BRIEF
The Benz 6×6 ARFF (Aircraft Rescue Firefighting) airport fire truck, manufactured by CSCTRUCK Fire Rescue Truck, is a high-capacity firefighting vehicle designed specifically for airport operations. Built on a sturdy Benz chassis with a 6×6 drive type, it boasts exceptional off-road mobility essential for navigating airport terrain. Powered by the robust OM473 engine model, it delivers 426 kW at 1,600 rpm, adhering to Euro VI emission standards to minimize environmental impact. With a full loading weight of 28,100 kg, this vehicle can reach a maximum speed of 100 km/h, ensuring rapid response times during emergencies.
The firefighting capabilities of this ARFF truck are notable. It carries a substantial 10,000-liter water tank alongside a 1,000-liter foam tank made from durable PP composite material, ensuring high capacity for extensive firefighting operations. The fire pump provides an impressive flow rate of 100 liters per second at 10 bar pressure, supporting both a front-mounted monitor with a 20 L/s flow rate and a powerful roof-mounted monitor capable of 80 L/s. With a shooting range exceeding 85 meters for both water and foam, the truck is capable of tackling large fires from a distance, adding a significant safety margin for operators.
This Benz 6×6 ARFF (Aircraft Rescue Firefighting) airport fire truck exemplifies advanced engineering in airport fire response, providing a balanced combination of power, capacity, and safety features tailored to meet the rigorous demands of modern aviation firefighting.
FEATURES
1. High Capacity Water and Foam Tanks: Equipped with a 10,000L water tank and a 1,000L foam tank, allowing for extended firefighting capability without frequent refills.
2. Powerful Engine and High-Speed Capability: Built on a Benz chassis with an OM473 engine model, delivering 426kW at 1,600rpm, achieving a maximum speed of 100km/h—ideal for rapid emergency response.
3. Robust Firefighting Equipment: Features a high-capacity fire pump with a flow rate of 100L/s at 10 bar pressure, a front monitor with a 20L/s flow rate, and a roof-mounted monitor with an impressive 80L/s flow rate for effective fire suppression.
4. Extended Range for Water and Foam Projection: The truck’s water and foam can reach distances of 85 meters, making it suitable for reaching large fire sources from a safe distance.
5. Durable Tank Construction: The tanks are made from PP composite material, enhancing their durability and resistance to corrosion, and ensuring long service life in demanding airport environments.
SPECIFICATION
| No. | Main Items | Technical Parameters |
| 1 | Model | CSCARFFT011 |
| 2 | Overall Dimension | 9,800×2,600×4,050mm |
| 3 | Full Load Weight | 28,100kgs |
| 4 | Number of the Crew | 2 (include driver) |
| 5 | Max. Speed | 100km/h |
| 6 | Capacity | 10,000L Water & 1,000L Foam. PP composite material liquid tank. |
| 7 | Fire pump flow rate | 100L/s@10bar |
| 8 | Fire monitor | Front-mounted monitor 20L/s, roof-mounted monitor 80L/s. |
| 9 | Painting | Fire Red |
Chassis
- Manufacturer: Benz
- Model: Arocs 3358E6 6×6
- Drive Type: 6*6
- Wheelbase: 4,450mm+1,450mm
- Engine model: OM473
- Engine type: In-line 6-cylinder turbocharged inter-cooled diesel engine
- Rated power: 426/1,600(kW/rpm)
- Gearbox form: 16 forward gears + 4 reverse gears, mechanical automatic transmission
- Fuel tank capacity: 290L aluminum fuel tank
- Emission standards: Euro VI
Superstructure / Upper Body
| No. | Main Items | Technical Parameters |
| 1 | Cabin | |
| 1.1 | Structure | Single row cabin with 2 doors |
| 1.2 | Seats | 2 seats with 3-point safety belt. |
| 2 | Standardized Sub-frame | |
| 2.1 | Material | High-strength rectangular tube made of special steel |
| 2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats. |
| 3 | Compartment | |
| 3.1 | Material | High-strength aluminum alloy profiles |
| 3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear. |
| 4 | Roller Shutter Door | |
| 4.1 | Material | Aluminum alloy profiles with anodized surface |
| 4.2 | Structure | With a rain-proof groove on the top, a lever-type bar, a lock handle, a pull strap, a two-point fixed seat, an LED light, and sensors. |
| 5 | Superstructure Electric Appliance | |
| 5.1 | Warning Light and Siren | Long-row warning lights and sirens are mounted above the cabin. The controller is installed in the driver’s cabin. |
| 5.2 | Strobe Light | Mounted on both sides of the compartment |
| 5.3 | External Lighting | LED lights are mounted on both sides of the compartment |
| 5.4 | Roof Lighting | LED lights are mounted on the inside of the roof |
| 5.5 | Side Indicator Light | The inline yellow warning light is mounted on the side of the compartment and the pedals. |
Fire Extinguishing System
1 Fire Pump
- Flow Rate: 100L/s @ 10bar
- Vacuum Pump: Electric vacuum pump
- Priming Manner: Automatic
- Suction Height: 7m
- Priming Time: ≤100s
- Location: Rear-mounted
2 Fire Monitor
- Flow Rate: 80L/s @ 10bar
- Shoot Range: Water ≥ 85 m, Foam ≥ 85m
- Location: On the top of the tank
- Control Manner: Electric remote control
- Horizontal Rotation Angle 0°~340°
- Pitch Rotation Angle: -15°~70°
3 Liquid Tank
- Capacity: Water 10,000L, Foam 1,000L.
- Material: PP composite material and Never Rust.
- Structure: Two Tank Manholes; Two Overflow Devices/Pressure Relief Devices; Two Liquid Level Indicators; One Foam tank Drain Outlet with Valves; One Water tank Drain Outlet with Valves.
4 Control Panel
It adopts advanced CANBUS 2.0 bus control technology and is equipped with a pump room operation control panel and a handheld wireless operation terminal, which can realize functions such as one-click water dispensing, stable flow and pressure, and automatic adjustment of foam ratio.
