HOWO 11Ton Water and Foam Tower Fire Truck

Make/Model:	CSCTRUCK/TFT025
Water+Foam:	7,500+3,500kg
Overall Dimensions(LxWxH):	11,600×2,500×3,870kg
Total weight:	32,350kg
Max. travel speed:	≥95km/h
Max. net power:	274kW
Rated working height:	25m
Max. working radius:	13m
Water monitor rated flow:	≥120L/s
Water monitor rated reach:	≥80m
Fire-rated flow:	≥100L/s
Fire-rated pressure:	≥1MPa

Truck Enquiry

Categories: Aerial Fire Truck, Tower Fire Truck

Description
Reviews (0)

BRIEF

The HOWO 11ton water and foam tower fire truck produced by CSCTRUCK Fire Rescue Truck is built on the HOWO ZZ5347V4647E5 National-V chassis and serves as a versatile, multi-function fire truck. It integrates a water tank, high-pressure spraying system, and foam capabilities, making it well-suited for a variety of fire emergencies. This main battle truck is especially effective in dealing with fires in high-rise buildings, industrial facilities, mining operations, petrochemical engineering sites, oil storage tanks, warehouses, and more. Its design allows it to tackle challenging firefighting scenarios, providing essential firefighting resources in a single vehicle. The HOWO 11ton water and foam tower fire truck is designed for urban environments and heavy-duty industrial use, where its advanced features can be utilized to handle complex fire hazards quickly and efficiently. Its robust engineering ensures reliability and performance, making it a vital tool for fire departments and emergency response teams in high-risk settings.

FEATURES

– It has excellent fire extinguishing capabilities, featuring a large-bore aluminum alloy telescopic pipe that is lightweight and reduces system pressure. It can achieve a spray flow of up to 80 liters per second at maximum height.

– Equipped with a large tank, it holds 7,500 kg of water and 3,500 kg of foam.

– The 2-row cab accommodates up to 6 firefighters.

– The aluminum alloy frame of the storage compartment ensures light weight and superior corrosion resistance.

– The non-metallic, one-piece control panel and trunk feature a sleek design for easy and comfortable operation.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	11,600
Overall height	mm	3,870
Overall width	mm	2,500
Total weight	kg	32,350
Extinguishant-rated load weight
Water	kg	7,500
Foam	kg	3,500
Dry powder	kg	–
Max. travel speed	km/h	≥95
Max. net power	kW	274
Rated working height	m	25
Max. working radius	m	13
Time for deploying boom	s	≤60
Time for deploying outriggers	s	≤30
Monitor
Water monitor-rated flow	L/s	≥120
Water monitor-rated reach	m	≥80
Water pump
Fire-rated flow	L/s	≥100
Fire-rated pressure	MPa	≥1
