8Ton Combined Fire Truck

Make/Model:	CSCTRUCK/CSCCFT080
Water+Foam+Dry Powder:	6,000+200/300(A/B)+800kg
Overall Dimensions(LxWxH):	11,500×2,540×3,950mm
Total weight:	31,500kg
Max. travel speed:	≥100km/h
Max. net power:	338kW
Water monitor rated flow:	80L/S
Water Reach:	≥80m
Foam Reach:	≥75m
Dry Powder Reach:	≥25m
Dry Foam Flow:	1.5L/S
Wet Foam Flow:	12L/S
Dry Foam Reach:	3m
Wet Foam Reach:	20m

Truck Enquiry

Categories: Combined Fire Truck, Tanker Fire Truck

Description
Reviews (0)

BRIEF

The 8Ton combined fire truck produced by CSCTRUCK Fire Rescue Truck is a versatile fire truck designed for urban environments, integrating the functions of an emergency rescue truck, powder fire truck, foam fire truck, and compressed air foam truck. To tackle complex fire situations, it can deploy various extinguishing agents such as water, foam A, foam B, and powder, either individually or in combination. The 8Ton combined fire truck can also provide high-pressure water and foam mixtures for firefighting in high-rise buildings. It is equipped with power generation, lighting, and a full set of hydraulic demolition tools for emergency rescue operations. With its high mobility, wading capability, and intelligent control systems, the 8Ton combined fire truck is the first to be dispatched for fires in public venues, residential buildings, and shopping centers, as well as for urban emergencies like traffic accidents, building collapses, earthquakes, and rescue missions.

FEATURES

– Versatile Extinguishing Capability: Equipped with both a high-pressure and general-pressure fire pump, as well as a CAFS (Compressed Air Foam System), this vehicle is designed to handle a range of fire scenarios. It can efficiently operate under normal pressure conditions using hoses and fire nozzles, supply water and foam to high-rise buildings, and collaborate with water and foam tower fire trucks in joint operations.

– Simple and Fast Intelligent Control: The 8Ton combined fire truck features a controller and large display screen, providing a one-button control system that integrates various firefighting operational modes for streamlined operation.

– Powerful Performance and Excellent Mobility: The vehicle boasts strong power, exceptional off-road capabilities, and impressive fording performance, making it suitable for challenging terrains.

– Optimal Carrying Capacity: With a double-row crew cab, the fire truck can transport up to 8 personnel, enabling rapid response and deployment of a large firefighting team to handle various fire emergencies and accidents.

SPECIFICATION

Category	Item		Unit	Parameter
Dimension	Overall length		mm	11,500
	Overall height		mm	3,950
	Overall width		mm	2,540
Weight	Total weight		kg	31,500
	Extinguishant-rated load weight	Water	kg	6,000
		Foam	kg	200/300(A/B)
		Dry powder	kg	800
Travel performance	Max. travel speed		km/h	100
	Max. net power		kw	338
	Power density		—	10.7
Fire-fighting performance	Monitor Water monitor rated flow	Water	L/s	80
		Foam	L/s	80
		Dry powder	kg/s	7
	Monitor Rated reach	Water	m	80
		Foam	m	75
		Dry powder	m	25
	Water pump Fire-rated flow	low-pressure	L/s	120
	Water pump Fire-rated flow	high-pressure	L/s	25
	Water pump Fire-rated pressure	low-pressure	mPa	1
	Water pump Fire-rated pressure	high-pressure	MPa	4
	Air/foam compressor system	Dry foam flow	L/S	1.5
		Wet foam flow	L/S	12
		Dry foam reach	m	3
		Wet foam reach	m	20
