BRIEF
The HOWO 4000 liters water tanker small fire engine, produced by CSCTRUCK Fire Rescue Truck, is a highly efficient and versatile fire-fighting vehicle. Designed for rapid response in both urban and rural areas, it features a 4000-liter water tank made of durable PP composite material, ensuring both lightweight construction and high resistance to corrosion.
Built on the reliable HOWO chassis, the fire engine has a 4×2 drive configuration and a rated power output of 140kW, enabling it to reach a top speed of 90km/h. With a full load weight of 10,950kg, this vehicle adheres to Euro 6 emission standards, ensuring environmental compliance and reduced emissions.
Its fire-fighting capabilities are enhanced by a robust fire pump, delivering a flow rate of 40 liters per second at 10 bar, with a suction depth of 7 meters, making it highly effective in drawing water from nearby sources. The vehicle’s fire monitor, also operating at 10 bar, can output 30 liters per second and has a shooting range of 55 meters, making it ideal for tackling fires in hard-to-reach areas.
The HOWO 4000L fire engine offers excellent performance, agility, and environmental responsibility, making it a dependable choice for fire departments needing a compact, efficient, and powerful fire-fighting solution.
FEATURES
1. High-Performance Fire Pump and Monitor: Equipped with a fire pump delivering a flow rate of 40 liters per second at 10 bar, it has a strong suction depth of 7 meters. The onboard fire monitor provides a flow rate of 30 liters per second at 10 bar, capable of shooting water up to 55 meters.
2. Large Capacity and Durable Water Tank: The tanker carries a 4000-liter water tank made of PP composite material, designed for lightweight strength and durability, ideal for firefighting needs in urban and rural settings.
3. Reliable HOWO Chassis and Power: Built on a robust HOWO chassis, this fire engine features a 4×2 drive type, powered by a 140kW engine, ensuring efficient operation and stability under full load.
4. Euro 6 Emission Standard: Compliant with the Euro 6 emission standard, it meets modern environmental regulations, reducing emissions while delivering the power needed for rapid response.
5. Good Load Capacity and Speed: With a full load weight of 10,950 kg, this fire engine can reach speeds of up to 90km/h, allowing quick dispatch to emergency sites while carrying a substantial water load.
SPECIFICATION
| 1 | Fire Pump | |
| 1.1 | Brand | CSCTRUCK |
| 1.2 | Model | CB10/40-G |
| 1.3 | Rated Flow Rate | 40L/s @ 10bar |
| 1.4 | Vacuum Pump | Water ring vacuum pump |
| 1.5 | Priming Manner | Automatic |
| 1.6 | Suction Height | 7m |
| 1.7 | Priming Time | ≤60s |
| 1.8 | Location | Rear-mounted |
| 2 | Fire Monitor | |
| 2.1 | Brand | CSCTRUCK |
| 2.2 | Model | PS8/30W |
| 2.2 | Flow Rate | 30L/s @ 10bar |
| 2.3 | Shoot Range | 55 m |
| 2.4 | Location | On the top of the tank |
| 2.5 | Control Manner | Manual |
| 2.6 | Horizontal Rotation Angle | 0°~360° |
| 2.7 | Pitch Rotation Angle | -15°~60° |
| 3 | Liquid Tank | |
| 3.1 | Capacity | 4,000 Liters Water Tank |
| 3.2 | Material | PP composite material and Never Rust |
| 3.3 | Structure | 1 Tank Manhole; 1 Overflow Device/Pressure Relief Device; 1 Liquid Level Indicators; 1 tank Drain Outlets with Valves. |
