall length | mm | 8,480 |
Overall height | mm | 3,530 |
Overall width | mm | 2,500 |
Total weight | kg | 19,100 |
Extinguish ant-rated load weight | ||
Water | kg | 7,800 |
Foam | kg | – |
Max. travel speed | km/h | 100 |
Max. net power | kW | 245 |
Power density | – | 12.8 |
Monitor | ||
Water monitor rated flow | L/S | 60 |
Fire rated pressure | MPa | ≤1.2 |
Range | ||
Water | m | ≥70 |
Foam | m | – |
Water pump | ||
Fire rated flow | L/S | ≥60 |
Fire rated pressure | MPa | ≥1 |
