BRIEF
The HOWO 10CBM pumper fire engine, manufactured by CSCTRUCK Fire Rescue Truck, is a high-performance vehicle designed for urban and industrial fire suppression. Built on the HOWO/ZZ1257N4341W chassis, this 6×4 drive type fire truck offers excellent maneuverability and stability, making it suitable for various emergency response scenarios.
The fire truck is powered by the WD615.69 engine and delivers 336 horsepower, the fire truck meets the Euro 3 emission standard, ensuring efficient performance with reduced environmental impact. The vehicle is equipped with a 10,000-liter (10CBM) water tank, providing ample firefighting capability for prolonged operations.
At the heart of its firefighting system is the CB10/60 fire pump, capable of delivering a 60L/S flow rate at a pressure of 1.0 MPa. With a 7-meter suction depth, the pump efficiently sources water from external supplies when necessary. The truck also features a PS8/50W fire monitor, offering a 40L/S flow rate at 0.8 MPa pressure, with an impressive fire suppression range of ≥65 meters. The fire monitor has a horizontal 360° rotation and a pitch adjustment from -35° to 70°, allowing flexible water jet direction for optimal fire control.
The HOWO 10CBM pumper fire engine is engineered for reliability and high performance, making it an ideal choice for municipal fire departments and industrial firefighting applications. Its robust construction, powerful engine, and efficient firefighting equipment ensure effective fire suppression in emergencies.
FEATURES
- High-Capacity Water Tank & Pump System – Equipped with a 10 CBM (10,000 liters) water tanker and a CB10/60 fire pump capable of delivering 60 liters per second at 1.0 MPa pressure, ensuring effective firefighting performance.
- Powerful Fire Monitor – The PS8/50W fire monitor provides a 40 L/S flow rate, 0.8 MPa pressure, and a ≥65m spray range, with a 360° horizontal rotation and -35° to 70° pitch angle, offering versatile fire suppression capabilities.
- Robust HOWO Chassis – Built on a HOWO/ZZ1257N4341W chassis with a 6×4 drive type, ensuring high durability, stability, and adaptability for various terrains and emergency conditions.
- Strong & Efficient Engine – Powered by a WD615.69 diesel engine with 336hp, meeting Euro 3 emission standards, providing reliable performance and compliance with environmental regulations.
- Excellent Suction & Drafting Capability – With a 7m suction depth, the fire pump can draw water efficiently from external sources like lakes, rivers, or reservoirs, enhancing operational flexibility in remote firefighting scenarios.
SPECIFICATION
Vehicle Description |
|||||
Overall dimensions(LxWxH) | 9,240*2,480*3,030mm | ||||
GVW | 25,000kg | ||||
Curb weight | 16,000kg | ||||
Chassis brand | SINOTRUK HOWO | ||||
Traction type | 6*4, left/right hand drive | ||||
Chassis Description |
|||||
Chassis model | ZZ1257N4341W | ||||
Cab | HW76 cabin, flat roof with 1 sleeper, A/C, ABS | ||||
Wheelbase | 4,300+1,350mm | ||||
Tire specification | 12R22.5 | ||||
Tire quantity | 10+1 units | ||||
Engine | Engine model | WD615.69 | |||
Emission level | Euro 3 (EGR) | ||||
Displacement/output | 9,726ml/247kW | ||||
Horse power | 336hp | ||||
Gear box | Model | HW19710 | |||
Number of gears | 10 forward gears& 2 reverse | ||||
Brake system | Type | Drum | |||
Service brake | Dual-circuit compressed air brake | ||||
Park brake | Power spring brake acting on rear wheel | ||||
Auxiliary brake | WEVB | ||||
Axle | Front | HF-7T | |||
Rear | ST-16T | ||||
Suspension | Front | Semi-elliptic leaf spring | |||
Rear | Trapezoidal leaf spring | ||||
Fuel tanker | Type | Steel fuel tanker | |||
Capacity | 400L | ||||
Up-parts Description |
|||||
Tanker capacity | Water tanker | 10CBM | |||
Foam tanker | / | ||||
Standard configuration | 1 set manhole with quick lock and open device; 1 set overflow device; 1 set fluid level gauge; 1 set drain outlet with manual control. |
||||
Fire pump | Model | CB10/60, normal pressure pump | |||
Flow | 60L/S | ||||
Pressure | 1.0Mpa | ||||
Suction depth | 7m | ||||
Fire monitor | Model | PS8/50W | |||
Flow | 40L/S | ||||
Pressure | 0.8Mpa | ||||
Range | ≥65m | ||||
Rotation angle | Horizontal 360° Pitch -35°~70° |
||||
Other configuration | Equipped with sandwich PTO, pipeline system; Equipped with equipment box and pump box; Equipped with flip pedal and electric system. Other equipment. |
