HOWO 32M Aerial Ladder Fire Truck

Make/Model:	CSCTRUCK/CSCLFT032
Chassis Model:	HOWO
Overall Dimensions(LxWxH):	11,450×2,500×3,810mm
Total weight:	29,000kg
Max. travel speed:	≥100km/h
Max. net power:	324kW
Rated working height:	32m
Max. working radius:	22m
Rated platform load:	300kg
Water monitor rated flow:	≥48L/s
Water monitor rated reach:	≥55m
Fire-rated flow:	≥60L/s
Fire-rated pressure:	≥1.2MPa

Truck Enquiry

Categories: Aerial Fire Truck, Ladder Fire Truck

Description
Reviews (0)

BRIEF

The HOWO 32M aerial ladder fire truck is built on the HOWO T-type ZZ5357TX-FV464ME1 National-V chassis, designed for city fire-fighting with high-altitude rescue and fire extinguishing capabilities. This fire truck offers excellent mobility, flexibility, and adaptability to various environments, making it suitable for quick and efficient rescue operations. With a high rescue speed and advanced safety features, it is widely used for fire and rescue missions in mid-rise buildings, mines, oil fields, and factories. The HOWO 32M aerial ladder fire truck is essential for extinguishing fires in tall structures, rescuing workers in distress, and protecting valuable property during emergencies. Its versatility and reliable performance make it an indispensable asset for urban fire departments and rescue teams.

FEATURES

● The system offers excellent performance, with the XFan Huayu-type water pump powered by a vacuum pump and a full power takeoff drive for reliable power reserves. It features a Zhangqiu electric-controlled dual-purpose fire monitor for platform water cannons. The inlet, outlet, and control valves are fully equipped and user-friendly. The vehicle includes a 5,150 kg fire tank, 2,750 kg water capacity, and 2,400 kg foam capacity, with lightweight aluminum alloy telescopic pipes.

● The HOWO 32M aerial ladder fire truck utilizes advanced technology based on PLC and CAN bus distributed control systems, providing automatic leveling, real-time load weighing, platform ultrasonic anti-collision detection, gesture-based dynamic monitoring, and one-touch vehicle shutoff.

● Featuring state-of-the-art telescopic winching technology, it includes dual-direction turning and double helical winch mechanisms. It can support 2 simultaneous telescopic systems for enhanced safety. The innovative design incorporates 2 safety limit locations for hydraulic and electrical operations, ensuring safe and reliable vehicle performance.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	11,450
Overall height	mm	3,810
Overall width	mm	2,500
Total weight	kg	29,000
Extinguishant-rated load weight
Water	kg	—
Foam	kg	—
Dry powder	kg	—
Max. travel speed	km/h	≥100
Max. net power	kW	324
Rated working height	m	32
Max. working radius	m	22
Rated platform load	kg	300
Time for deploying boom	s	≤55
Time for deploying outriggers	s	≤25
Monitor
Water monitor-rated flow	L/s	≥48
Water monitor-rated reach	m	≥55
Water pump
Fire-rated flow	L/s	≥60
Fire-rated pressure	MPa	≥1.2
Rated lift load	kg	–
The working speed of the lift	m/s	–
Working range of lift	°	–
