53M Aerial Ladder Fire Truck

Make/Model:	CSCTRUCK/CSCLFT053
Overall Dimensions(LxWxH):	12,250×2,500×4,000mm
Total weight:	29,900kg
Max. travel speed:	≥90km/h
Max. net power:	315kW
Rated working height:	53m
Max. working radius:	18m
Rated platform load:	270kg
Water monitor rated flow:	≥80L/s
Water monitor rated reach:	≥70m
Fire-rated flow:	≥100L/s
Fire-rated pressure:	≥1MPa
Water tanker:	1,500kg

Truck Enquiry

Categories: Aerial Fire Truck, Ladder Fire Truck

Description
Reviews (0)

BRIEF

The 53M aerial ladder fire truck produced by CSCTRUCK Fire Rescue Truck is designed for versatile use, primarily focused on high-altitude rescues. It is also equipped with effective firefighting capabilities for mid-rise buildings, making it a valuable asset in urban areas. Its key features include exceptional flexibility, allowing it to adapt to various rescue and firefighting scenarios, and high operational efficiency, ensuring quick response times. The vehicle offers a strong, comprehensive rescue capability, making it suitable for a range of emergencies. Safety and reliability are top priorities, with the truck engineered to ensure the security of both firefighters and the people they rescue. With these features, the 53M aerial ladder fire truck fully meets the demanding firefighting and rescue needs of urban environments, especially for mid-rise structures. This combination of high-altitude reach and robust performance makes it an essential tool for modern firefighting operations.

FEATURES

– The 53M aerial ladder fire truck is compactly designed, featuring a short length, a small turning radius, and excellent maneuverability compared to others in its class.

– Equipped with strong rescue capabilities, the vehicle offers 2 rescue modes—working platform and axle fall block—delivering fast and efficient performance.

– The firefighting system includes a large-diameter aluminum alloy pipeline, an imported pump, and an imported monitor, all with a fully integrated configuration. With a 1.5-ton onboard water tank, it provides powerful firefighting capabilities.

– The safety protection system is comprehensive and dependable, featuring ladder vibration suppression and other control functions, significantly enhancing platform rescue comfort and operational reliability.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	12,250
Overall height	mm	4,000
Overall width	mm	2,500
Total weight	kg	29,900
Extinguishant-rated load weight
Water	kg	1,500
Foam	kg	—
Dry powder	kg	—
Max. travel speed	km/h	90
Max. net power	kW	315
Rated working height	m	53
Max. working radius	m	18
Rated platform load	kg	270
Time for deploying boom	s	≤150
Time for deploying outriggers	s	≤35
Monitor
Water monitor-rated flow	L/s	≥80
Water monitor-rated reach	m	≥70
Water pump
Fire-rated flow	L/s	≥100
Fire-rated pressure	MPa	≥1
Rated lift load	kg	180
The working speed of the lift	m/s	0.8
Working range of lift	°	45°-75°
