6×6 Combination Rescue Fire Truck

Model No.:	CSCCRFT016
Overall Dimensions(LxWxH):	11,880×2,550×4,000mm
Drive Type:	6×6
Wheelbase:	5,200+1,650mm
Winch Pull:	10t
Wire rope length:	48m
Max. speed:	100km/h
Hydraulic tail-plate lifting weight:	2,000kg
Hydraulic tail-plate lifting height:	1,550mm
Lighting power:	4×1,000W
Crew capacity:	8
Max. gradability:	60%

Truck Enquiry

Categories: Combination Rescue Truck, Rescue Fire Truck

Description
Reviews (0)

BRIEF

The 6×6 combination rescue fire truck produced by CSCTRUCK Fire Rescue Truck is a heavy-duty rescue unit designed for high mobility, modularity, and intelligence. It carries over 138 types of equipment, with more than 700 individual pieces, making it versatile for various rescue operations. This vehicle serves multiple roles: as a lead vehicle at rescue scenes, providing lighting, pathways for survival, and search and rescue support. It can also function as a logistics vehicle, transporting essential equipment to disaster sites to ensure successful rescue missions. The 6×6 combination rescue fire truck is widely used in emergency response, including natural disasters, urban building collapses, and chemical decontamination efforts, ensuring efficient and comprehensive support in critical situations.

FEATURES

● Powerful PerfoonaiXR – “One Vehicle with Multiple Removable Modules”

A single vehicle adaptable for various disaster scenarios, featuring a modular design with interchangeable heavy-duty equipment.

● Quality and Efficiency – Precision Equipment Layout and Advanced Dynamic Auxiliary Mechanism

Ergonomic design optimizes the equipment layout, reducing the physical effort required. It follows principles of speed, logic, and weight distribution, enhancing the efficiency of rescue operations. Equipped with multi-power auxiliary mechanisms for ease of use and energy conservation.

● Technological Intelligence – Digital Equipment Management

Daily digital management system with real-time monitoring of operational equipment.

● High Driving Performance – Active Independent Suspension Technology

Adaptable to various road conditions, offering superior off-road capability and enhanced control. Multiple steering modes provide better adaptability.

SPECIFICATION

Item		Unit	Parameter
Equipment	Type	—	138
Equipment	EA	—	700
Winch	Pull	t	10
Winch	Wire rope length	m	48
Max. speed		km/h	100
		mm	15,600
Min. turning diameter		mm	15,600
		mm	600
Fording depth		mm	600
		mm	2,090
Tread		mm	2,090
		—	6×6
Drive form		—	6×6
		mm	11,880×2,550×4,000
Dimension		mm	11,880×2,550×4,000
Hydraulic tail-plate	Lifting weight	kg	2,000
Hydraulic tail-plate	Lifting height	mm	1,550
Lighting power		W	4×1,000
Crew capacity		—	8
Max. gradability		—	60%
Min. ground clearance		mm	355
Approach and Departure Angle		°	30/30
Wheelbase		mm	5,200+1,650
Total weight		—	3
