Benz 80M Water Tower Fire Truck

BRIEF

The Benz 80M water tower fire truck, produced by CSCTRUCK Fire Rescue Truck, is a specialized firefighting vehicle designed for high-rise and large-scale fire rescue operations. With a remarkable maximum working height of 80 meters, it provides exceptional reach for tackling fires in tall buildings and other structures. The truck’s maximum operating radius extends to 26 meters, ensuring flexibility and coverage in complex rescue scenarios.

The fire truck is built on a Benz chassis with an 8×4 drive configuration, allowing for excellent maneuverability and stability, even in challenging terrains. The vehicle is powered by a 435hp engine, offering a top speed of ≥90km/h, which is crucial for rapid response times in emergencies. The truck adheres to the Euro 4 emission standard, ensuring environmentally responsible operation.

Equipped with a 2,900-liter water tank, the truck is capable of carrying and deploying substantial amounts of water during firefighting missions. The onboard fire fighting pump boasts an impressive rated flow of 50L/s with a rated pressure of 1.6MPa, allowing it to deliver a powerful stream of water to extinguish fires effectively. The 3578+3626 firefighting guns, each capable of a rated flow of 48L/s and a pressure of 0.8MPa, offer a range of 60 meters, making them suitable for tackling fires from a distance while maintaining precision and force.

The vehicle’s maximum slewing speed ranges from 0.5 to 1.5 revolutions per minute (r/min), providing controlled movement of the water tower to direct the firefighting equipment accurately. The Benz 80M water tower fire truck is a versatile and high-performance machine, ideal for handling extreme firefighting scenarios in urban and industrial environments.

FEATURES

1. High Reach and Extended Operational Range: The fire truck features an impressive 80-meter maximum working height and a 26-meter maximum operating radius, allowing for efficient firefighting in high-rise buildings and difficult-to-reach locations.
2. Powerful Firefighting System: Equipped with a 50L/s rated flow fire fighting pump and a 1.6MPa rated pressure, this truck can deliver a strong and consistent water stream. The firefighting gun also has a 48L/s flow rate and a range of up to 60 meters, ensuring effective coverage.
3. Robust Engine and Drive System: Powered by a 435hp engine, the truck can reach a maximum speed of ≥90km/h, while the 8×4 drive type ensures reliable traction and stability, even on challenging terrain.
4. Durable and Efficient Design: The truck is built on a sturdy Benz chassis and adheres to Euro 4 emission standards, providing a balance between performance and environmental responsibility.
5. Advanced Maneuverability: The water tower has a maximum slewing speed of 0.5 to 1.5r/min, allowing for precise and quick adjustments to the positioning of the firefighting equipment during an emergency.

SPECIFICATION
