BRIEF
The 6×6 wildland fire engine with a 6-ton PALFINGER crane, produced by CSCTRUCK Fire Rescue Truck, is a high-performance multifunctional emergency response vehicle designed for rugged and off-road firefighting, rescue, and recovery operations. Built on a FAW 6×6 chassis, this rescue fire engine offers superior mobility and traction in harsh terrain conditions such as forests, mountains, and disaster zones. Its 261 kW engine power at 1900 rpm enables a maximum driving speed of 95 km/h, ensuring fast deployment and reliable performance even under challenging environments.
A standout feature of this vehicle is the PALFINGER AG/PK12000 crane, which provides a maximum lifting capacity of 6 tons and an operation range of up to 8 meters. This crane is highly versatile for lifting heavy equipment, clearing obstacles, or rescuing trapped vehicles during emergency operations. The vehicle is also equipped with a FEW-16500 winch offering 70 kN maximum traction and a 30 meter towing length, further enhancing its recovery capabilities in rough terrain.
For illumination and auxiliary power needs, the truck includes an SHT11500 generator with 10 kW rated power and 50 Hz frequency, capable of supporting lighting, tools, and other electrical devices on-site. Complementing this system is the YZH2-5.5CA telescopic lighting unit, which features 4×500W lamps and can extend up to 8 meters above the ground, providing bright and extensive lighting coverage for night operations or low-visibility conditions.
Overall, the 6×6 wildland fire engine integrates firefighting, rescue, lifting, towing, and lighting capabilities into one robust and efficient platform. It is purpose-built for emergency response teams who require a powerful, adaptable, and dependable vehicle for extreme firefighting and rescue missions.
FEATURES
- High Mobility and All-Terrain Capability
Built on a robust FAW 6×6 chassis, this wildland fire engine provides exceptional off-road performance, ensuring reliable access to remote and rugged terrains where wildfires commonly occur. Its 6×6 drive configuration enhances traction and stability in challenging conditions. - Powerful Performance and Speed
Equipped with a 261 kW engine operating at 1,900 rpm, the truck delivers strong power output and can reach a maximum speed of 95 km/h, allowing for rapid deployment to emergency sites and efficient response operations. - Versatile 6-Ton PALFINGER Crane
The integrated PALFINGER AG/PK12000 crane offers a maximum lifting capacity of 6 tons and an operation range of up to 8 meters, providing reliable support for heavy lifting tasks such as clearing debris, moving equipment, or aiding rescue operations. - Integrated Winch and Towing System
The FEW-16500 winch provides a maximum traction of 70 kN and a towing length of 30 meters, enhancing the vehicle’s recovery and support capabilities during emergency and rescue missions in off-road environments. - Advanced Lighting and Power Systems
The onboard SHT11500 generator delivers 10 kW of rated power at 50 Hz, supporting auxiliary equipment and lighting systems. The YZH2-5.5CA telescopic light, with 4 × 500 W lamps and an 8-meter elevation, ensures optimal illumination for nighttime firefighting and rescue operations.
SPECIFICATION
1. 6×6 Wildland Fire Engine with Rescue Equipment
| No. | Main Items | Technical Parameters |
| 1.1 | Model | CSCWFE006 |
| 1.2 | Overall Dimension(LxWxH) | ≤10,150mm×2,550mm×3,700mm |
| 1.3 | Max. Load Weight | ≤17,500kg |
| 1.4 | Number of the Crew | 2+4 (including driver) |
| 1.5 | Max. Speed | 95km/h |
| 1.6 | Painting | Fire Red |
2. Superstructure Parameters
| Section | Item | Material | Structure / Description | Layout / Location |
|---|---|---|---|---|
| 2.1 Compartment | Frame & Panels | High-strength aluminum alloy profiles | All-aluminum welded frame with bonded aluminum alloy outer skin | — |
| Roof Guard | Aluminum alloy | Integrated roof guard with strobe warning lights, exterior lights, and interior LED roof lights | Top of vehicle | |
| Ladder | Aluminum alloy safety ladder | Provides safe access to the roof | Left side of the vehicle | |
| 2.2 Roller Shutter | Shutter Panels | Lightweight high-quality aluminum alloy | Equipped with a top diversion groove and a full sealing strip for rainproof and dustproof performance | Sides of the equipment box and the rear pump room |
| 2.3 Foot Pedal | Pedal Platform | High-quality aluminum alloy profile | 50 cm wide, integral drawn structure, load-bearing capacity > 150 kg | Below the equipment box and the pump room |
| 2.4 Electrical System | Warning Lights | — | Long-row warning lights on the roof, cab-controlled | Top of cab |
| Equipment Box Lights | — | LED white lighting strips on both sides, auto-linked with roller shutter switches | Equipment box interior | |
| Strobe Lights | — | Mounted on the upper parts for visibility | Upper section | |
| Exterior Lighting | — | LED exterior lights for illumination | Upper compartment | |
| Roof Lighting | — | Internal LED lights on carriage ceiling | Inside roof | |
| Side Indicator Lights | — | Built-in yellow indicator lights are integrated on the pedals | Pedal sides |
3. Rescue Equipment
| No. | Main Items | Technical Parameters |
| 3.1 | Crane | |
| 3.1.1 | Brand | PALFINGER AG |
| 3.1.2 | Model | PK12000 |
| 3.1.3 | Max. Lifting Weight | 6 Tons |
| 3.1.4 | Maximum lifting weight(Fully Extracted) | 1,300kg |
| 3.1.5 | Max. Operate Range | 8 Meters |
| 3.1.6 | Swivel angle | 400° |
| 3.1.7 | Installation Type | The rear of the vehicle and the longitudinal centerline of the vehicle |
| 3.2 | Winch | |
| 3.2.1 | Brand | Hangzhou Tianming Electromechanical Tools Co., Ltd |
| 3.2.2 | Model | FEW-16500 |
| 3.2.2 | Installation Type | Under the front bumper |
| 3.2.3 | Drive Type | Electric |
| 3.2.4 | Voltage | 24V |
| 3.2.5 | Max. Traction | 70kN |
| 3.2.6 | Max. Towing length | 30 meters |
| 3.3 | Generator | |
| 3.3.1 | Brand | Sawato Electric Co., Ltd. |
| 3.3.2 | Model | SHT11500 |
| 3.3.3 | Drive Type | Gasoline Generator |
| 3.3.4 | Rated Power | 10 kW |
| 3.3.5 | Rated Frequency | 50 Hz |
| 3.3.6 | Rated Voltage | 220 V |
| 3.3.7 | Location | In the storage compartment |
| 3.4 | Telescopic Light | |
| 3.4.1 | Brand | Wilbert Corporation of America |
| 3.4.2 | Model | YZH2-5.5CA |
| 3.4.3 | Power | 4x500W |
| 3.4.4 | Lamp | LED |
| 3.4.5 | The Max. Height | 8 Meters from the ground |
| 3.4.6 | Rotation Angle | Horizontal 360°, pitch ≥-90°, tilt ≥180° |
| 3.4.7 | Working Voltage | 220V |
| 3.4.8 | Installation Type | On the top |
