BRIEF

The HOWO 34M aerial platform fire engine, produced by CSCTRUCK Fire Rescue Truck, is a versatile and robust fire-fighting vehicle designed for advanced rescue and suppression operations. Built on the reliable HOWO chassis with a 6×4 drive configuration, it ensures excellent maneuverability and durability, suitable for various terrains. Its EURO V-compliant engine, offering 351-450 horsepower, enables the vehicle to reach speeds of up to 90 km/h, ensuring rapid deployment to emergency scenes.

Equipped with a water tank capacity of 5,000 liters and a foam tank capacity of 2,000 liters, the aerial platform fire engine provides extended operational endurance in firefighting scenarios. The integrated fire pump boasts a rated flow of ≥50 L/s and a rated pressure of ≥1.4 MPa, ensuring high-performance water and foam delivery. Complementing this system is the PSKD80 fire-fighting gun, capable of a rated flow of 50 L/s (±8%) at a pressure of ≤0.8 MPa, with an impressive range of ≥65 meters.

The aerial platform features a maximum working height of 34 meters and an operating radius of up to 21 meters, facilitating access to high-rise buildings and hard-to-reach areas. The work platform can support a load of 400 kg, accommodating rescue personnel and equipment. With a slewing speed of 0.5~1.5 r/min, the platform ensures precise positioning during operations.

This fire engine combines exceptional performance, reliability, and advanced functionality, making it a vital asset for modern fire and rescue services. Its innovative design and capabilities enhance operational efficiency, safety, and effectiveness in combating complex emergencies.

FEATURES

1. Dual Tank Capacity: The vehicle is equipped with a 5,000-liter water tank and a 2,000-liter foam tank, ensuring sufficient firefighting resources for prolonged operations.
2. Impressive Operational Reach: It boasts a 34-meter maximum working height and a 21-meter maximum operating radius, enabling efficient firefighting and rescue operations in high-rise structures.
3. Powerful Firefighting Equipment: The PSKD80 firefighting gun has a rated flow of 50 L/s (±8%), a range of ≥65 meters, and a rated pressure of ≤0.8 MPa, providing robust and accurate firefighting capability.
4. Reliable Performance: The vehicle utilizes a HOWO chassis with a 6×4 drive type, a 351-450 hp engine compliant with EURO V emission standards, and can achieve a maximum speed of ≥90 km/h.
5. High-Capacity Work Platform: The aerial platform has a 400 kg load capacity, allowing safe and efficient transport of rescue personnel and equipment during critical operations.

SPECIFICATION
