10 Wheelers 10CBM Suction Excavator

Model No.:	CSCSE010
Garbage Tank Volume+Water Tank Volume:	8.2+1.6CBM
Overall Dimensions(LxWxH):	10,420×2,500×3,890mm
Chassis Make/Model:	HOWO/ZZ1257N464GF1
Drive Type:	6×4
Wheelbase:	4,875+1,400mm
Rated Power@Speed:	294/1,900kW/r/m
Water pump pressure:	20MPa
Max total weight:	25,000kg
Emission Standard:	EURO 6
Suction system Suction deep:	≥30M
Suction system Suction length:	≥100M
Suction system Pipe diameter:	200MM
Water pump flow:	32L/min

Truck Enquiry

Category: Multipurpose Fire Truck

Description
Reviews (0)

BRIEF

The 10 wheelers 10CBM suction excavator produced by CSCTRUCK Fire Rescue Truck combines high mobility with advanced vacuum suction technology, designed to handle a variety of solid, liquid, and mixed materials such as sand, stone, soil, and sludge. This multifunctional vehicle excels in tasks like material collection, loading, and unloading, as well as non-destructive excavation. It is ideal for use in rescue operations, such as recovering individuals buried in sand or cleaning up material leaks and post-disaster sludge. Additionally, the 10 wheelers 10CBM suction excavator is highly effective in urban infrastructure maintenance, including non-destructive excavation of underground pipelines, pipeline dredging, and pollution cleanup. Its versatility makes it a valuable tool for municipal sanitation and disaster relief efforts, with a wide range of potential applications.

FEATURES

● Pneumatic Suction for Nondestructive Mining

Minimizes damage caused by mechanical contact, replacing manual mining and significantly boosting work efficiency.

● Powerful Suction

Equipped with high negative pressure and large airflow capacity, the suction system is highly efficient. It can extract objects from distances exceeding 100 meters horizontally and depths over 30 meters vertically. Capable of aspirating solids, liquids, or solid-liquid mixtures.

● Safety and Protection

Features dynamic monitoring of vacuum safety thresholds, along with real-time operational status tracking and quick response mechanisms to ensure equipment and personnel safety.

● Overhead Rotating Arm Support

Allows for a wide operational range with remote control functionality, enabling quick positioning and increased efficiency in operations.

● High-Efficiency Dust Control

A multi-stage dust removal module effectively separates water vapor, dust, and particles from the air, reducing dust and improving the working environment.

SPECIFICATION

Item	Unit	Parameter
Outline size(LxWxH)	mm	10,420×2,500×3,890
Chassis Model	—	ZZ1257N464GF1
Drive Type	—	6×4
Rated Power@Speed	kW/r/m	294/1,900
Boom Turning angle	°	±135
Boom Luffing angle	°	45
Boom Expansion length	mm	1,500
Tank volume	m³	8.2
Water pump pressure	MPa	20
Max total weight	kg	25,000
Wheelbase	mm	4,875+1,400
Axle	—	3
Emissions Standard	—	EURO 6
Suction system Suction deep	m	≥30
Suction system Suction length	m	≥100
Suction system Pipe diameter	mm	200
Water tank volume	m³	1.6
Water pump flow	L/min	32
