BRIEF
The FOTON Auman 12 CBM pumper fire engine, produced by CSCTRUCK Fire Rescue Truck, is a high-performance firefighting vehicle designed for rapid response and efficient fire suppression. Built on a FOTON Auman chassis with a 6×4 drive configuration, this fire engine is engineered for durability and stability, ensuring reliable operation in demanding conditions.
Equipped with a WP10.270 engine, delivering 270 horsepower and compliant with the Euro III emission standard, the fire truck can reach a maximum driving speed of 90 km/h, allowing for quick deployment to emergency scenes.
The fire engine features a 9CBM carbon steel water tank and a 2.655CBM carbon steel foam tank, providing ample firefighting capacity. It is fitted with a CB30/60 fire pump, delivering a rated flow of 60L/s at 1.0 MPa pressure, ensuring strong and consistent water supply.
For effective firefighting, the vehicle is equipped with a PL48 fire monitor, capable of handling pressures between 1.0–1.2 MPa and providing a flow rate of 48L/s. The monitor boasts an impressive fire suppression range of ≥65 meters for water and 60 meters for foam. It features a 360° rotation angle with a vertical adjustment range of -30° to 80°, offering superior targeting flexibility.
This FOTON Auman 12 CBM pumper fire engine is designed for urban and industrial firefighting applications, delivering robust water and foam discharge capabilities. Its high-capacity tanks, powerful pumping system, and flexible fire monitor make it an essential asset for fire departments and emergency response teams, ensuring rapid and effective fire suppression in critical situations.
FEATURES
- High-Capacity Water & Foam Tanks – Equipped with a 9 CBM (carbon steel) water tank and a 2.655 CBM (carbon steel) foam tank to ensure sufficient firefighting resources.
- Powerful Engine & Chassis – Built on a FOTON Auman chassis with a WP10.270 engine delivering 270HP and compliant with the Euro III emission standard, ensuring reliable performance.
- Strong Pumping System – Features a CB30/60 fire pump with a 60L/s rated flow at 1.0 MPa pressure, providing efficient water delivery for firefighting operations.
- Advanced Fire Monitor – Equipped with a PL48 fire monitor offering a 1.0-1.2 MPa pressure, 48L/s flow rate, and an extensive reach of ≥65m (water) / 60m (foam), with a 360° horizontal and -30° to 80° vertical rotation range.
- Robust Driving System – Utilizes a 6×4 drive type for enhanced traction and stability, achieving a maximum driving speed of 90 km/h, ensuring rapid response to emergency situations.
SPECIFICATION
| Model No. | CSCPFE012 | ||
| Drive Model | 6×4 | ||
| Chassis | BJ1253VLPJE | ||
| Fact cubage | 11.655 CBM (Water tank: 9CBM, foam tank 2.655CBM) | ||
| Vehicle Main Dimensions | Dimensions(LxWxH)(mm) | 9,905×2,480×3,500 | |
| Wheel base(mm) | 4,300+1,350 | ||
| Overhang (front/rear) (mm) | 1,555/2,600 | ||
| Wheel track (front/rear) (mm) | 2,005/1,865/1,865 | ||
| Approach/Departure angle(°) | 18/16 | ||
| Weight in KGS | Curb Weight | 12,040 | |
| GVW. | 24,490 | ||
| Max. driving speed(km/h) | 90 | ||
| Engine | Model | WP10.270 | |
| Type | 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging, and inter-cooling | ||
| Horse Power(HP) | 270 | ||
| Engine capacity(ml) | 199 | ||
| Emission standard | Euro III | ||
| Gearbox | 8 forwards & 1 reverse | ||
| Clutch | Reinforced diaphragm clutch | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Fuel tank (L) | 200 | ||
| Tire | 12.00R20, 10pcs + 1spare | ||
| Brakes | Dual circuit compressed air brake | ||
UPPER |
|||
| Water tank Volume | 9 CBM | ||
| Foam tank Volume | 2.655 CBM | ||
| Loading Capacity | 11.655 CBM | ||
| Protective material | Carbon steel | ||
Key Equipment |
|||
| Fire Pump | Mode | CB30/60 | |
| Flow | 60L/s | ||
| Pressure | 1.0Mpa | ||
| Fire Monitor | Mode | PL48 | |
| Pressure | 1.0-1.2MPa | ||
| Flow | 48L/S | ||
| Fire Distance(water/foam) | ≥65m/60m | ||
| Rotation Angle(°) | 360/-30~80. | ||
