HOWO 14Ton Water and Foam Tower Fire Truck

Make/Model:	CSCTRUCK/TFT020
Water+Foam:	11,800+2,100kg
Overall Dimensions(LxWxH):	10,620×2,500×3,880kg
Total weight:	32,250kg
Max. travel speed:	≥90km/h
Max. net power:	274kW
Rated working height:	20m
Max. working radius:	12m
Water monitor rated flow:	≥64L/s
Water monitor rated reach:	≥60m
Fire-rated flow:	≥60L/s
Fire-rated pressure:	≥1.2MPa

Truck Enquiry

Categories: Aerial Fire Truck, Tower Fire Truck

BRIEF

The HOWO 14ton water and foam tower fire truck produced by CSCTRUCK Fire Rescue Truck is a versatile firefighting vehicle based on the heavy-duty HOWO ZZ5347V4647E5 Class II automotive chassis. Designed for multifunctional use, this main battle truck integrates a water tank, high-spraying capabilities, and foam application, making it ideal for a wide range of firefighting operations. It is particularly suited for extinguishing fires in low-rise buildings, industrial sites, mining enterprises, petrochemical facilities, oil tanks, and warehouses. Its robust design ensures reliable performance in demanding environments, allowing for efficient fire suppression in urban areas and industrial and hazardous locations. The HOWO 14ton water and foam tower fire truck is an essential asset for fire departments, offering flexibility and effectiveness in various emergencies.

FEATURES

– Powerful firefighting capability: Equipped with a heavy-duty HOWO 2-row cab chassis, the water and foam tower fire truck can accommodate 6 people, making it ideal for organized firefighting operations.

– Comprehensive fire system configuration: The vehicle features a carbon steel tank with a total capacity of 13,900 kg, including an 11,800 kg water tank and a 2,100 kg foam tank.

– Convenient and efficient operation with enhanced safety: All key functions—such as boom movement, turntable rotation, water monitor control, and pump speed—are centrally managed. The system allows for 360° continuous hydraulic rotation, ensuring high operational efficiency, safety, and comfort. Additionally, a 40-meter wired remote control makes it ideal for handling fires in flammable and explosive environments, offering better protection for firefighters.

– Ergonomic design with multiple safety features and a high degree of intelligence.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	10,620
Overall height	mm	3,880
Overall width	mm	2,500
Total weight	kg	32,250
Extinguishant-rated load weight
Water	kg	11,800
Foam	kg	2,100
Dry powder	kg	–
Max. travel speed	km/h	≥90
Max. net power	kW	274
Rated working height	m	20
Max. working radius	m	12
Time for deploying boom	s	≤45
Time for deploying outriggers	s	≤20
Monitor
Water monitor-rated flow	L/s	≥64
Water monitor-rated reach	m	≥60
Water pump
Fire-rated flow	L/s	≥60
Fire-rated pressure	MPa	≥1.2
