HOWO 20Ton Water and Foam Tower Fire Truck

Make/Model:	CSCTRUCK/TFT020
Water+Foam:	14,500+5,500kg
Overall Dimensions(LxWxH):	11,990×2,500×3,830kg
Total weight:	41,200kg
Max. travel speed:	≥90km/h
Max. net power:	324kW
Rated working height:	20m
Max. working radius:	12.5m
Water monitor rated flow:	≥120L/s
Water monitor rated reach:	≥80m
Fire-rated flow:	≥100L/s
Fire-rated pressure:	≥1MPa

Truck Enquiry

Categories: Aerial Fire Truck, Tower Fire Truck

Description
Reviews (0)

BRIEF

The HOWO 20Ton water and foam tower fire truck produced by CSCTRUCK Fire Rescue Truck is a versatile heavy-duty firefighting truck, built on the robust HOWO ZZ5437V4667E5 National V chassis. This multi-functional main battle truck integrates a water tank, high-pressure sprayer, and foam system, making it highly effective in various firefighting scenarios. It is designed for use in urban areas, industrial settings, mining operations, and petrochemical facilities. Its capabilities are ideal for extinguishing fires in low-rise buildings, oil tanks, warehouses, and other critical infrastructures. With its combination of water and foam extinguishing systems, the HOWO 20Ton water and foam tower fire truck provides a comprehensive solution for tackling a wide range of fire hazards, ensuring safety and protection in complex environments. Its advanced design and reliable performance make it a valuable asset for firefighting teams operating in both city and industrial zones.

FEATURES

● Key operational parameters for home fire safety: The operating height is 20 meters, the operational range is 12 meters, and the carrying capacity is 20,000 kg.

● Enhanced firefighting capability: Equipped with a heavy-duty HOWO truck chassis with a 2-row cab, it can accommodate 6 people. This setup is ideal for large-scale firefighting operations, offering a significant load capacity, ample power reserves, and a specific power rating of 7.9.

● Comprehensive fire system configuration: The vehicle includes a 20,000 kg carbon steel tank, consisting of a 14,500 kg water tank and a 5,500 kg foam tank.

● Efficient and secure operation: The booms, turntables, water monitor, and pump speed are all centrally controlled, allowing for 360° continuous rotation of the turntable. This ensures high efficiency, safety, and comfort during operations. Additionally, the 25-meter wired remote control is ideal for fire incidents involving flammable and explosive materials, offering increased safety for firefighters.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	11,990
Overall height	mm	3,830
Overall width	mm	2,500
Total weight	kg	41,200
Extinguishant-rated load weight
Water	kg	14,500
Foam	kg	5,500
Dry powder	kg	–
Max. travel speed	km/h	≥90
Max. net power	kW	324
Rated working height	m	20
Max. working radius	m	12.5
Time for deploying boom	s	≤70
Time for deploying outriggers	s	≤30
Monitor
Water monitor-rated flow	L/s	≥120
Water monitor-rated reach	m	≥80
Water pump
Fire-rated flow	L/s	≥100
Fire-rated pressure	MPa	≥1
