    6x6 Combination Rescue Fire Truck

    6×6 Combination Rescue Fire Truck

    Model No.: CSCCRFT016
    Overall Dimensions(LxWxH): 11,880×2,550×4,000mm
    Drive Type: 6×6
    Wheelbase: 5,200+1,650mm
    Winch Pull: 10t
    Wire rope length: 48m
    Max. speed: 100km/h
    Hydraulic tail-plate lifting weight: 2,000kg
    Hydraulic tail-plate lifting height: 1,550mm
    Lighting power: 4×1,000W
    Crew capacity: 8
    Max. gradability: 60%
    Truck Enquiry
    Category:

    BRIEF



    The 6×6 combination rescue fire truck produced by CSCTRUCK Fire Rescue Truck is a heavy-duty rescue unit designed for high mobility, modularity, and intelligence. It carries over 138 types of equipment, with more than 700 individual pieces, making it versatile for various rescue operations. This vehicle serves multiple roles: as a lead vehicle at rescue scenes, providing lighting, pathways for survival, and search and rescue support. It can also function as a logistics vehicle, transporting essential equipment to disaster sites to ensure successful rescue missions. The 6×6 combination rescue fire truck is widely used in emergency response, including natural disasters, urban building collapses, and chemical decontamination efforts, ensuring efficient and comprehensive support in critical situations.



    FEATURES



    ● Powerful PerfoonaiXR – “One Vehicle with Multiple Removable Modules”
    A single vehicle adaptable for various disaster scenarios, featuring a modular design with interchangeable heavy-duty equipment.
    ● Quality and Efficiency – Precision Equipment Layout and Advanced Dynamic Auxiliary Mechanism
    Ergonomic design optimizes the equipment layout, reducing the physical effort required. It follows principles of speed, logic, and weight distribution, enhancing the efficiency of rescue operations. Equipped with multi-power auxiliary mechanisms for ease of use and energy conservation.
    ● Technological Intelligence – Digital Equipment Management
    Daily digital management system with real-time monitoring of operational equipment.
    ● High Driving Performance – Active Independent Suspension Technology
    Adaptable to various road conditions, offering superior off-road capability and enhanced control. Multiple steering modes provide better adaptability.

    SPECIFICATION



    Item

    Unit

    Parameter
    Equipment Type — 138
    EA — 700
    Winch Pull t 10
    Wire rope length m 48
    Max. speed km/h 100
    mm 15,600
    Min. turning diameter
    mm 600
    Fording depth
    mm 2,090
    Tread
    — 6×6
    Drive form
    mm 11,880×2,550×4,000
    Dimension
    Hydraulic tail-plate Lifting weight kg 2,000
    Lifting height mm 1,550
    Lighting power W 4×1,000
    Crew capacity — 8
    Max. gradability — 60%
    Min. ground clearance mm 355
    Approach and Departure Angle ° 30/30
    Wheelbase mm 5,200+1,650
    Total weight — 3
