BRIEF
The 15 CBM pumper fire apparatus produced by CSCTRUCK Fire Rescue Truck is a high-capacity firefighting vehicle designed for efficient water delivery and fire suppression. Built on a Dongfeng chassis, this model features a 6×4 drive type, ensuring stability and reliability in various terrains.
Powered by an L340 30 engine, this fire truck generates 340 horsepower (HP), complying with the Euro 3 emission standard for environmentally friendly operations. Its 24V electric system provides reliable power for onboard equipment and lighting.
The 15 CBM pumper fire apparatus is equipped with a 15 CBM (15,000-liter) water tank, allowing for extended firefighting operations without frequent refilling. Its firefighting system includes a CB10/40 fire pump, capable of delivering a rated pressure of 1.0 MPa with a 40 liters per second (L/s) flow rate, ensuring strong water output.
For fire suppression, the truck is fitted with a PS40 fire gun, also offering a 40L/s flow rate and a jet distance of ≥60 meters, making it effective for combating large-scale fires from a safe distance.
Designed for municipal and industrial firefighting applications, the 15 CBM pumper fire apparatus provides robust performance, high water capacity, and reliable firefighting tools, making it an essential asset for fire departments and emergency response teams.
FEATURES
- Large Water Tank Capacity – Equipped with a 15 CBM (15,000 liters) water tank, providing extended firefighting capability.
- Powerful Engine & Chassis – Built on a Dongfeng 6×4 chassis with an L340 30 engine model, delivering 340HP and meeting the Euro 3 emission standard for reliable performance.
- Efficient Fire Pump System – Features a CB10/40 fire pump with a 40L/s rated flow and 1.0MPa rated pressure, ensuring strong water discharge capability.
- High-Performance Fire Gun – Equipped with a PS40 fire gun, capable of a 40L/s rated flow and achieving a ≥60m jet distance for effective fire suppression.
- Durable Electrical System – Operates on a 24V electric system, ensuring reliable power distribution for firefighting equipment and onboard systems.
SPECIFICATION
| Model No. | CSCWFTFT062 | ||
| Cab | Tianlong KC double row cab, channel type instrument panel, air conditioner, allowable 2+4 passengers. | ||
| Engine Power(Hp) | 340 | ||
| Power(kW) | 250 | ||
| Wheelbase | 4,350+1,300mm | ||
| Front/Rear Suspension | 1,460/2,820 | ||
| Steering | Power steering | ||
| Approach/departure angle | 20/10 | ||
| Wheels & tire | 11.00R20 | ||
| Tire number | 10+1 | ||
| Tank Dimensions(mm) | |||
| Cubage (m3) | 15 | ||
| RHD or LHD | optional | ||
| Overall Dimensions(LxWxH)(mm) | 10,200×2,500×3,700 | ||
| Curb Weight (Kg) | 15,000 | ||
| Engine | Model | L340 30 | |
| Horsepower | 340 | ||
| Maximum output kW | 250 | ||
| Maximum torque N·m | |||
| Type | 6 cylinders, in-line,4-stroke, water-cooled, turbo inter-cooling, diesel engine | ||
| Displacement | 8.900L | ||
| Cummins brand, Euro 3 | |||
| Driving passenger | 2+4 | ||
| Transmission | FAST 10 speed forward and 1 reverse, manual. | ||
| Front Axle | 6.5T | ||
| Rear Axle | 13Tx2 | ||
| Brake System | Air brake, Exhaust brake | ||
| Color and LOGO | Customized | ||
| Electric System | 24V | ||
| Fire Equipment Part | Fire pump | CB10/40, rated pressure 1.0MPa, flow 40L/s | |
| Fire gun | PS40, flow 40L/s, jet distance ≥ 60m | ||
| Standard Configuration | National standard equipment box, with national standard fire-fighting equipment, fire pump, fire gun, firepower take off, sliding gate, row type lights, reel, common tools, rear climbing ladder, water tank. | ||
