BRIEF
The Benz 32M water tower aerial fire truck, produced by CSCTRUCK Fire Rescue Truck, is a highly specialized firefighting vehicle equipped to handle significant fire emergencies. Built on a durable Mercedes-Benz 6×4 chassis, this aerial fire truck provides excellent stability and off-road capability. It has a maximum working height of 32 meters, allowing it to effectively reach high-rise buildings and other challenging structures.
Designed with a large capacity for firefighting resources, this fire truck carries a 5,000-liter water tank and a 2,000-liter foam tank made from PP composite material, which is lightweight and corrosion-resistant, ensuring durability in tough conditions. The truck’s fire pump offers a flow rate of 100 liters per second at 10 bar pressure, delivering a powerful stream to combat fires efficiently. It also features a fire monitor flow rate of 950-5,700 liters per minute with a shooting range of over 70 meters for water and 60 meters for foam, enabling the truck to tackle fires from a safe distance.
Weighing in at 33,000 kilograms fully loaded, this truck can reach speeds up to 90 km/h and has a maximum working radius of 20 meters. These specifications make the Benz 32M water tower aerial fire truck a robust and effective tool for firefighting, combining height, power, and volume to address large-scale emergencies and complex fire scenarios.
FEATURES
1. High Working Height and Radius: The truck has a maximum working height of 32 meters and a working radius of up to 20 meters, making it suitable for high-rise firefighting and rescue operations.
2. Large Water and Foam Capacity: It is equipped with a 5,000-liter water tank and a 2,000-liter foam tank, ensuring an extended supply of firefighting agents for prolonged operations.
3. Powerful Fire Pump and Monitor: The fire truck has a fire pump flow rate of 100 liters per second at 10 bar, and the fire monitor can deliver between 950 to 5,700 liters per minute, reaching distances of up to 70 meters for water and 60 meters for foam.
4. Robust Chassis and Drive: Built on a Mercedes-Benz chassis with a 6×4 drive type, it is designed for stability and maneuverability, even with a full load of 33,000 kg, and can reach a maximum speed of 90 km/h.
5. Durable Composite Material Tank: The water and foam tanks are made from PP composite material, which offers high corrosion resistance and enhances the durability of the vehicle in demanding firefighting environments.
SPECIFICATION
No. | Main Items | Technical Parameters |
1 | Model | CSCTFT032 |
2 | Overall Dimensions(LxWxH) | 10,850×2,500×3,980mm |
3 | Full Loading Weight | 33,000kgs |
4 | Number of the Crew | 1+1(Including Driver) |
5 | Max. Speed | 90km/h |
6 | Capacity | 5,000 Liters Water & 2000 Liters Foam. PP composite material liquid tank. |
7 | Fire pump flow rate | 100L/s@10bar |
8 | Fire monitor | 950-5,700L/min Adjustable with 70m shoot range |
9 | Max. working height | 32 Meters |
Aluminum Superstructure
No. | Main Items | Technical Parameters |
1 | Cabin | |
1.1 | Structure | Single row cabin with 2 doors |
1.2 | Seats | 1+1, with a 3-point safety belt |
2 | Standardized Sub-frame | |
2.1 | Material | High-strength rectangular tube made of special steel |
2.2 | Performance | The liquid tank and the sub-frame are connected by elastic connecting seats |
3 | Compartment | |
3.1 | Material | High-strength aluminum alloy profiles (Never Rust) |
3.2 | Structure | Aluminum alloy welded structure. Roof railing with LED light. With an aluminum alloy ladder in the rear |
4 | Roller Shutter Door | |
4.1 | Material | Aluminum alloy profiles with anodized surface |
4.2 | Structure | With a rain-proof groove on the top, a lever-type bar, a lock handle, a pull strap, a two-point fixed seat, LED light, and sensors. |
5 | Foot Pedals | |
5.1 | Material | High-quality aluminum alloy |
5.2 | Structure | 50cm width, bears more than 300kg, anti-slip design, with double lock function. Mounted on both sides of the compartment. |
Fire Extinguishing System
1 Centrifugal Fire Pump
- Rated Flow Rate: 100L/s @ 10bar
- Vacuum Pump: Electric vacuum pump
- Priming Manner: Automatic
- Suction Height: 7m
- Priming Time: ≤80s
- Location: Rear-mounted
2 Roof Fire Monitor on Boom
- Flow Rate: 950-5700L/min.
- Shoot Range: Water ≥ 70 m, Foam ≥ 60 m
- Location: On the top of the boom
- Control Manner: Remote control
- Horizontal Rotation Angle: 0°~355°
- Pitch Rotation Angle: -45°~120°
3 Water and Foam Tank
- Capacity: Water 5,000 Liters and Foam 2,000 Liters
- Material: PP composite material and Never Rust
- Structure: Two Tank Manholes; One Overflow Device/Pressure Relief Device; Two Liquid Level Indicators; One Foam tank Drain Outlet with Valves; One Water tank Drain Outlet with Valves.
