4×4 Emergency Vehicle Rescue Fire Truck

Model No.:	CSCEVRFT028
Overall Dimensions(LxWxH):	10,500×2,550×3,930
Drive Type:	4×4
Weight:	24,000kg(Excluding bulldozer)
Max. travel speed:	100km/h
Maximum Climbing Degree:	60%
Wading Depth:	600mm
Boom pitch angle:	-6～80
Rated Load of Platform:	300kg
Maximum Working Height:	27.5m
Maximum Working Depth:	-8m
Grab Maximum Weight:	1,500kg
Maximum Working Height:	18m
Maximum Working Depth:	-6m
Shearing Force:	390kN
Maximum Shear Round Steel Diameter:	Φ28MM
Maximum Lifting Capacity of Main Hook:	16,000kg
Main hook Maximum Working Height:	15.7m
Maximum Operating Range:	10m

Truck Enquiry

Categories: Multipurpose Fire Truck, Rescue Fire Truck

Description
Reviews (0)

BRIEF

The 4×4 emergency vehicle rescue fire truck produced by CSCTRUCK Fire Rescue Truck is a versatile, high-mobility vehicle designed for a wide range of emergencies. Equipped with capabilities such as lifting, grabbing, dragging, pushing, cutting, and expansion, it serves multiple rescue functions. The fire truck can be deployed as a first-response vehicle for clearing roads and removing obstacles or as a rescue vehicle for complex scenarios like high and low-altitude rescues and long-distance entries. Its design makes it invaluable in responding to natural disasters such as earthquakes, landslides, floods, and mudslides. The 4×4 emergency vehicle rescue fire truck is widely utilized for emergency operations, providing critical support in situations that require swift and efficient response.

FEATURES

● Multi-functional Base Unit

Equipped with a fast-change device, it can quickly connect with various modular machines and tools, offering great versatility. It also features electrical, hydraulic, and gas quick connection joints, making it convenient for quick attachment to handheld operating tools.

● Fast Wheel Exchange

Designed for high-speed driving on wheels to reach the work site quickly. It operates with triangular tracks near the working area, providing low ground pressure and strong performance on rough terrain. The common quick-change interface for tires and triangular tracks allows for fast switching, enhancing rescue efficiency.

● Modular Operation Equipment

The modular interface design of the operational equipment meets the needs for a variety of tasks, including saving, grabbing, lifting, dragging, cutting, expanding, and breaking functions.

● High Mobility Chassis

Offers strong off-road capability, superior overall performance, and more efficient control. It allows for a larger angle of climbing and higher vertical obstacle-crossing capability.

SPECIFICATION

Category	Item	Unit	Parameter
Dimension	Overall length	mm	10,500
	Overall height	mm	3,930
	Overall width	mm	2,550(Excluding bulldozer)
Drive Type		—	4×4
Weight	Total curb weight	kg	24,000(Excluding bulldozer)
Travel performance	Max. travel speed	km/h	100
	Maximum Climbing Degree	%	60
	Wading Depth	mm	600
	Approach Angle	°	30
	Departure Angle	°	30
Rescue	Boom pitch angle	°	-6～80
	Rated Load of Platform	kg	300
	Maximum Working Height/Maximum Operating Range/Maximum Working Depth	m	27.5/19/-8
Grab (Hand-held)	Grab Maximum Weight	kg	1,500
Grab (Hand-held)	Maximum Working Height/Maximum Operating Range/Maximum Working Depth	m	18/14.5/-6
Shear	Shearing Force	kN	390
Shear	Maximum Shear Round Steel Diameter	mm	Φ28
Expansion (Hand-held)	Maximum Extension tension	kN	120
Lifting	Maximum Lifting Capacity of Main Hook	kg	16,000
	Main hook Maximum Working Height/Maximum Operating Range	m	15.7/10
	Maximum Lifting Capacity of Auxiliary Hook	kg	2,500
	Auxiliary hook Maximum Working Height/Maximum Operating Range	m	25.5/20
Drag and Drop	Maximum Drag Force	kN	100
Drag and Drop	Length of Dragging Wire Rope	m	48
Breaking	Breaking Thrust	kN	50
Breaking	Breaking Width/Flat Width	mm	2,837/2,940
