The 32M Water Tower Fire Truck Upper Body, produced by CSCTRUCK Fire Rescue Truck, is a state-of-the-art firefighting solution designed for superior performance and stability in emergencies. This fire truck features a robust H-style outrigger system with a horizontal span of 5,630 mm and a transverse span of 5,820 mm, ensuring excellent operational control stability.

The truck’s main firefighting apparatus includes a 3-section telescopic boom combined with a fly jib boom structure, offering a maximum working height of 32 meters and a maximum working radius of 20 meters. This advanced configuration allows firefighters to access high and difficult-to-reach areas efficiently.

Equipped with a 6,000-liter water tank and a 2,000-liter foam tank, the truck is built for extensive firefighting missions. The water tank is constructed from high-quality 304 stainless steel, ensuring durability and resistance to corrosion. The car features the Waterous CB10/100-CXC20 water pump, which delivers a rated flow of 100 L/S at 1.0 MPa and a testing flow of 80 L/S at 1.5 MPa, with a DN150 inlet flange and DN100 outlet flange.

The fire truck also includes an America AKRON PLKD10/80B-5177 fire monitor, capable of a maximum flow rate of 4,800 L/min at 0.8 MPa, with a minimum effective water range of 65 meters and foam range of 60 meters. Additionally, the Waterous electric vacuum pump (24V) provides a vacuum capacity of ≥85 kPa, a suction depth of up to 7 meters, and a suction time of ≤70 seconds.

1. Advanced Boom Structure: The fire truck is equipped with a 3 telescopic boom plus 1 fly jib boom structure, enabling it to achieve a maximum working height of 32 meters and a maximum working radius of 20 meters. This design provides exceptional reach and versatility for firefighting operations.

2. Substantial Tank Capacities: It boasts a 6,000-liter water tank and a 2,000-liter foam tank, made from durable 304 stainless steel. This ensures a significant supply of firefighting resources, allowing extended operation times without the need for immediate refilling.

3. Powerful Pumping System: The truck features a Waterous CB10/100-CXC20 water pump with a rated flow of 100 liters per second at 1.0 MPa and a testing flow of 80 liters per second at 1.5 MPa. This powerful pump system ensures effective water and foam delivery during firefighting efforts.

4. Efficient Fire Monitor: The fire truck is fitted with an America AKRON PLKD10/80B-5177 fire monitor, which has a maximum flow of 4,800 liters per minute at 0.8 MPa. It is capable of shooting water to a distance of over 65 meters and foam to over 60 meters, providing extensive coverage during firefighting.

5. Reliable Outrigger System: The H-style outrigger system provides excellent stability and control during operation. With a horizontal span of 5,630mm and a transverse span of 5,820mm, this system ensures the fire truck remains stable even when operating at its maximum height and reach, enhancing safety and performance.
