20M Water and Foam Tower Fire Truck

Make/Model:	CSCTRUCK/TFT020
Water+Foam:	17,000+3,000kg
Overall Dimensions(LxWxH):	12,000×2,550×4,000kg
Total weight:	42,680kg
Max. travel speed:	≥90km/h
Max. net power:	405kW
Rated working height:	20m
Max. working radius:	15m
Water monitor rated flow:	≥120L/s
Water monitor rated reach:	≥80m
Fire-rated flow:	≥170L/s
Fire-rated pressure:	≥1MPa

Truck Enquiry

Categories: Aerial Fire Truck, Tower Fire Truck

Description
Reviews (0)

BRIEF

The 20M water and foam tower fire truck produced by CSCTRUCK Fire Rescue Truck is a versatile firefighting vehicle that combines the functions of a water-tank truck, foam truck, and water tower fire truck into a single unit. Equipped with a firefighting liquid and foam device, it features both water and foam towers, making it highly effective for various firefighting situations. This vehicle is particularly suited for combating fires in low-rise buildings in towns, and industrial and mining enterprises, and is especially useful in petrochemical facilities, oil storage tanks, and warehouses. The 20M water and foam tower fire truck‘s integrated systems allow it to handle different fire scenarios, offering both water and foam capabilities for maximum efficiency and control. Its multifunctional design makes it an ideal choice for tackling complex fire hazards, providing enhanced fire suppression in a wide range of environments where both foam and water-based solutions are necessary.

FEATURES

– The 20M water and foam tower fire truck is designed to meet real-world firefighting demands, featuring an independent crew cabin with 4 seats. This setup is ideal for deploying firefighting teams. The cabin comes equipped with an air conditioning system, specialized fire-resistant seats, and an intercom system.

– Intelligent control enhances convenience and efficiency. All operations in the superstructure are managed from the chassis, which includes a newly upgraded control panel with a modern design and a 7-inch display. This provides real-time updates on the firefighting system’s status. The vehicle also features one-button controls for water spraying, foam application, external foam supply, and flushing, making operations straightforward.

– The wired remote control is designed for safety and reliability. Equipped with a 25-meter cable, a 4-inch display, and one-button firefighting controls, the 20M water and foam tower fire truck provides real-time status updates. It is especially suited for firefighting in flammable and explosive environments, offering better protection for firefighters.

– The all-aluminum alloy frame structure ensures a lightweight design with excellent corrosion resistance.

SPECIFICATION

Item	Unit	Parameter
Overall length	mm	12,000
Overall height	mm	4,000
Overall width	mm	2,550
Total weight	kg	42,680
Extinguishant-rated load weight
Water	kg	17,000
Foam	kg	3,000
Dry powder	kg	–
Max. travel speed	km/h	≥90
Max. net power	kW	405
Rated working height	m	20
Max. working radius	m	15
Time for deploying boom	s	≤70
Time for deploying outriggers	s	≤30
Monitor
Water monitor-rated flow	L/s	≥120
Water monitor-rated reach	m	≥80
Water pump
Fire-rated flow	L/s	≥170
Fire-rated pressure	MPa	≥1
