32M Tower Ladder Fire Truck

Model No.:	CSCTLFT032
Water+Foam+Dry Powder Volume:	2,000+500+360kg
Overall Dimensions(LxWxH):	10,000×2,550×3,900mm
Total weight:	33,860kg
Max. travel speed:	≥100km/h
Max. net power:	356kW
Rated working height:	32M
Max. working radius:	26M
Water monitor rated flow:	≥80L/min
Water monitor rated reach:	≥70M
Fire-rated flow:	170L/min
Fire-rated pressure:	1MPa

Truck Enquiry

Categories: Aerial Fire Truck, Ladder Fire Truck

Description
Reviews (0)

BRIEF

The 32M tower ladder fire truck produced by CSCTRUCK Fire Rescue Truck is an advanced vehicle with comprehensive firefighting capabilities. Featuring a robust build with a total weight of 33,860kg, it ensures operation stability and durability. It offers versatile firefighting options, equipped with a 2,000-liter water tank, 500-liter foam tank, and 360kg dry powder capacity. Powered by a 356kW engine, it achieves speeds exceeding 100km/h, enhancing rapid response capabilities. With a rated working height of 32 meters and a maximum working radius of 26 meters, it facilitates effective rescue and firefighting operations in high-rise scenarios. The water monitor delivers a rated flow of over 80 liters per minute with a reach exceeding 70 meters, complemented by a fire-rated flow of 170 liters per minute at 1MPa pressure, ensuring effective fire suppression across various situations.

FEATURES

● Compact in size, the vehicle offers excellent maneuverability.

● Equipped with a high-mobility specialized chassis, rear-wheel drive, all-wheel steering, and active suspension leveling technology, it adapts well to challenging terrains.

● The control console, located in the cab, integrates a fire monitoring and wireless remote control system, allowing for low-speed firefighting operations from within the cab and remote control in high-risk situations.

● It features various fire-extinguishing systems that support multi-agent and 3-dimensional jet firefighting, providing large fire flows and superior firefighting capability.

● Intelligent firefighting functions are expandable for enhanced performance.

SPECIFICATION

Category	Item		Unit	Parameter
Dimension	Overall length		mm	10,000
	Overall height		mm	3,900
	Overall width		mm	2,550
Weight	Total weight		kg	33,860
	Extinguishant-rated load weight	Water	kg	2,000
		Foam	kg	500
		Dry powder	kg	360
Travel performance	Max. travel speed		km/h	≥100
Travel performance	Max. net power		kW	356
Main performance	Rated working height		m	32
Main performance	Max. working radius		m	26
Working speed	Time for deploying boom		S	≤120
Working speed	Time for deploying outriggers		S	≤30
Fire-fighting performance	Monitor	Water monitor-rated flow	L/min	≥80
	Monitor	Water monitor-rated reach	m	≥70
	Water pump	Fire-rated flow	L/min	170
	Water pump	Fire-rated pressure	MPa	1
